System Board Components and LEDs

System Board Fans

Cisco Wide Area Virtualization Engine 574 Hardware Installation Guide
1-12
Table 1-3 System Board LEDs (continued)
LED
11
DIMM 1 failure
12 Reserved
Figure 1-9 shows the location of the system board fans that provide ventilation for
the chassis.
Figure 1-9 System Board Fans
Chapter 1 Introducing the Cisco Wide Area Virtualization Engine 574
Color State
Amber On
- Off
- -
Description
DIMM has failed or is
missing.
Normal.
-
OL-17738-01
