Installing a Cisco WAVE Inline Adapter
Figure 4-1
Locate Slot 4, which is a standard PCI Express full-length slot.
Step 5
Note
Slide the expansion-slot cover out of the PCI riser-card assembly expansion slot.
Step 6
(See
Cisco Wide Area Virtualization Engine 574 Hardware Installation Guide
4-4
Removing the PCI Riser-Card Assembly
You can only install the Cisco WAVE inline network adapter card in
Slot 4.
Figure
4-2.)
Chapter 4
Installing Hardware Options for the WAVE-574
OL-17738-01
