Upgrading The Memory From 3 Gb To 6 Gb - Cisco WAVE-574-K9 - Wide Area Virtualization Engine 574 Hardware Installation Manual

Chapter 4 Installing Hardware Options for the WAVE-574

Upgrading the Memory from 3 GB to 6 GB

Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
OL-17738-01
This section describes how to upgrade your WAVE-574 device from the standard
3 GB of memory to 6 GB of memory.
To install the Cisco memory upgrade, follow these steps:
Power down the WAVE appliance.
Remove the WAVE appliance from the rack.
Remove the primary access panel (See the
page 4-1).
Open the DIMM slot latches for slot 2B and slot 4B (the black colored slots) See
Figure 4-5 on page 4-10.
Remove the 512 MB DIMMs from slot 2B and slot 4B.
Install one replacement 2-GB DIMM into slot 2B. Install the other replacement
2-GB DIMM into slot 4B. See
Cisco Wide Area Virtualization Engine 574 Hardware Installation Guide
"Removing the Covers" section on
Figure 4-5 on page 4-10.
Installing Memory
4-9
