11.4. Configuration of Radio card QUECTEL EC25
The following information is valid for the radio card QUECTEL EC25. Its precise
designation is:
USA: QUECTEL EC25A or EC25V

Europe: QUECTEL EC25E

The WWAN configuration is identical for both radio cards. For this reason, the
abbreviation QUECTEL EC25 is used.
11.4.1. Establish Internet connection
In the section below, the provider Vodafone is used as an example. Adjust the settings
for your provider.
DLT-V72 Series User Manual V2.76
Fig. 11.1: QUECTEL EC25 - Set up a new connection or network
Fig. 11.2: QUECTEL EC25 - Connect to the Internet
WWAN Configuration
1. Open the
Network and
Sharing
Center.
2. Click Set up a
new
connection or
network.
3. Connect to the
Internet -
select and
confirm.
