Quick Start and
Installation Guide
(EN)
DLT-V6210FL
1
Introduction – For Your Safety
− Read and observe this document and
the accompanying "DLT-V6210 Safety
Instructions" carefully.
− Keep all documents for future
reference.
− Go to
www.advantech.com
manuals, e.g. "DLT-V6210 Manual"
and "MDevice Configuration Manual".
DANGER
Observe the intended use.
Observe the intended use of the DLT-V6210, e.g.: No use in potentially
explosive zones and on ships, on railed vehicles, no use in life-supporting
systems or security-critical facilities.
Observe the required qualification.
This document is intended for qualified skilled personnel. Only skilled
personnel may put the DLT-V6210 into operation.
− Do not put the DLT-V6210 into operation if it is damaged.
− Do not open or modify the DLT-V6210.
− Only connect or disconnect electrical connections when the device is in a
de-energized state (electrically dead).
for detailed
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DLT-V6210FL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech-DLoG DLT-V6210FL

Summary of Contents for Advantech-DLoG DLT-V6210FL

  • Page 1 Quick Start and Installation Guide (EN) DLT-V6210FL Introduction – For Your Safety − Read and observe this document and the accompanying “DLT-V6210 Safety Instructions” carefully. − Keep all documents for future reference. − Go to www.advantech.com for detailed manuals, e.g. “DLT-V6210 Manual”...
  • Page 2 Design method in this document Hazards that pose a risk to life and limb – Personal injury: DANGER / WARNING / CAUTION DANGER: Danger that immediately leads to death or severe injury. WARNING: Danger that can lead to death or severe injury. CAUTION: Danger that can lead to slight injuries.
  • Page 3 External connectors of DLT-V6210 Connectors under the cable cover RSMA External Wi-Fi antenna interface Power Power supply 12/24/48 nominal Network 2 x network adapter (RJ45 connection jack) with adapter 10/100/1000 Mbit per second 2 x USB 2.0 Hi-Speed HOST A type, 5 VDC 500 mA Fused at 0.5 A per channel Serial COM Max.

  • Page 4: Overview Of Operation Elements

    Closing the antenna cap: − Place the antenna cap back onto DLT-V6210. The antenna cap seal must not be damaged; it must be seated correctly in the groove. − Tighten the two screws of the antenna cap again (1 Nm torque). Overview of operation elements NOTE: Users of the DLT-V6210 must be trained by skilled personnel and instructed about the operation of the device.
  • Page 5 Software configuration (e.g. Wireless) Basic software settings for DLT-V6210 are defined at the factory, for example with regard to Wi-Fi settings, network settings, etc. To adapt this, use the configuration tool for the respective operating system: WES7, WE8S, MDevice tool, etc. Win 10 IoT Ent., etc.
  • Page 6 Important notes before installation General: The DLT-V6210 installation environment must not result in a closed system. The cooling system of the device requires a supply of fresh air. Otherwise, there is a danger of overheating and damage to the device. Overview: Recommended installation steps Find a suitable installation position for the DLT-V6210.
  • Page 7 Notes about the attachment of device mounts and accessory mounts Mechanical expert knowledge is required for correct attachment of device mounts (e.g. mounting bracket, RAM mount) and accessory mounts (e.g. for scanner, keyboard) on the DLT-V6210. − Use suitable mounting material (screws and washers). −...
  • Page 8 Connect cables and cable cover Parts required NOTICE: Some screws and grommets delivered are spare parts. Part Name / Purpose Phillips screw, flat screw head, M3x5L F/S D=5.0 H=0.8 (1+)SUS BZn NK: − For fixing the cable cover to the terminal −...
  • Page 9 STEP 1: Plugging in and screwing on the power supply cable − Plug the power supply cable into the power supply plug-in location. − Tighten both mounting screws hand- tight. The screws required for this are already fixed in the delivered cable plug.
  • Page 10 STEP 3: Securing the power supply cable to the strain relief rail − Attach the matching cable grommet to the power supply cable. NOTICE: The cable grommet must completely surround the cable. The opening of the cable grommet must be slightly smaller than the cable diameter.
  • Page 11 Result (example): STEP 5: Closing off unused cable passages − Close off all unused cable passages with dummy grommets so that they are sealed. Dummy grommets STEP 6: Attaching the cable cover − Place the cable cover on the DLT-V6210 housing slot. −...

  • Page 12: Technical Customer Support

    Technical customer support Advantech-Service & Support Find out about our worldwide and comprehensive service offering: https://erma.advantech.com Manufacturer address Advantech Co., Ltd. No. 1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 11491, Taiwan, R.O.C. Web: www.advantech.com E-Mail: aeu.helpdesk@advantech.com Warranty The statutory warranty applies to the DLT-V6210 and accessories.
