Quick Start and
Installation Guide (EN)
DLT-V6210
1
Introduction – For Your Safety
− Read and observe this document and
the accompanying "DLT-V6210 Safety
Instructions" carefully.
− Keep all documents for future
reference.
− Go to www.advantech-dlog.com for
detailed manuals, e.g. "DLT-V6210
Manual" and "MDevice Configuration
Manual".
DANGER
Observe the intended use.
Observe the intended use of the DLT-V6210, e.g.: No use in potentially
explosive zones and on ships, on railed vehicles, no use in life-supporting
systems or security-critical facilities.
Observe the required qualification.
This document is intended for qualified skilled personnel. Only skilled
personnel may put the DLT-V6210 into operation.
− Do not put the DLT-V6210 into operation if it is damaged.
− Do not open or modify the DLT-V6210.
− Only connect or disconnect electrical connections when the device is in a
de-energized state (electrically dead).
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DLT-V6210 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech-DLoG DLT-V6210

Summary of Contents for Advantech-DLoG DLT-V6210

  • Page 1 Manual” and “MDevice Configuration Manual”. DANGER Observe the intended use. Observe the intended use of the DLT-V6210, e.g.: No use in potentially explosive zones and on ships, on railed vehicles, no use in life-supporting systems or security-critical facilities. Observe the required qualification.
  • Page 2 DANGER / WARNING / CAUTION DANGER: Danger that immediately leads to death or severe injury. WARNING: Danger that can lead to death or severe injury. CAUTION: Danger that can lead to slight injuries. Technical data of DLT-V6210 DLT-V6210 Weight 3.2 kg...
  • Page 3 External connectors of DLT-V6210 Connectors under the cable cover RSMA External Wi-Fi antenna interface Power Power supply 12/24/48 nominal Network 2 x network adapter (RJ45 connection jack) with adapter 10/100/1000 Mbit per second 2 x USB 2.0 Hi-Speed HOST A type, 5 VDC 500 mA Fused at 0.5 A per channel...

  • Page 4: Overview Of Operation Elements

    Closing the antenna cap: − Place the antenna cap back onto DLT-V6210. The antenna cap seal must not be damaged; it must be seated correctly in the groove. − Tighten the two screws of the antenna cap again (1 Nm torque).
  • Page 5 Software configuration (e.g. Wireless) Basic software settings for DLT-V6210 are defined at the factory, for example with regard to Wi-Fi settings, network settings, etc. To adapt this, use the configuration tool for the respective operating system: WES7, WE8S, MDevice tool, etc.
  • Page 6 Important notes before installation General: The DLT-V6210 installation environment must not result in a closed system. The cooling system of the device requires a supply of fresh air. Otherwise, there is a danger of overheating and damage to the device.
  • Page 7 (e.g. mounting bracket, RAM mount) and accessory mounts (e.g. for scanner, keyboard) on the DLT-V6210. − Use suitable mounting material (screws and washers). − Observe the maximum screw-in depth of the holes of the DLT-V6210: The recommended screw-in depth of D x 1 always applies (screw diameter x 1).
  • Page 8 Connect cables and cable cover Parts required NOTICE: Some screws and grommets delivered are spare parts. Part Name / Purpose Phillips screw, flat screw head, M3x5L F/S D=5.0 H=0.8 (1+)SUS BZn NK: − For fixing the cable cover to the terminal −...
  • Page 9 (from inside to outside): Place toothed washer first: Then put the ring tongue of the power supply cable (flat side faces the DLT-V6210 connector panel): Place the nut and tighten it hand-tight:...
  • Page 10 If the opening is too large or too small, the sealing of the device will not be ensured. As a delivery standard, screws and cable clips are fixed on the DLT-V6210 strain relief rail. − Unscrew and remove the screws and the cable clip fixed on the cable passage you want to use for the power supply cable.
  • Page 11 Dummy grommets STEP 6: Attaching the cable cover − Place the cable cover on the DLT-V6210 housing slot. − Use 4 pcs of Phillips Screws M3x5L: − Lock the screws loosely into the holes of the cable cover.

  • Page 12: Technical Customer Support

    Phone: +49 (0)89 / 41 11 91 999 Warranty The Advantech-DLoG general terms and conditions of business are applicable to DLT-V6210 and its accessories (Liability for defects -> limitation period for claims in relation to defects). For more details, please refer to www.advantech- dlog.com.
