Advantech-DLoG DLT-V7210KD User Manual

Industrial computer
Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
DLT-V72 Series
Industrial Computer

Advertisement

loading
Need help?

Need help?

Do you have a question about the DLT-V7210KD and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech-DLoG DLT-V7210KD

Summary of Contents for Advantech-DLoG DLT-V7210KD

  • Page 1 User Manual DLT-V72 Series Industrial Computer...
  • Page 2 IMPORTANT: For safe and proper use, follow these instructions. Keep them for future reference. Manual version Manual version: V2.76 Completed on: July 26, 2022 Revision history (starting from DLT-V72 Facelift 2019): Version Date Manual modifications Description of new Facelift models DLT-V7210 KD and DLT-V7212 P+. September 12, V2.60 2019...
  • Page 3 Copyright This document and the software and hardware included with this product are copyrighted 2019- 2021 by Advantech Co., Ltd. All rights are reserved. This document is intended for reference purposes only. All product specifications are subject to change without notice. Advantech Co., Ltd.
  • Page 4 Manufacturer Advantech Co., Ltd. No. 1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 11491, Taiwan, R.O.C. Simplified EU declaration of conformity The manufacturer: Advantech Co., Ltd. No.1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 11491, Taiwan, R.O.C. The importer: Advantech Europe B.V.
  • Page 5 Initial inspection Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with the table, please contact your dealer immediately: DLT-V72 Industrial Computer • Cable cover and cable sealing set •...
  • Page 6 Introduction Contents 1. Introduction ..........11 1.1. About the DLT-V72 manuals ....................... 12 1.1.1. Manuals for all DLT-V72 models ..................... 12 1.1.2. Further available manuals ....................... 13 1.1.3. Abbreviations used ......................... 13 1.1.4. Design elements used in the manuals ..................14 1.1.5.
  • Page 7 Introduction 5.4.1. DC voltage supply connection ....................40 5.4.2. DC Power supply cable ......................41 6. Technical Data – Radio ......42 6.1. Identification of radio equipment variants .................... 43 6.2. Radio cards (optional) ......................... 44 6.2.1. Radio card for WLAN: SPARKLAN WPEQ-261ACN (BT) ............44 6.2.2.
  • Page 8 Introduction 9.2.2. Configuring the front keys, automatic shutdown, etc.............. 81 9.2.3. Energy options and battery pack durability ................81 9.2.4. Suppress automatic Win10IoTEnt updates ................82 9.3. Linux (optional) ............................ 83 9.4. ADLoG Android (optional) ........................83 9.5. Automatic shut down ........................... 84 9.6.
  • Page 9 Introduction 12.2. Overview: Recommended mounting sequence ................. 142 12.2.1. Mounting the DLT-V72 at the deployment location ............... 143 12.2.2. Electrically isolated DLT-V72 mounting ................144 12.2.3. Attaching accessories to the DLT-V72 .................. 145 12.2.4. VESA mounting hole pattern ....................146 12.2.5.
  • Page 10 Introduction 16.3. Replacing the battery pack ........................ 178 16.4. Replacing the touchscreen protective film ..................178 17. Troubleshooting ........179 18. Guidelines and Certificates ....182 18.1. USA/CANADA: FCC Part 15 Statement .................... 183 18.2. ICES Kanada ............................. 184 18.3. CNROHS ............................184 19.
  • Page 11 Introduction Introduction DLT-V72 Series User Manual V2.76 11 / 189...
  • Page 12 Introduction 1.1. About the DLT-V72 manuals NOTE Pay attention to the DLT-V72 manuals because they help avoid hazards, reduce repair costs and downtimes, and increase the reliability and service life of the DLT-V72. Keep the manuals for future use. Please contact Advantech if you require additional information or clarification.
  • Page 13 Introduction 1.1.2. Further available manuals Manual Contents Availability For target group ADLoG Config Software Skilled PDF file at our configuration Windows personnel websites tool description ADLoG Linux OS and Linux Skilled Upon request, please configuration personnel contact our Technical Customer Support Android OS and Android...
  • Page 14 Introduction 1.1.4. Design elements used in the manuals Safety notes and other notices <Signal word> Damage to persons Signal word DANGER means that death or severe bodily injury will occur if this information is not observed. Signal word WARNING means that death or severe bodily injury can occur if this information is not observed.
  • Page 15 Introduction 1.1.5. Text formatting conventions Subject Formatting Example Lists Bullet points Part 1  Part 2  Instructions Numbers 4. Copy file … 5. Rename file … Product names Normal, not Software MDevice is a setup tool highlighted for … Bold With button Next …...
  • Page 16 Safety Chapter Safety Chapter DLT-V72 Series User Manual V2.76 16 / 189...
  • Page 17 Safety Chapter 2.1. Please read and observe. These safety instructions apply to all device models in the DLT-V72 Series: For DLT- V7210, DLT-V7212 and DLT-V7215 in various equipment levels. WARNING Non-observance of the safety instructions can result in injury to persons and in physical damage, e.g.
  • Page 18 Safety Chapter 2.3. Battery pack safety The DLT-V72 is optionally available with an integrated UPS. The battery pack of the UPS is located in the battery pocket of the device: Fig. 2.1: Battery pocket with UPS DLT-V72 EXPLOSION HAZARD! BATTERY PACK SAFETY NOTICE Battery packs may ignite if stored or handled incorrectly (fire risk, explosion risk), and may cause chemical burns or release poisonous substances.
  • Page 19 Safety Chapter Prevent physical damage due to deep discharge. Storing the battery packs incorrectly will cause them to discharge completely (deep discharge) and thus damage them irreparably. To prevent a deep discharge: 1. Remove the battery pack from the battery pocket, if the DLT-V72 is not used for a longer period of time (more than one month).
  • Page 20 Safety Chapter 2.5. Information on safe mounting During the mounting process The DLT-V72 can fall down and cause injuries due to its weight. 1. Use the assistance of a second person for installation work. 2. Always hold the DLT-V72 by the housing with both hands. 3.
  • Page 21 Safety Chapter 2.6. Information on safe electrical installation Danger of electric shock 1. Do not put the DLT-V72 into operation if it is showing damage. 2. Do not open or modify the DLT-V72. 3. Only connect or disconnect electrical connections when the device is in a de-energized state.
  • Page 22 Safety Chapter 2.7. Safety during ongoing work operations Users of the DLT-V72 must be trained by skilled personnel and instructed in the operation of the device. All users must be familiar with all functions of the product they come into contact with. General 1.
  • Page 23 Safety Chapter 2.8. Regular maintenance work Please read manual section 16 Maintenance. 2.9. Repairs, modifications Only authorized Advantech Service Centers may perform the following: Open the device (front unit and base unit)  Repairs  Modifications  Replace integrated modules, e.g. radio cards ...
  • Page 24 Safety Chapter 2.10. Recycling information Fig. 2.2: Recycling information icons DLT-V72 devices and lithium-ion batteries are recyclable; they may not be disposed of with general/domestic waste. They must be disposed of properly in accordance with local regulations. Please contact the responsible authorities in your country/region to find out about the applicable regulations for proper disposal, if necessary.
  • Page 25 Functional Description Functional Description DLT-V72 Series User Manual V2.76 25 / 189...
  • Page 26 Functional Description 3.1. Intended use DLT-V72 Industrial Computers are data communication terminals for use in commercial industries such as logistics, warehousing and manufacturing. Any other or additional use beyond this is regarded as improper use. DLT-V72 Industrial Computers are only permitted to be operated: In accordance with the defined intended use.
  • Page 27 Functional Description 3.2. Mount, operate and service the device correctly DLT-V72 Industrial Computers were designed and built according to modern technology and accepted safety regulations. However, the operation of the DLT-V72 can endanger personnel or third parties and cause damage to the device and other material assets when, for example, the device is Installed incorrectly or configured improperly ...
  • Page 28 Unpacking, Storing Unpacking, Storing DLT-V72 Series User Manual V2.76 28 / 189...
  • Page 29 Unpacking, Storing 4.1. Packing list Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with the table, please contact your dealer immediately: DLT-V72 Industrial Computer  Cable cover and cable sealing set ...
  • Page 30 Unpacking, Storing 4.4. Storage WARNING Personal injury from integrated UPS battery pack: Short- circuit, fire, chemical burns, toxic substances Some DLT-V72 devices contain an integrated UPS with a battery pack (hereinafter referred to as “battery pack”). These can ignite (risk of fire), cause chemical burns or release toxic substances. 1.
  • Page 31 Technical Data – Device Technical Data – Device DLT-V72 Series User Manual V2.76 31 / 189...
  • Page 32 Technical Data – Device 5.1. General NOTE The latest status of technical data is available in the DLT-V72 data sheets at our websites. Intel ATOM™ E3845 Quad Core 1.91 GHz Processor ® Chipset Dual channel 1333 MHz memory bus speed Cache 2 MB L2 cache, 22 nm 4 GB RAM...
  • Page 33 Technical Data – Device Display DLT-V7215 P+ 15" XGA color TFT 1024 x 768 resolution 600 cd/m² brightness The LCD display of the DLT-V72 series fulfills the highest quality standards and was inspected for pixel defects. However, due to technological reasons pixel defects can occur.
  • Page 34 Technical Data – Device Projected-capacitive touchscreen (PCT) Type Projected-capacitive touchscreen Construction Glass film Surface Hardness JIS-K-5400: > 10 H at 750 g Chemical AR coated glass: DLT-V7210 P and DLT-V7212 P gloss value 85 at 60° DLT-V7210 K, KD and DLT-V7212 P+ gloss value 70 at 60° DLT-V7215 P+ gloss value 80 at 60°...
  • Page 35 Technical Data – Device 5.2. Environmental conditions DLT-V72 without integrated UPS Operating temperature -30 to +50 °C Specification according to EN 60068-2-1/2 Storage temperature -30 to +65 °C Specification according to EN 60068-2-1/2 Relative humidity 10% to 90% at 40 °C relative humidity Noncondensing Specification according to EN 60068-2-3 Mechanical vibration...
  • Page 36 Technical Data – Device 5.3. Device dimensions 5.3.1. DLT-V7210 P, R, D Dimensions without add-ons (in mm) Fig. 5.1: Dimensions DLT-V7210 P, R, D (in mm) 5.3.2. DLT-V7212 P, R, D Dimensions without add-ons (in mm) Fig. 5.2: Dimensions DLT-V7212 P, R, D (in mm) DLT-V72 Series User Manual V2.76 36 / 189...
  • Page 37 Technical Data – Device 5.3.3. DLT-V7210 K, KD Dimensions without add-ons (in mm) Fig. 5.3: Dimensions DLT-V7210 K, KD (in mm) 5.3.4. DLT-V7212 P+ Dimensions without add-ons (in mm) Fig. 5.4: Dimensions DLT-V7212 P+ (in mm) DLT-V72 Series User Manual V2.76 37 / 189...
  • Page 38 Technical Data – Device 5.3.5. DLT-V7215 P+ Dimensions without add-ons (in mm) Fig. 5.5: Dimensions DLT-V7215 P+ (in mm) 5.3.6. VESA drill holes The back of the DLT-V72 has a VESA-compatible 75 x 75 mm mounting hole pattern. It is used to attach VESA-compatible mountings to mount the DLT-V72 at the deployment location.
  • Page 39 Technical Data – Device 5.4. Integrated power supply, power supply cable DLT-V72 is equipped with a galvanically separated, integrated DC power supply unit. Power is connected to the back of the unit using a Phoenix Contact plug. There is no power switch.
  • Page 40 Technical Data – Device Power consumption DLT-V7210 (all model types) Typically 25 W; Standby typically 1 W DLT-V7212 (all model types) Typically 30 W; Standby typically 1 W DLT-V7215 P+ Typically 30 W; Standby typically 1 W Power supply unit fuses Power supply unit Fuse type Example...
  • Page 41 Technical Data – Device 5.4.2. DC Power supply cable Fig. 5.8: DC connection cable assignment DLT-V72 Series User Manual V2.76 41 / 189...
  • Page 42 Technical Data – Radio Technical Data – Radio DLT-V72 Series User Manual V2.76 42 / 189...
  • Page 43 Technical Data – Radio 6.1. Identification of radio equipment variants The DLT-V72 offers numerous radio modules for WLAN, WWAN, GNSS and Bluetooth. This radio modules are available as options and are not included in the standard scope of delivery of the DLT-V72 device. To identify the modules installed in your device, proceed as follows: 1.
  • Page 44 Technical Data – Radio 6.2. Radio cards (optional) NOTICE Prevent system malfunction and property damage DLT-V72 may only be operated with the radio modules described in the following section. Radio cards are located inside the devices and are not accessible from the outside. Only the manufacturer and its authorized service centers may open the device and install / remove it.
  • Page 45 Technical Data – Radio 6.2.2. Radio card for WWAN: QUECTEL EC25 A/E USA: QUECTEL EC25A Europe: QUECTEL EC25E Card type WWAN PCIe Full-Mini Card Technology WWAN 2G, 3G, 4G cellular bands and GNSS FCCID FCC ID: XMR201605EC25A (valid for the EC25-A variant) Class 3 (23dBm±2dB) for LTE FDD Maximum transmitting power...
  • Page 46 Technical Data – Radio 6.3. Antennas (optional) 6.3.1. WLAN antenna IEEE 802.11 a/b/g/n/ac Fig. 6.1: WLAN antenna IEEE 802.11 a/b/g/n/ac Technical data Application WLAN a/b/g/n/ac Dual Band with MRC Bluetooth (integrated via Radio card) WLAN frequency range Band 1: 2400 to 2485 MHz Band 2: 5150 to 5850 MHz Bluetooth features See section 6.3.5 Bluetooth integrated (optional)
  • Page 47 Technical Data – Radio 6.3.2. WLAN, WWAN, LTE 4G antenna (Multiband) Fig. 6.2: WLAN, WWAN, LTE 4G antenna (Multiband) Technical data Application WLAN IEEE 802.11 ac/a/b/g/n/ac Dual Band with MRC WWAN 4G Bluetooth WLAN frequency range Band 1: 2400 to 2485 MHz Band 2: 5150 to 5875 MHz WWAN frequency bands FDD LTE: B1/B3/B5/B7/B8/B20...
  • Page 48 Technical Data – Radio Compatible WLAN card: SPARKLAN WPEQ-261 ACN (BT) (see section 6.2.1 Radio card) Compatible WWAN card: USA: QUECTEL EC25A Europe: QUECTEL EC25E (see section 6.2.2 Radio card) 6.3.3. External WLAN antenna IEEE 802.11 a/b/g/n Fig. 6.3: External WLAN antenna Technical data Application WLAN IEEE 802.11 a/b/g/n Dual Band...
  • Page 49 Technical Data – Radio 6.3.4. External WWAN antenna 2G, 3G, 4G Fig. 6.4: External 2G, 3G, 4G WWAN antenna Technical data Application WWAN 2G, 3G, 4G cellular bands Mounting location For detached mounting, e.g. on the roof of the forklift Number of antennas Type Omnidirectional antenna...
  • Page 50 Technical Data – Radio 6.3.5. Bluetooth integrated (optional) Requirement: Use of the radio card SPARKLAN WPEQ-261ACN (BT) Bluetooth Type 5.0  Standards: V5.0, V4.2 +HS, V4.0 LE, V3.0+HS, V2.1+EDR  Transmission rate: 1 Mbps, 2 Mbps, up to 3 Mbps ...
  • Page 51 Technical Data – Radio 6.3.6. GPS receiver external (optional) With the optional GPS receiver the DLT-V72 can be used for GPS navigation. The GPS receiver has an integrated antenna for position data of the Global Positioning System and communicates with the DLT-V72 via USB interface. We recommend using only a GPS receiver approved by Advantech.
  • Page 52 Connectors Connectors DLT-V72 Series User Manual V2.76 52 / 189...
  • Page 53 Connectors 7.1. Connectors under the cable cover Cable cover Connectors located on the connector panel under the cable cover: Fig. 7.1: Connectors on the connector panel under the cable cover Pin assignment description Power supply 12/24/48 VDC nominal 1 x SMA (optional) Remote WWAN antenna 1 x RSMA (optional) Remote WLAN antenna...
  • Page 54 Connectors COM1 as a voltage source The COM1 interface can optionally supply to externally connected equipment with +5 VDC. The voltages are protected by internal fuses and may not exceed a continuous consumed current of 1 A at 5 V. Depending on the connected devices, the maximum current consumption may be significantly lower.
  • Page 55 Connectors 7.1.1. Opening the cable cover 1. Unscrew the thin headless screws of the cable cover with an Allen wrench, size 2. Carefully remove the cable cover. NOTICE Prevent system malfunction and property damage Improper opening of the cable cover can impair the function of the entire DLT-V72 system.
  • Page 56 Connectors 7.2. Connectors under the antenna Antenna Connectors located under the antenna: Service-USB (USB 3.0 Host, SUPERSPEED  CFast slot  Mini-SIM card slot (optional)  7.2.1. Devices with sealing plate DLT-V72 devices without radio equipment have a sealing plate instead of the radio antenna: Fig.
  • Page 57 Connectors 4. Hold cards and sticks securely and carefully, and insert precisely into the connections to avoid anything falling inside the device. 5. To remove the CFast card, carefully push on the card. 6. Use only CFast cards that have been approved by Advantech. 7.
  • Page 58 Connectors 7.2.2. Open/close the WLAN antenna IEEE 802.11 a/b/g/n/ac Fig. 7.4: WLAN antenna IEEE 802.11 a/b/g/n/ac NOTICE Prevent system malfunction and property damage Improper opening of the antenna can impair the function of the entire DLT-V72 system and in particular the radio functionality. 1.
  • Page 59 Connectors Follow these steps to open antenna “WLAN antenna IEEE 802.11 a/b/g/n/ac”: Tools required: Torx screwdriver, Tx20  Opening the antenna: Fig. 7.5: WLAN antenna IEEE 802.11 a/b/g/n/ac 1. Unfasten both screws on the antenna with a Torx screwdriver, Tx20. 2.
  • Page 60 Connectors 7.2.3. Open/close the WLAN, WWAN, LTE 4G antenna Fig. 7.7: WLAN, WWAN, LTE 4G antenna (Multiband) NOTICE Prevent system malfunction and property damage Improper opening of the antenna can impair the function of the entire DLT-V72 system and in particular the radio functionality. 1.
  • Page 61 Connectors Follow these steps to open antenna type “WLAN, WWAN, LTE 4G”: Tools required: Torx screwdriver, Tx20  Allen key size 7  Step 1: Opening the antenna cap: 1. Unfasten both screws on the antenna cap with a Torx screwdriver, Tx20. 2.
  • Page 62 Connectors Step 2: Removing the antenna module: 1. Unfasten both screws on the antenna module with an Allen key (size 7) 2. Remove the antenna module extremely carefully. Service USB, CFast and mini SIM card slot are now accessible: Fig. 7.10: Antenna module WLAN, WWAN LTE 4G is open NOTICE Prevent system malfunction and property damage 1.
  • Page 63 Operating the DLT-V72 Operating the DLT-V72 DLT-V72 Series User Manual V2.76 63 / 189...
  • Page 64 Operating the DLT-V72 8.1. Safety notes WARNING Personal injury, Property damage and downtimes due to improper operation Users of the DLT-V72 must be trained by skilled personnel and instructed in the operation of the device. All users must be familiar with all functions of the product they come into contact with.
  • Page 65 Operating the DLT-V72 8.2. Switching the DLT-V72 on/off The following factors determine how the DLT-V72 can be switched on and off: Is the DLT-V72 mounted on a vehicle and connected with the ignition signal?  What are the automatic shutdown settings that were defined in the respective ...
  • Page 66 Operating the DLT-V72 8.3. Operating the touchscreen All touchscreens (Resistive and PCT) can be operated with: Clean, dry fingers  Clean, dry gloves  Resistive touchscreens can be operated with: Suitable touch stylus plastic or wood, rounded tip  PCT touchscreens can be operated with: Suitable touch stylus with capacitive (electrically conductive) tip ...
  • Page 67 Operating the DLT-V72 8.3.2. Operating the PCT with gloves For PCT touchscreens, you can adjust the touch sensitivity with the ADLoG Config tool. NOTE The “ADLoG Config Manual” is available at our websites: www.advantech.com DLT-V72 Series User Manual V2.76 67 / 189...
  • Page 68 Operating the DLT-V72 8.4. Operation elements 8.4.1. DLT-V72 rear side DLT-V72 Series User Manual V2.76 68 / 189...
  • Page 69 Operating the DLT-V72 8.4.2. Front side DLT-V7210 and DLT-V7212: P, R, D Note on the backlighting function on/off: The DLT-V72 will continue to react to keyboard, mouse and touchscreen inputs even if the backlight is switched off. DLT-V72 Series User Manual V2.76 69 / 189...
  • Page 70 Operating the DLT-V72 8.4.3. Front side DLT-V7212 and DLT-V7215: P+ DLT-V72 Series User Manual V2.76 70 / 189...
  • Page 71 Operating the DLT-V72 8.4.4. Front side DLT-V7210 K, KD Note on the backlighting function on/off: The DLT-V72 will continue to react to keyboard, mouse and touchscreen inputs even if the backlight is switched off. DLT-V72 Series User Manual V2.76 71 / 189...
  • Page 72 Operating the DLT-V72 8.5. Using the integrated keyboard 8.5.1. Language variants Device model Languages available English  DLT-V7210 K German  French  English DLT-V7210 KD  Example English version (QWERTY): Fig. 8.1: Integrated keyboard English (QWERTY) 8.5.2. Description of specific keys (in all languages) General Function Caps Lock: permanent switch to uppercase letters...
  • Page 73 Operating the DLT-V72 Sticky key function for one-hand operation Modifier Key Operation mode on the DLT-V72 When you press a modifier key (SHIFT, CTRL, and ALT) on the DLT-V72 keyboard, this key is active for the duration of 4 seconds. This facilitates inputting key combinations with one hand.
  • Page 74 Operating the DLT-V72 8.5.4. Integrated keyboard French (AZERTY) features Fig. 8.3: Integrated keyboard French (AZERTY) Special characters French: Character Press the keys successively: Æ ALT + 146 æ ALT + 145 Ç FN + C or ALT + 128 É FN + J or ALT + 144 Œ...
  • Page 75 Operating the DLT-V72 8.6. Operating states LED status DLT-V72 status Supply voltage Temperature Initial state, idle time – waiting for a new ignition signal or for the POWER button after switch-off; no voltage supply FLASHING Temperature sensor faulty FLASHING DLT-V72 is in standby mode (S3) Computer will only start if the temperature in the device is in the range between -30 and +59 °C again.
  • Page 76 Operating the DLT-V72 8.7. Software keyboard (optional) The optional “DLoG software keyboard” brings the complete standard keyboard with function keys and numeric pad directly to your DLT-V72 screen – with easy touch operation. Any entries made, for example, letters and numbers, are passed to the currently active application program.
  • Page 77 Operating the DLT-V72 8.8. Operating the DLT-V72 with UPS The DLT-V72 is optionally available with an integrated UPS. The battery pack of the UPS is located in the battery pocket of the device: Fig. 8.5: Battery pocket with UPS DLT-V72 WARNING Personal injury due to short-circuit, fire, chemical burns, toxic substances.
  • Page 78 Operating the DLT-V72 8.9. Internal speaker, sound The DLT-V72 is equipped with an internal speaker as standard (2 W). The system messages from the industrial PC are output via this speaker. The internal speaker is configured in the audio settings for the operating system in question. DLT-V72 Series User Manual V2.76 78 / 189...
  • Page 79 General Device Configuration General Device Configuration DLT-V72 Series User Manual V2.76 79 / 189...
  • Page 80 General Device Configuration 9.1. Operating systems (optional) NOTE Please find the latest overview of all supported operating systems in the DLT-V72 data sheets at our websites. The following operating systems are available at the time of manual creation, Feb 2021: MS Windows 10 IoT Enterprise (Win10IoTEnt) ...
  • Page 81 General Device Configuration 9.2.2. Configuring the front keys, automatic shutdown, etc. The DLoG Config software is used to configure DLT-V72 devices with a MS Windows operating system. For configuring DLT-V72, the DLoG Config version 5.0 or higher is required. Configuration examples: Automatic shut down ...
  • Page 82 General Device Configuration 9.2.4. Suppress automatic Win10IoTEnt updates Under Win10IoTEnt, the automatic Windows updates can no longer be deactivated; the Never check for updates setting in the Windows Update dialog is not available. With the following entry in the Windows registry, the Never check for updates setting can be set anyway: 1.
  • Page 83 General Device Configuration 9.3. Linux (optional) NOTE The configuration of the DLT-V72 with Linux with regard to radio networks, touchscreen calibration, etc. is described in the “Advantech Linux Manual”. Please contact our Technical Customer Support if required. 9.4. ADLoG Android (optional) NOTE The configuration of the DLT-V72 with Android with regard to radio networks, touchscreen calibration, etc.
  • Page 84 General Device Configuration 9.5. Automatic shut down Functional description The DLT-V72 is equipped with an automatic shutdown module. If wired up accordingly, the DLT-V72 conveniently switches off together with the vehicle’s ignition. As disconnecting the power supply during operation can lead to data loss, the operating system needs to be shut down normally using the appropriate hardware and software installed on the system when the ignition is switched off.
  • Page 85 General Device Configuration Device shut down If the operating system is shut down, all applications will be notified via the Windows message “WM_QUERYENDSESSION” first. Every application must then respond within the time set in the registry. If there is no response within the preset time, the application will be hard-terminated.
  • Page 86 General Device Configuration 9.6. MPair With the help of the MPair application, Bluetooth® capable 2D scanners can be connected to the terminal by scanning an onscreen barcode. NOTE This function is only available for industrial computers of the DLT- V72 and DLT-V83 series, which are equipped with the WLAN-Card SPARKLAN WPEQ-261ACN (BT).
  • Page 87 General Device Configuration 9.7. MTouch With the help of the MTouch application, users without administrator rights can switch the PCAP touch sensitivity between different modes for better glove support during use. MPair supports the following operating systems. Windows 10 IoT Enterprise 2019 •...
  • Page 88 General Device Configuration 9.8. DeviceOn/iService support Advantech’s DeviceOn/iService is a next-generation unified device management solution based on the WISE-DeviceOn platform. Designed to enable centralized monitoring and remote management, DeviceOn/iService supports Advantech devices equipped with Windows, Linux, or Android operating systems. The software also supports the management of applications and integrated peripherals, such as barcode scanner, card reader, camera, and printer.
  • Page 89 General Device Configuration Installation requirements The following Windows 10 IoT Enterprise version (or newer) is required to support Advantech’s DeviceOn/iService for ADLoG DLT-V72: Part number: Description: 20708WX6ES0039 Win10 IoT Ent 2016 x64 APAC V72 v1.07 20708WX6ES0040 Win10 IoT Ent 2016 x64 US_EU V72 v1.07 20708WX9ES0032 Win10 IoT Ent 2019 x64 US_EU V72 v1.03 20708WX9ES0033...
  • Page 90 General Device Configuration When the BIOS version is not the correct one to support DeviceOn/iService, but the correct Win10 image is already installed, the Windows Device Manager will show an exclamation mark in the Device Manager at driver \System Devices\SUSI4 driver. Fig.
  • Page 91 WLAN Configuration 10. WLAN Configuration DLT-V72 Series User Manual V2.76 91 / 189...
  • Page 92 WLAN Configuration 10.1. Safety notes CAUTION Danger of radiation. DLT-V72 devices with radio technology emit high frequency energy (abbreviation: HF). To protect persons and domestic animals against HF radiation: 1. Observe section 2.4 HF Radiation in the Safety Chapter of this manual.
  • Page 93 WLAN Configuration Antenna solutions for use in Germany The Advantech antenna solutions are based on the prevailing IEEE 802.11 standard. This standard allows radio data transfer at rates from 1 Mbps to 54 Mbps (867 Mbit/s if using IEEE 802.11ac) using the 2.4 GHz and 5 GHz frequency band. Information on radio performance The consistency of the radio performance is dependent on the following factors: Radio card (set transmission power)
  • Page 94 WLAN Configuration 10.3. OS-specific configuration Observe the following manuals to find more details about OS-specific configuration: WLAN configuration description DLT-V72 with MS-Windows In the following manual sections DLT-V72 with Linux In manual “Advantech Linux“; please contact our Technical Customer Support if required. DLT-V72 with Android In manual “Android Nougat 1.xx for DLT-V72”...
  • Page 95 WLAN Configuration 10.4. Customer-specific WLAN profiles To create a customer-specific profile: 1. Use the configuration program that is already factory-installed on the DLT- V72. (Sparklan or IGX) 2. Observe the description of the configuration programs in the following sections. Radio card Configuration program Qualcomm Atheros Advantech WLAN Client...
  • Page 96 WLAN Configuration 10.6. Sparklan WLAN driver 10.6.1. Area of application This chapter describes the Sparklan WLAN driver under the following OS: Win7Pro  WES7  Win10IoTEnt  Required: DLT-V72 with radio card SPARKLAN WPEQ-261ACN (BT) MiniPCIe 10.6.2. Driver download The currently available Sparklan WLAN driver can be downloaded from the following Link.
  • Page 97 WLAN Configuration 10.6.3. After image reinstallation: Driver installation If the image has been reinstalled, the DLT-V72 must be set up again using the Sparklan WLAN driver. Two drivers are available: Driver for Win7Pro and WES7  Driver for Win10IoTEnt  10.6.4.
  • Page 98 WLAN Configuration Fig. 10.3: Setup.exe Choose Setup Language (Sparklan WLAN) 3. Select the language and continue with Next. Fig. 10.4: Sparklan WLAN driver installation Welcome dialog DLT-V72 Series User Manual V2.76 98 / 189...
  • Page 99 WLAN Configuration 4. Continue the installation with Next. Fig. 10.5: Sparklan WLAN driver installation starts 5. Continue the installation of the required files with Install. Fig. 10.6: Sparklan WLAN driver installation Exit with Finish 6. Exit the driver installation with Finish. The WLAN configuration is then carried out using the WZC tool under Windows.
  • Page 100 WLAN Configuration 10.6.5. Sparklan “Roaming” Setting For an optimal “roaming” result, we recommend using the Windows device manager to manually adjust the following setting after the standard WLAN driver installation. 1. Open Windows Device Manager. Fig. 10.7: Device Manager network adapter Properties (Qualcomm) 2.
  • Page 101 WLAN Configuration Fig. 10.8: Advanced – Roaming aggressiveness Property 3. Under the Advanced tab, set the Roaming aggressiveness property to value 5. Highest. 4. Confirm the setting made with OK. DLT-V72 Series User Manual V2.76 101 / 189...
  • Page 102 WLAN Configuration 10.7. Sparklan BT driver In addition to the WLAN driver, Sparklan provides a suitable Bluetooth® driver separately. NOTICE For full Bluetooth 5.0 SW support you need at least Sparklan driver version v1159 (or higher) in combination with Windows 10 Enterprise (2016, 2019, and 2021).
  • Page 103 WLAN Configuration 10.7.3. After image reinstallation: Driver installation If the image has been reinstalled, the DLT-V72 must be set up again using the Sparklan BT driver. One driver is available: Driver for Win10IoTEnt  10.7.4. “Standard” Driver installation Win10IoTEnt 1. Run Setup.exe to start the installation. Fig.
  • Page 104 WLAN Configuration Fig. 10.10: Sparklan WLAN driver installation Welcome dialog 2. Continue the installation with Next. Fig. 10.11: Sparklan BT driver installation destination folder 3. Continue the installation with Next. DLT-V72 Series User Manual V2.76 104 / 189...
  • Page 105 WLAN Configuration Fig. 10.12: Sparklan BT driver installation starts 4. Continue the installation of the required files with Install. Fig. 10.13: Sparklan BT driver installation Exit with Finish 5. Exit the driver installation with Finish. DLT-V72 Series User Manual V2.76 105 / 189...
  • Page 106 WLAN Configuration 6. It is recommended to restart the system immediately after the installation. Fig. 10.14: Sparklan BT driver installation perform system restart 7. Continue with Yes. The system restart is being performed. DLT-V72 Series User Manual V2.76 106 / 189...
  • Page 107 WLAN Configuration 10.8. Advantech WLAN Client Manager (IGX Tool) 10.8.1. Area of application This chapter describes the Advantech WLAN Client Manager version 1.02 under the following OS: Win7Pro  WES7  Win10IoTEnt  Required: DLT-V72 with radio card SPARKLAN WPEQ-261ACN (BT) MiniPCIe 10.8.2.
  • Page 108 WLAN Configuration 10.8.4. Driver download The currently available IGX drivers can be downloaded from the following Link. Link to available Drivers: https://cutt.ly/AEU_SIOT_FAE_CUSTOMER ->Additional-Driver-Software ->WLAN_driver ->X86_(DLOG_MPC_MTC_IPC_series - >Sparklan_261_ACN_BT ->IGX Once the download has completed, the contents of the ".zip" directory on the desktop must be unzipped.
  • Page 109 WLAN Configuration 10.8.7. “Silent” Driver uninstaller WES7 / Win7Pro / Win10IoTEnt 1. Open the corresponding installation directory depending on the operating system. 2. Run “Silent_UnInstall.bat” (Run as administrator) to start the uninstall process. 3. Confirm the Windows UAC (User-Account-Control) message. The uninstall process will be done automatically in background and takes around 2 minutes.
  • Page 110 WLAN Configuration 10.8.8. Start WLAN Client Manager, Login 1. Launch the WLAN Client Manager by double-clicking the Launch WCU icon: Fig. 10.15: WCU icon on the desktop You must login as "WCU_Administrator" first. DLT-V72 Series User Manual V2.76 110 / 189...
  • Page 111 WLAN Configuration 2. To do this, click Admin Login. Fig. 10.16: WCU main window, Admin Login 3. Then open the login window. 4. Enter the passport, which by default is "gold". 5. Confirm the input with the Login button. DLT-V72 Series User Manual V2.76 111 / 189...
  • Page 112 WLAN Configuration Fig. 10.17: WCU-Administrator login window After successful Admin-login, speed buttons for managing profiles are available: Fig. 10.18: Speed buttons for managing profiles DLT-V72 Series User Manual V2.76 112 / 189...
  • Page 113 WLAN Configuration 10.8.9. WLAN Client Manager Functions License The License function lists the current status of the enabled options: Fig. 10.19: Check License NOTE The correct implementation of the WLAN driver requires a valid license in combination with the DLT-V72 terminal. DLT-V72 Series User Manual V2.76 113 / 189...
  • Page 114 WLAN Configuration If, as shown in the image, the license information is missing: Contact Technical Customer Support to solve the problem. Fig. 10.20: Info display via existing license 10.8.10. Browse nearby wireless networks Set up the WLAN connection To set up a WLAN connection, you can show all available networks using the Browse nearby wireless networks function.
  • Page 115 WLAN Configuration Define security settings The security settings must be selected (depending on the network). These settings can be made in the Advanced Security Settings section: Fig. 10.22: Advanced Security Settings dialog To be able to connect with the network automatically, set the checkmark to connect automatically when the network is in range: Fig.
  • Page 116 WLAN Configuration Available parameters in the Connection and Security sections: Connect automatically when Enable this parameter to set up an automatic the network is in range connection to the network. Connect to a more preferred In the event of multiple profiles being present, this network if available option can be used to select the preferred profile.
  • Page 117 WLAN Configuration This results in the following selection options and settings: Fig. 10.24: Security settings - network authentication methods The network authentication methods shown, as well as their designations, differ depending on the operating system used. For the remaining settings as in the case shown above (Cisco: Leap), the required additional parameters are carried out using the two buttons Settings and Advanced settings.
  • Page 118 WLAN Configuration Fig. 10.26: Security settings – LEAP properties 2. Lastly, the network key must be entered in the following example (WPA2- Personal) (Network Security Key). 3. Confirm the settings with OK. Fig. 10.27: Wireless Network properties dialog DLT-V72 Series User Manual V2.76 118 / 189...
  • Page 119 WLAN Configuration Fig. 10.28: Create new profile dialog 4. Confirm the new profile with the OK button. DLT-V72 Series User Manual V2.76 119 / 189...
  • Page 120 WLAN Configuration Establish network connection After the WLAN profile settings have been made, a connection to the network is established automatically. The connection setup with the selected network is successful only if the "green" connection line is displayed in the WCU main window. Fig.
  • Page 121 WLAN Configuration 10.8.11. Roam Management General tab After clicking the General dialog, the following information is displayed on the screen: Fig. 10.30: General dialog in the Roam Management menu Info section Info Meaning of the display Client Status Current connection status: Connected / Disconnected Network Name SSID SSID of the currently connected access points Network Type...
  • Page 122 WLAN Configuration Security section Authentication The authentication process used, e.g. WPA2-PSK (Pre-Shared- Key) Encryption Display of the corresponding encryption process, e.g. (AES-CCMP, TKIP) Roaming tab The Roaming dialog is used to define the following parameters: Fig. 10.31: Roaming dialog in the Roam Management menu DLT-V72 Series User Manual V2.76 122 / 189...
  • Page 123 WLAN Configuration Roam section Signal Level The client decides to roam only when the current signal strength is weaker than the setting value and the new visible access point has higher signal (dBm): strength (defined in Roam RSSI Difference).Possible values: -55 dBm to - 80 dBm Default value: -70 dBm (adjustable in 5 dBm increments) Minimum...
  • Page 124 WLAN Configuration Background Scan section Signal Level The client begins the background scan only when the current signal (dBm) strength is weaker than the setting value. Possible values: -55 dBm to -80 dBm Default value: -65 dBm Probe request This setting is used to define how frequently the probes are to be sent interval when the client is in the "Connected"...
  • Page 125 WLAN Configuration Channel List Select all This option can be used for simultaneous pre-selection of all 2.4 GHZ 2.4Ghz channels 1 to 13 supported by the WLAN driver. channels Modifications to individual channels can be carried out at any time by clicking the checkboxes for each channel.
  • Page 126 WLAN Configuration Radio Tab The Radio dialog is used to define the following parameters: Fig. 10.33: Radio dialog in the Roam Management menu Power Save The Power Save Level is set. The levels OFF and Auto-PSM are available. Mode Selection The client’s band is specified.
  • Page 127 WLAN Configuration Adapter Tab After clicking the Adapter dialog, the following information is displayed on the screen: Fig. 10.34: Adapter Tab in Roam Management menu DLT-V72 Series User Manual V2.76 127 / 189...
  • Page 128 WLAN Configuration 10.8.12. Import / Export feature This feature in program version 1.01 (or higher) allows export and import of configured WLAN profiles and settings. The “OutputFile.txt” contains the following saved information: Roam parameters: Roam RSSI difference, Signal Level, Min Connection Time ...
  • Page 129 WLAN Configuration The following dialog will be shown: Fig. 10.36: WLAN Client Manager - Import/Export dialog Choose Export Profiles to create an “OutputFile.txt” using standard windows directory dialog for free selectable file location: Fig. 10.37: WLAN Client Manager - Export Profiles in OutputFile.txt DLT-V72 Series User Manual V2.76 129 / 189...
  • Page 130 WLAN Configuration With button Save “OutputFile.txt” will be generated followed by message: Fig. 10.38: WLAN Client Manager - Info box Profiles exported Import process requires afterwards to select an existing “OutputFile.txt”: Fig. 10.39: WLAN Client Manager - Select an existing “OutputFile.txt” By clicking Open button the file will be imported (existing setup will be overwritten during this process!) Fig.
  • Page 131 WLAN Configuration “Auto” Import wireless settings file as part of “silent” driver installation This option is useful for multiple installation scenarios to skip the graphical dialog that requires admin login to import the wireless setting automatically as part of “silent” driver installation process.
  • Page 132 WLAN Configuration After the required reboot the wireless connection will be set up automatically based on imported settings: Fig. 10.42: Successful „Auto” Import of a WLAN settings file DLT-V72 Series User Manual V2.76 132 / 189...
  • Page 133 WWAN Configuration 11. WWAN Configuration DLT-V72 Series User Manual V2.76 133 / 189...
  • Page 134 WWAN Configuration 11.1. Safety notes CAUTION Danger of radiation. DLT-V72 devices with radio technology emit high frequency energy (abbreviation: HF). To protect persons and domestic animals against HF radiation: 1. Observe section 2.4 HF Radiation in the Safety Chapter of this manual.
  • Page 135 WWAN Configuration 11.2. Preparation work at the factory (delivery status) The following preparations have already been carried out at the factory for the optional WWAN functionality of the DLT-V72: The WWAN radio card and the corresponding drivers are installed.  GNSS is enabled at the factory ...
  • Page 136 WWAN Configuration 11.4. Configuration of Radio card QUECTEL EC25 The following information is valid for the radio card QUECTEL EC25. Its precise designation is: USA: QUECTEL EC25A or EC25V  Europe: QUECTEL EC25E  The WWAN configuration is identical for both radio cards. For this reason, the abbreviation QUECTEL EC25 is used.
  • Page 137 WWAN Configuration 4. Click Dial-up. Fig. 11.3: QUECTEL EC25 - Connect to the Internet - Dial-up 5. Specify as a telephone number, e.g. *99***1#. 6. Enter a connection name, e.g. Vodafone test connection. Username and password are not required in the example. (Provider-dependent) Fig.
  • Page 138 WWAN Configuration 8. Do not enter a user name or password. 9. Click Dial. The test connection is established. Fig. 11.6: QUECTEL EC25 - Dial Vodafone test connection In the Network and activation center of the device, the status of the test connection can be tested: 10.
  • Page 139 WWAN Configuration 11.4.2. Trouble Shooting Test virtual COM ports In the device manager it is possible to test that the virtual COM ports are correctly set. If they are not correctly set, they must be modified as appropriate. The virtual COM ports must be set up as shown in the figure: Fig.
  • Page 140 WWAN Configuration Test communication between DLT-V72 and WWAN Radio card The open source software Tera Term, for example, can be used to test that the DLT- V72 can communicate with the Radio card. This software can be downloaded from the following URL, for example (website available at time of writing this operating manual, dated May 2019): https://www.heise.de/download/product/tera-term-51776 Perform the following steps:...
  • Page 141 Mechanical Installation 12. Mechanical Installation DLT-V72 Series User Manual V2.76 141 / 189...
  • Page 142 Mechanical Installation 12.1. Safety notes WARNING Risk of personal injury and property damage due to improper mechanical installation. These mounting instruction are directed to skilled personnel. Only qualified skilled personnel may perform the mechanical installation work on the DLT-V72. 1. Observe manual section 2.5 Information on safe mounting. NOTICE Prevent system malfunction and property damage The front display of the DLT-V72 is protected during transport by a...
  • Page 143 Mechanical Installation 12.2.1. Mounting the DLT-V72 at the deployment location WARNING Risk of injury and damage due to improper deployment location. 1. Observe the intended use of the DLT-V72, e.g. not in potentially explosive areas, not in life-supporting facilities. 2. Ensure that the deployment location of the DLT-V72 complies with the permissible environmental conditions.
  • Page 144 Mechanical Installation 12.2.2. Electrically isolated DLT-V72 mounting Due to a variety of technical properties of forklifts and forklift trucks, it can be necessary to electrically isolate DLT-V72 from the chassis of the vehicle to prevent malfunctions. The necessity of this must be studied on a case-by-case basis, however, it is recommended for vehicles with potential-free chassis.
  • Page 145 Mechanical Installation 5. If you want to connect devices fed by other power sources to the DLT-V72, such as certain Wedges, printers and so on, be sure to power up the peripheral devices at the same time or after the vehicle-mount. Otherwise, you may encounter start-up problems, malfunctions or even irreparable damage to the device.
  • Page 146 Mechanical Installation 12.2.4. VESA mounting hole pattern The rear side of the DLT-V72 has a VESA-compatible mounting hole pattern with 75 x 75 mm for a RAM Mount bracket or swivel mounting. Screw-in depth VESA mounting hole pattern: M6 x 6 mm ...
  • Page 147 Mechanical Installation 12.2.5. Attach the mounting bracket The DLT-V72 housing has holes provided for attaching a mounting bracket. Fig. 12.2: Mounting bracket on the DLT-V72 4 x cylinder head screws DIN912 M6  Screw-in depth: M6 x 6 mm  Washers DIN 125 - A 6.4 ...
  • Page 148 Mechanical Installation 12.2.6. Attach accessories The housing of the DLT-V72 has holes provided for attaching an accessory. Example: Fig. 12.3: Scanner mounting attachment Screw-in depth: M6 x 6 mm  Suitable mounting material: Cylinder head screw DIN 912 M6  Washer ISO 8738 - A6-A2 ...
  • Page 149 Electrical Installation 13. Electrical Installation DLT-V72 Series User Manual V2.76 149 / 189...
  • Page 150 Electrical Installation 13.1. Safety notes 13.1.1. Disconnecting device and emergency-off WARNING Risk of personal injury and property damage due to improper electrical installation. These mounting instruction are directed to skilled personnel. Only qualified skilled personnel may perform the electrical installation work on the DLT-V72.
  • Page 151 Electrical Installation 13.1.2. Power cables and fuses WARNING Electric shock, fire due to incorrect cable routing or insufficient grounding. 1. Use only original Advantech power cables; these meet the specific requirements for low-temperature flexibility, UV resistance, oil resistance, etc. 2. Make sure that the power supply cables are run without kinks and are protected (securely protected against crushing and abrading).
  • Page 152 Electrical Installation 13.1.3. Observe the potential ratios On the DLT-V72, the logic ground and the shield ground are firmly connected to each other. Logic ground is the ground (GND) used to supply the internal parts and components such as the display or CPU. All cable shields and the housing are connected to shield ground.
  • Page 153 Electrical Installation 13.2. Preparations 1. Lay out ready all cables that are to be connected to the DLT-V72. 2. Select the appropriate slots on the connector panel of the DLT-V72. 3. Test in which order the cables best fit in the cable compartment. Overview of connectors located on the connector panel under the cable cover: Fig.
  • Page 154 Electrical Installation Cable cover Including 2 x special screws M4x12, neck 8 mm, thread length 4 mm, (latching in the holes of the cable cover) Fig. 13.3: DLT-V72 cable cover with screws Power supply cable DC power supply cable with Phoenix contact connector Tools Allen wrench, size 3 ...
  • Page 155 Electrical Installation 13.3. Procedure 13.3.1. Inserting the rubber seal in the cable compartment 1. Insert the rubber seal in the cable compartment. 2. Place the rubber seal in the frame of the cable compartment (see figure). 3. Press the plugs of the rubber seal into the holes of the frame. Fig.
  • Page 156 Electrical Installation 13.3.2. Ensure a proper electrical connection 1. Remove the nut from the ground bolt. 2. The toothed washer remains on the ground bolt. 3. Plug the ring tongue on the power supply cable onto the ground bolt; the flat side of the ring tongue points towards the DLT-V72 connector panel.
  • Page 157 Electrical Installation 13.3.4. Secure the power supply cable to the strain relief rail Mounting screws 1. Open the round cable passage in the rubber seal. 2. Insert the power supply cable. 3. Place one cable clip on the power supply cable.
  • Page 158 Electrical Installation 13.3.5. Connecting the USB, Ethernet and COM cables Procedure as described for the power supply cable: 1. Connect the cable. 2. Open the round cable passage in the rubber seal. 3. Insert the cable. 4. Insert both components into the cable passage. 5.
  • Page 159 Electrical Installation 13.3.6. Close off unused cable openings Close off all unused cable openings of the rubber seal using the accompanying blind plugs so that they are sealed. 13.3.7. Attach the cable cover 1. Place the cable cover in the DLT-V72 housing slot. 2.
  • Page 160 Electrical Installation 13.4. Pressure compensation element The DLT-V72 cable cover has a pressure compensation element. NOTICE Prevent system malfunction and property damage Do not modify or remove the pressure compensation element; doing so would make the device leak and the IP protection would no longer be ensured.
  • Page 161 Optional Equipment 14. Optional Equipment DLT-V72 Series User Manual V2.76 161 / 189...
  • Page 162 Optional Equipment 14.1. Integrated UPS (optional) The DLT-V72 is optionally available with an integrated UPS. The battery pack of the UPS is located in the battery pocket of the device. Fig. 14.1: Battery pocket with UPS DLT-V72 WARNING Personal injury due to short-circuit, fire, chemical burns, toxic substances DLT-V72 devices with integrated UPS contain battery packs.
  • Page 163 Optional Equipment 14.1.2. Charging the battery pack Connect the properly installed DLT-V72 to the main supply voltage. WARNING Electric shock when charging the battery pack DLT-V72 devices with integrated UPS contain battery packs. These can ignite if handled or stored improperly (risk of fire), cause chemical burns or release toxic substances.
  • Page 164 Optional Equipment 14.1.3. Replacing the battery pack The battery pack of the DLT-V72 can be charged approx. 600 times. It may only be replaced by an original battery pack from Advantech. WARNING Personal injury due to short-circuit, fire, chemical burns, toxic substances.
  • Page 165 Optional Equipment 14.2. Screen defroster (optional) Some DLT-V72 models are optionally available with a screen defroster (containing “D” in the model name, e.g. “DLT-V7210 D”. Functional description As soon as the internal temperature of the DLT-V72 device falls below 5°C, the screen defroster is automatically activated and heats the front of the device.
  • Page 166 Optional Equipment 14.3. Screen blanking (optional) An optional Screen Blanking Solution is available for the DLT-V72 for use in vehicles. This solution blanks the DLT-V72 screen automatically as soon as the vehicle starts driving. NOTE The “DLT-SA6100 Screen Blanking Solution Manual” is available at our websites.
  • Page 167 Optional Equipment 14.5. Keyboards and keyboard mounts (optional) Any USB keyboard can be connected to the DLT-V72. Advantech offers the following keyboards: SMALL keyboard 1. Mountable 2. Protection class IP65 3. Keyboard layouts: German, English, French Fig. 14.3: SMALL keyboard 24-key keypad Mountable ...
  • Page 168 Optional Equipment 14.6. Scanner and scanner bracket (optional) You can connect scanners to either the USB interface or the serial interface. If connected to COM1, the scanner can be powered through the interface with a voltage of 5 V. Use only scanners that have been approved by Advantech. Optional scanner brackets are available for the DLT-V72.
  • Page 169 Optional Equipment 14.7. Touch stylus (optional) Advantech offers some touch stylus pens (with associated mountings) for resistive and PCT touchscreens. Use only touch stylus that have been approved by Advantech. Touch stylus with mounting Touch stylus with mounting for resistive touchscreen: for PCT touchscreen: Fig.
  • Page 170 Optional Equipment 14.8. Protective film for touchscreen (optional) An optional protective film is available for DLT-V72 touchscreens. This film protects the touchscreen during extreme use. NOTICE Prevent system malfunction and property damage Do not attach the protective film to damaged or worn out touchscreens.
  • Page 171 Repairs, Modifications 15. Repairs, Modifications DLT-V72 Series User Manual V2.76 171 / 189...
  • Page 172 Repairs, Modifications 15.1. Authorized Advantech Service Centers Only authorized Advantech Service Centers may perform the following: Open the device (front unit and base unit)  Repairs  Modifications  Replace integrated modules, e.g. radio cards  The device operator may perform the following (only qualified skilled personnel): Opening/closing the antenna cap (e.g.
  • Page 173 Maintenance 16. Maintenance DLT-V72 Series User Manual V2.76 173 / 189...
  • Page 174 Maintenance 16.1. Regular maintenance work 16.1.1. General To avoid damage to the DLT-V72 and to ensure safe functioning: Depending on the load and environmental conditions, check at least once per month, and more often if necessary, that all connected cables are secured and that the cable cover is tightly sealed (important for IP protection against dust, etc.).
  • Page 175 Maintenance 16.2. Replacing the integrated keyboard If necessary, the integrated keyboard of the DLT-V7210 K and DLT-V7210 KD can be removed and replaced by a new keyboard (only by skilled personnel). WARNING Hazardous voltage, electric shock from contact with live parts. To prevent an electric shock: 1.
  • Page 176 Maintenance 16.2.2. Attach the integrated keyboard (example) Reuse the black keyboard grid. New, replacement parts: Silicon keyboard mat  5 x screws ISO14580-m3x8 A2  Fig. 16.2: Integrated keyboard: Keyboard components Procedure 1. Place the silicon keyboard mat on the circuit board. Fig.
  • Page 177 Maintenance 2. Carefully press the 3 nubs on the back of the silicone keypad into the openings provided on the circuit board. Fig. 16.4: Integrated keyboard: Silicone keypad 3. Place on the keyboard grid at a 45° angle, see Fig. 16.5. Fig.
  • Page 178 Maintenance 16.3. Replacing the battery pack See manual section 14.1 Integrated UPS (optional) . 16.4. Replacing the touchscreen protective film NOTICE Prevent system malfunction and property damage Do not attach the protective film to damaged or worn out touchscreens. Air bubbles can get trapped and cause malfunctions. The ordered optional protective film is normally attached to the DLT-V72 touchscreen at the factory.
  • Page 179 Troubleshooting 17. Troubleshooting DLT-V72 Series User Manual V2.76 179 / 189...
  • Page 180 Troubleshooting Error Possible cause(s) Remedy Battery pack run time is The device may possibly Check the temperature significantly shorter than not be in the temperature specifications for the device specified. range, which is necessary and surroundings. for charging the battery pack.
  • Page 181 Troubleshooting This resets the sensitivity of the touchscreen to an operating system default setting, which can result in poorer detection of taps on the screen. You can use Reset to reset the software recalibration. Operating system does External boot media lock Remove all external storage not start Operating system...
  • Page 182 Guidelines and Certificates 18. Guidelines and Certificates DLT-V72 Series User Manual V2.76 182 / 189...
  • Page 183 Guidelines and Certificates 18.1. USA/CANADA: FCC Part 15 Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 184 Guidelines and Certificates 18.2. ICES Kanada Deutsch [German]: DLT-V72 Industrie-PCs sind digitale Geräte der Klasse A und entsprechen der Kanadischen ICES-003 Norm. English: This Class A digital apparatus complies with Canadian ICES- 003. Français [French]: Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
  • Page 185 Return shipment form 19. Return shipment form Return shipment form (please fill in once per return shipment): Company Street Zip code, town Contact Phone number /E-Mail Type(s) of unit(s) returned: Serial number(s) of the unit(s) returned: [ ] The units have not been returned, as they are currently being used. However, the following parts are missing: [ ] Unit was already damaged on delivery (please enclose a copy of the delivery note) [ ] Delivery was incomplete Missing parts:...
  • Page 186 List of figures 20. List of figures DLT-V72 Series User Manual V2.76 186 / 189...
  • Page 187 List of figures Fig. 2.1: Battery pocket with UPS DLT-V72 ..............18 Fig. 2.2: Recycling information icons................24 Fig. 5.1: Dimensions DLT-V7210 P, R, D (in mm) ............36 Fig. 5.2: Dimensions DLT-V7212 P, R, D (in mm) ............36 Fig.
  • Page 188 List of figures Fig. 10.14: Sparklan BT driver installation perform system restart ......106 Fig. 10.15: WCU icon on the desktop ................ 110 Fig. 10.16: WCU main window, Admin Login ............111 Fig. 10.17: WCU-Administrator login window ............112 Fig. 10.18: Speed buttons for managing profiles ............112 Fig.
  • Page 189 Fig. 14.2: Inserting the battery pack in the battery pocket ......... 164 Fig. 14.3: SMALL keyboard ..................167 Fig. 14.4: 24-key keypad ................... 167 Fig. 14.5: Keyboard mounting examples ..............167 Fig. 14.6: Example scanner bracket ................168 Fig. 14.7: Examples touch stylus ................169 Fig.

This manual is also suitable for:

Dlt-v7210kDlt-v72 seriesDlt-v7210pDlt-v7210rDlt-v7210dDlt-v7212p ... Show all
