Advantech-DLoG DLT-V72 Series Operating Instructions Manual
Hide thumbs
Also See for DLT-V72 Series:
- Manual (94 pages) ,
- Mounting instructions (7 pages) ,
- User manual (189 pages)
Table of Contents
Advertisement
Advertisement
Chapters
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Advantech-DLoG DLT-V72 Series
Summary of Contents for Advantech-DLoG DLT-V72 Series
- Page 1 DLT-V72 Industrial Computer Operating Instructions V2.50 (EN) Preliminary...
- Page 2 IMPORTANT: For safe and proper use, follow these Operating Instructions. Keep them for future reference. Operating Instructions completed on Feb 22, 2019. Preliminary Version 2.50 Copyright This document and the software and hardware included with this product are copyrighted 2019 by Advantech Co Ltd All rights are reserved.
-
Page 3: Table Of Contents
7.2. Operating the touchscreen ............. 37 7.3. Operation elements ..............39 Table of contents 7.3.1. Rear side: DLT-V72 all device models ........39 7.3.2. Front side: DLT-V7210 P, R, D and DLT-V7212 P, R, D ..40 7.3.3. Front side: DLT-V7210 K, KD ..........41 7.3.4. - Page 4 11.3.3. Attach the Advantech accessories ........100 19. GUIDELINES AND CERTIFICATES ..........135 19.1. Simplified EU declaration of conformity ........135 12. ELECTRICAL INSTALLATION, CABLE CONNECTION, 19.2. Low-voltage guidelines ............135 CABLE COVER ................... 101 19.3. EMC guidelines ............... 135 12.1.
-
Page 5: Introduction
Introduction Introduction 1.1. Information about the DLT-V72 manuals Contents For target Availability group Safety instructions Important information Skilled about protecting personnel personnel and property Printed, enclosed with the Quick Start and First steps in Skilled device Installation Guide commissioning, personnel mechanical and electrical installation and mounting Operating... -
Page 6: One Manual For All Device Models
Introduction 1.1.2. ONE manual for all device models These operating instructions apply to all models of the DLT-V72 series. − DLT-V7210 P (PCT) − DLT-V7210 R (Resistive Touch) − DLT-V7210 D (Defroster) − DLT-V7212 P (PCT) − DLT-V7212 R (Resistive Touch) −... -
Page 7: Warnings And Notes In The Operating Instructions
Introduction 1.1.3. Warnings and notes in the operating instructions Personal injury Information with regard to personal injury is shown as follows (signal words for indicating risk level): DANGER / WARNING / CAUTION DANGER means that death or severe bodily injury will occur if this information is not observed. WARNING means that death or severe bodily injury can occur if this information is not observed. -
Page 8: Technical Customer Support
Technical customer support Technical customer support Contact your distributor, sales representative, or an Advantech Service Center for technical support. Please have the following information ready: − Product name − Serial number − Description of your peripheral attachments − Description of your software (operating system, application software, etc.) −... -
Page 9: Functional Description
Functional description Functional description 3.1. Intended use The DLT-V72 Industrial Computers are data communication terminals for use in commercial environments (e.g. logistics, warehousing, manufacturing). Any other or additional use beyond this shall be deemed an improper use. The user/operator of the DLT-V72 is solely responsible for any resulting damage. -
Page 10: Mount, Operate And Service The Device Correctly
Functional description 3.2. Mount, operate and service the device correctly DLT-V72 Industrial Computers were designed and built according to modern technology and accepted safety regulations. However, the operation of the DLT-V72 can endanger personnel or third parties and cause damage to the device and other material assets when, for example, the device is installed incorrectly or configured improperly. -
Page 11: Unpacking, Transporting, Storing
Unpacking, transporting, storing Unpacking, transporting, storing 4.1. Unpacking Open the packaging carefully to prevent damaging the device inside. Save the packaging material (for possible forwarding transports or returns of the DLT-V72). Check the shipment for completeness and any possible damage. ... -
Page 12: Protecting Touchscreens During Storage
Unpacking, transporting, storing WARNING Personal injury due to short-circuit, fire, chemical burns, toxic substances. Devices with integrated UPS (optional) contain lithium-ion battery packs. These can ignite if handled or stored improperly (risk of fire), cause chemical burns or release toxic substances. Use care when handling lithium-ion battery packs. -
Page 13: Technical Data - Device
12.1" XGA color TFT with 1024 x 768 resolution and 600 cd/m² brightness The LCD display of the DLT-V72 series fulfills the highest quality standards and was inspected for pixel defects. However, due to technological reasons pixel defects can occur. - Page 14 Technical data – Device ATTENTION: Physical damage Protect the display of the DLT-V72 from the memory effect. The display of the DLT-V72 has to be protected from the burning in of a motionless image. An image that has remained motionless for too long can cause irreversible damage to the display. Recommendation: Use a screensaver.
-
Page 15: Environmental Conditions
Technical data – Device Internal speaker, sound The DLT-V72 is equipped with an internal speaker as standard (2 W). The system messages from the industrial PC are output via this speaker. The internal speaker is configured in the audio settings for the operating system in question. 5.2. -
Page 16: Device Dimensions
Technical data – Device 5.3. Device dimensions 5.3.1. DLT-V7210 P, R, D Dimensions without add-ons (in mm) Fig. 5.1: Dimensions DLT-V7210 P, R, D 16 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... -
Page 17: Dlt-V7212 P, R, D
Technical data – Device 5.3.2. DLT-V7212 P, R, D Dimensions without add-ons (in mm) Fig. 5.2: Dimensions DLT-V7212 P, R, D DLT-V72 Operating Instructions V2.50 Preliminary 17 / 140... -
Page 18: Dlt-V7210 K, Kd
Technical data – Device 5.3.3. DLT-V7210 K, KD Dimensions without add-ons (in mm) Fig. 5.3: Dimensions DLT-V7210 K, KD 18 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... -
Page 19: Dlt-V7212 P
Technical data – Device 5.3.4. DLT-V7212 P+ Dimensions without add-ons (in mm) Fig. 5.4: Dimensions DLT-V7212 P+ DLT-V72 Operating Instructions V2.50 Preliminary 19 / 140... -
Page 20: Position Of Vesa Drill Holes
Technical data – Device 5.4. Position of VESA drill holes The back of the DLT-V72 has a VESA-compatible 75 x 75 mm mounting hole pattern. It is used to attach VESA-compatible mountings to mount the DLT-V72 at the deployment location. ATTENTION: Physical damage Only use mountings and mounting materials that have been tested and approved for the respective DLT-V72. -
Page 21: Dlt-V7212 P, R, D
Technical data – Device 5.4.2. DLT-V7212 P, R, D Dimensions without add-ons (in mm): Depth of thread: M6 x 6mm. Fig. 5.6: Position VESA drill holes DLT-V7212 P, R, D DLT-V72 Operating Instructions V2.50 Preliminary 21 / 140... -
Page 22: Dlt-V7210 K, Kd
Technical data – Device 5.4.3. DLT-V7210 K, KD Dimensions without add-ons (in mm): Depth of thread: M6 x 6mm. Fig. 5.7: Position VESA drill holes DLT-V7210 K, KD 22 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... -
Page 23: Dlt-V7212 P
Technical data – Device 5.4.4. DLT-V7212 P+ Dimensions without add-ons (in mm): Depth of thread: M6 x 6mm. Fig. 5.8: Position VESA drill holes DLT-V7212 P+ DLT-V72 Operating Instructions V2.50 Preliminary 23 / 140... -
Page 24: Technical Data - Radio Modules (All Optional)
Technical data – Radio modules (all optional) Technical data – Radio modules (all optional) NOTICE: Property damage DLT-V72 may only be operated with the radio modules described in the following section. 6.1. Identification of the equipment variants The DLT-V72 offers numerous radio equipment variants for Wi-Fi, WWAN, GNSS and Bluetooth. To identify the variant installed in your device, proceed as follows: Read off the FCCID on the device name plate/label and compare with the technical data on the −... -
Page 25: Available Radio Cards For Wi-Fi
Technical data – Radio modules (all optional) 6.2.1. Available radio cards for Wi-Fi SPARKLAN WPEQ-261ACN(BT) Card type Wi-Fi PCIe Half-Mini Card Technology Wi-Fi IEEE802.11 a/b/g/n/ac and Bluetooth (both supported via a single antenna) FCCID RYK-261ACNBT IC ID 6158A-261ACBT Band 1: WLAN 2.4 GHz Frequency range 2400 to 2483.5 MHz Frequency band ETSI Europe... -
Page 26: Available Radio Cards For Wwan
Technical data – Radio modules (all optional) 6.2.2. Available Radio cards for WWAN USA: QUECTEL EC25A Europe: QUECTEL EC25E Card type WWAN PCIe Full-Mini Card Technology WWAN 2G, 3G, 4G cellular bands and GNSS FCCID FCC ID: XMR201605EC25A (valid for the EC25-A variant) Maximum transmitting power Class 3 (23dBm±2dB) for LTE FDD Class 3 (23dBm±2dB) for LTE TDD... -
Page 27: Antennas (All Optional)
Technical data – Radio modules (all optional) 6.3. Antennas (all optional) 6.3.1. Wi-Fi antenna IEEE 802.11 a/b/g/n/ac Detail view: Antenna module (visible with open antenna) Technical data Fig. 6.1: Wi-Fi antenna IEEE 802.11 a/b/g/n and antenna module Application Wi-Fi a/b/g/n/ac Dual Band with MRC Bluetooth (integrated via Radio card) Wi-Fi frequency range Band 1: 2400 to 2483.5 MHz... -
Page 28: Wi-Fi, Wwan, Lte 4G Antenna (Multiband)
Technical data – Radio modules (all optional) 6.3.2. Wi-Fi, WWAN, LTE 4G antenna (Multiband) Detail view: Antenna module (visible with open antenna open) Fig. 6.2: Wi-Fi, WWAN, LTE 4G antenna (Multiband) Technical data Application Wi-Fi IEEE 802.11 ac/a/b/g/n Dual Band with MRC WWAN 4G Bluetooth 4.2+HS Wi-Fi frequency range... -
Page 29: External Wi-Fi Antenna Ieee 802.11 A/B/G/N
Technical data – Radio modules (all optional) (see section 6.2.1 Available radio cards)) Compatible WWAN card: USA: QUECTEL EC25A Europe: QUECTEL EC25E (see section 6.2.2 Available Radio cards) 6.3.3. External Wi-Fi antenna IEEE 802.11 a/b/g/n Fig. 6.5: External Wi-Fi antenna Technical data Application Wi-Fi IEEE 802.11 a/b/g/n Dual Band... -
Page 30: External Wwan Antenna 2G, 3G, 4G
Technical data – Radio modules (all optional) 6.3.4. External WWAN antenna 2G, 3G, 4G 2G, 3G, 4G Fig. 6.7: External WWAN antenna Technical data Application WWAN 2G, 3G, 4G cellular bands Mounting location For detached mounting, e.g. on the roof of the forklift Number of antennas Type Dipole antenna... -
Page 31: Bluetooth (Optional)
Technical data – Radio modules (all optional) 6.4. Bluetooth (optional) The DLT-V72 offers the following Bluetooth options: 6.4.1. Bluetooth integrated: Wi-Fi card SPARKLAN WPEQ-261ACN (BT) Requirement: Use of the Wi-Fi card SPARKLAN WPEQ-261ACN (BT) Technical data Type Bluetooth 4.2+HS Standards V4.2, V4.0 LE, V3.0+HS, V2.1+EDR Transmission rate 1 Mbps, 2 Mbps, up to 3 Mbps... -
Page 32: Gps Receiver External (Optional)
Technical data – Radio modules (all optional) 6.5. GPS receiver external (optional) With the optional GPS receiver the DLT-V72 can be used for GPS navigation. The GPS receiver has an integrated antenna for position data of the Global Positioning System (GPS) and communicates with the DLT-V72 via USB interface. -
Page 33: Operation
Operation Operation 7.1. Switching the DLT-V72 on/off The following factors determine how the DLT-V72 can be switched on and off: − Is the DLT-V72 mounted on a vehicle and connected with the ignition signal? − What are the automatic shutdown settings that were defined in the DLoG Config configuration program? 7.1.1. -
Page 34: Switch Off
Operation 7.1.2. Switch off Switch the DLT-V72 off as follows, depending on the configuration: Press the <Power> button of the activated DLT-V72. Or: Disconnect the supply voltage. NOTICE: Devices without integrated UPS will be hard-terminated (data loss possible). Devices with integrated UPS will switch automatically to UPS/battery power supply when the supply voltage is broken. - Page 35 Operation Operating the touchscreen All touchscreens can be operated with: Clean, dry fingers. − − Clean, dry, soft gloves. Resistive touchscreens with: − Suitable touch stylus (plastic or wood, rounded tip) PCT touchscreens with: Suitable touch stylus with capacitive (electrically conductive) tip. −...
-
Page 36: Operation Elements
Operation 7.3. Operation elements 7.3.1. Rear side: DLT-V72 all device models DLT-V72 Operating Instructions V2.50 Preliminary 39 / 140... -
Page 37: Front Side: Dlt-V7210 P, R, D And Dlt-V7212 P, R, D
Operation 7.3.2. Front side: DLT-V7210 P, R, D and DLT-V7212 P, R, D Background lightning of the display on / off. NOTE: The DLT-V7210K will continue to react to keyboard, mouse and touchscreen inputs even if the backlight is switched off. 40 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... -
Page 38: Front Side: Dlt-V7210 K, Kd
Operation 7.3.3. Front side: DLT-V7210 K, KD Background lightning of the display on / off. NOTE: The DLT-V7210K will continue to react to keyboard, mouse and touchscreen inputs even if the backlight is switched off. DLT-V72 Operating Instructions V2.50 Preliminary 41 / 140... -
Page 39: Front Side: Dlt-V7212 P
Operation 7.3.4. Front side: DLT-V7212 P+ 42 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... -
Page 40: Integrated Keyboard
Operation 7.3.5. Integrated keyboard The integrated keyboard of the DLT-V7210 K and KD models is available in three languages: German, English and French. Example English version (QWERTY) Description of specific keys Function <Shift> key Caps Lock: permanent switch to uppercase letters Activate the FN key on the left of the device: See the explanation there. -
Page 41: Operating States
Operation 7.4. Operating states Status of LEDs Supply voltage Temperature DLT-V72 status Initial state, idle time – waiting for a new ignition signal or for the <Power> key after switch-off; no voltage supply FLASHING Temperature sensor faulty FLASHING DLT-V72 is in standby mode (S3) Computer will only start if the temperature in the device is in the range between -30 and +59 °C again. -
Page 42: Software Keyboard (Optional)
Operation 7.5. Software keyboard (optional) The optional DLoG software keyboard brings the complete standard keyboard with function keys and numeric pad directly to your DLT-V72 screen – with easy touch operation. Any entries made, for example, letters and numbers, are passed to the currently active application program. -
Page 43: General Device Configuration
General device configuration General device configuration WARNING Risk of injury and damage due to improper configuration. These instructions are directed to skilled personnel. Only qualified skilled personnel (e.g. IT personnel with good knowledge of PCs, operating systems and wireless networks) may configure the DLT-V72. If the DLT-V72 is incorrectly configured, warranty for this device will be void. -
Page 44: Wes 7 And Win 7 Prof.: Usb Icon In The Taskbar
General device configuration Front-key assignment − Network settings − And depending on the equipment of the DLT-V72 also: − Battery pack charge settings (only on devices with optional UPS) − Screen defroster heating function (only on devices with optional screen defroster) −... -
Page 45: Android
General device configuration Restart Windows. Via Start -> Settings -> Update & Security, switch to the Windows Updates dialog. Click on Retry to search for updates. Click on Advanced Options. The Never check for updates setting is now set. Fig. -
Page 46: Automatic Shut Down
General device configuration 8.5. Automatic shut down 8.5.1. Functional description The DLT-V72 is equipped with an automatic shutdown module. If wired up accordingly, the DLT-V72 conveniently switches off together with the vehicle’s ignition. As disconnecting the power supply during operation can lead to data loss, the operating system needs to be shut down normally using the appropriate hardware and software installed on the system when the ignition is switched off. -
Page 47: Automatic Shutdown Configuration
General device configuration To ensure that important data is saved correctly, the application must respond appropriately to “WM_QUERYENDSESSION”, i.e. the backup data must be saved without user confirmation and within the preset time. 8.5.2. Automatic shutdown configuration Configure automatic shutdown behavior of DLT-V72 with MS Windows Configuring the automatic shutdown is described in the “DLoG Config Manual”. -
Page 48: Wi-Fi Configuration
Wi-Fi configuration Wi-Fi configuration 9.1. Safety notice CAUTION Danger of radiation emission. DLT-V72 devices with radio technology emit high frequency energy (abbreviation: HF). To protect persons against HF radiation: Mount the DLT-V72 so that persons and domestic animals maintain a minimum distance of 20 to 50 cm from the radio antennas. -
Page 49: Differences Between Ms Windows And Linux
Wi-Fi configuration Information on radio performance The consistency of the radio performance is dependent on the following factors: 1. Radio card (set transmission power) 2. Connecting cables 3. Antenna gain Help table for the correct setting: 9.2. Differences between MS Windows and Linux The radio configuration of the DLT-V72 with MS Windows operating system is described in the following manual sections. -
Page 50: Customer-Specific Settings
Wi-Fi configuration 9.4. Customer-specific settings To create a customer-specific profile: Use the configuration program that is already factory-installed on the DLT-V72. Observe the description of the configuration programs in the following sections. Radio card Operating Configuration program system Laird Connection Manager (LCM) Password: SUMMIT (upper case mandatory) SUMMIT/LAIRD... -
Page 51: Advantech Wi-Fi Client Manager (Igx Tool)
Wi-Fi configuration 9.6. Advantech Wi-Fi Client Manager (IGX Tool) 9.6.1. Area of application This chapter describes the Advantech Wi-Fi Client Manager program version 1.00 under the following operating systems: 6. Win7Pro 7. WinEmbStd7 8. Win8.1IndPro 9. Win10IoTEnt This chapter applies to DLT-V72 devices with the Radio card "SPARKLAN WPEQ-261ACN(BT) MiniPCIe". -
Page 52: Driver Installation Winembstd7
Wi-Fi configuration 9.6.4. Driver installation WinEmbStd7 If it is not known which operating system variant (32 or 64 bit) is installed on the DLT-V72, the system overview can be used for testing: Fig. 9.1: System overview in Control Panel For 32 bit systems: Open the subfolder Win7_X86. -
Page 53: Fig.9.2: Setup.exe For 64 Bit Operating System In The Subfolder Win7_X64
Wi-Fi configuration Example screenshot for 64 bit system, subfolder Win7_X64: Fig.9.2: Setup.exe for 64 bit operating system in the subfolder Win7_X64 NOTE The remaining installation workflow is covered in the next chapter and is identical in all operating systems. 56 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... -
Page 54: Driver Installation Win7Pro / Win 8.1 Indpro / Win 10 Iot
Wi-Fi configuration 9.6.5. Driver installation Win7Pro / Win 8.1 IndPro / Win 10 IoT Open the corresponding installation directory depending on the operating system. Run Setup.exe to start the installation. NOTE The following installation example shows the Win8.1 / 10 driver. For Windows7 installation, please use the corresponding Win7 driver. -
Page 55: Fig.9.4: Igx Driver Installation Welcome Dialog
Wi-Fi configuration On completion, the following window is displayed that starts the actual driver installation process: Fig.9.4: IGX driver installation Welcome dialog Continue the installation with Next: Fig.9.5: IGX driver installation user and company name In this dialog, enter a username and a company name and confirm with Next. ... -
Page 56: Fig.9.6: Igx Driver Installation All Program Features
Wi-Fi configuration Fig.9.6: IGX driver installation All program features Leave the Complete option enabled. Continue the installation with Next. Fig.9.7: IGX driver installation starts Continue the installation of the required files with Install. DLT-V72 Operating Instructions V2.50 Preliminary 59 / 140... -
Page 57: Fig.9.8: Igx Driver Installation Windows Security
Wi-Fi configuration During installation, the following window is opened: Fig.9.8: IGX driver installation Windows Security Ensure that the Always trust software from… option has been selected. Continue the driver installation with Install. Fig.9.9: IGX driver installation Exit with Finish Exit the driver installation with Finish. -
Page 58: Fig.9.10: Igx Driver Installation Perform Computer Re-Start
Wi-Fi configuration The system re-start is carried out. Fig.9.10: IGX driver installation Perform computer re-start DLT-V72 Operating Instructions V2.50 Preliminary 61 / 140... -
Page 59: Start Wi-Fi Client Manager, Login
Wi-Fi configuration 9.6.6. Start Wi-Fi Client Manager, Login Launch the Wi-Fi Client Manager by double-clicking the Launch WCU icon: Fig.9.11: WCU icon on the desktop You must login as "WCU_Administrator" first. To do this, click Admin Login. Fig.9.12: WCU main window, Admin Login 62 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... -
Page 60: Fig.9.13: Wcu-Administrator Login Window
Wi-Fi configuration Then open the login window. Enter the passport, which by default is "gold". Confirm the input with the Login button. Fig.9.13: WCU-Administrator login window DLT-V72 Operating Instructions V2.50 Preliminary 63 / 140... -
Page 61: Wi-Fi Client Manager Functions
Wi-Fi configuration 9.6.7. Wi-Fi Client Manager functions 9.6.8. License The License function lists the current status of the enabled options: Fig.9.14: Check License NOTE The correct implementation of the Wi-Fi driver requires a valid license in combination with the DLT-V72 terminal. If, as shown in the image, the license information is missing: Contact technical customer support to solve the problem. -
Page 62: Browse Nearby Wireless Networks
Wi-Fi configuration 9.6.9. Browse nearby wireless networks 9.6.9.1. Set up the Wi-Fi connection To set up a Wi-Fi connection, you can show all available networks using the Browse nearby wireless networks function. You can select the appropriate network from here. Fig.9.16: Browse nearby wireless networks function DLT-V72 Operating Instructions V2.50 Preliminary 65 / 140... -
Page 63: Fig.9.17: Advanced Security Settings Dialog
Wi-Fi configuration 9.6.9.2. Define security settings The security settings must now be selected depending on the network. These settings can be made in the Advanced Security Settings section: Fig.9.17: Advanced Security Settings dialog To be able to connect with the network automatically, set the checkmark to connect automatically when the network is in range: Fig.9.18: Connection when the network is in range dialog 66 / 140... - Page 64 Wi-Fi configuration Available parameters in the Connection and Security sections: Connection Connect automatically when the Enable this parameter to set up an automatic network is in range connection to the network. Connect to a more preferred In the event of multiple profiles being present, this network if available option can be used to select the preferred profile.
-
Page 65: Fig.9.19: Security Settings - Network Authentication Methods
Wi-Fi configuration This results in the following selection options and settings: Fig.9.19: Security settings - network authentication methods The network authentication methods shown, as well as their designations, differ depending on the operating system used. 68 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... -
Page 66: Fig.9.20: Security Settings - Advanced Settings (Cisco: Leap)
Wi-Fi configuration For the remaining settings as in the case shown above (Cisco: Leap), the required additional parameters are carried out using the two buttons Settings and Advanced settings. Fig.9.20: Security settings – Advanced settings (Cisco: Leap) Fig.9.21: Security settings – LEAP properties Lastly, the network key must be entered in the following example (WPA2-Personal) (Network ... -
Page 67: Fig.9.22: Wireless Network Properties Dialog
Wi-Fi configuration Fig.9.22: Wireless Network properties dialog Fig.9.23: Create new profile dialog Confirm the new profile with the OK button. 70 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... -
Page 68: Fig.9.24: Network Connection Is Established
Wi-Fi configuration 9.6.9.3. Establish network connection After the Wi-Fi profile settings have been made, a connection to the network is established automatically. The connection setup with the selected network is successful only if the "green" connection line is displayed in the WCU main window. Fig.9.24: Network connection is established DLT-V72 Operating Instructions V2.50 Preliminary 71 / 140... -
Page 69: 9.6.10. Roam Management
Wi-Fi configuration 9.6.10. Roam Management 9.6.10.1. General After clicking the General dialog, the following information is displayed on the screen: Fig.9.25: General dialog in the Roam Management menu General Info Meaning of the display Client Status Current connection status Connected / Disconnected Network Name SSID SSID of the currently connected access points Network Type... -
Page 70: Fig.9.26: Roaming Dialog In The Roam Management Menu
Wi-Fi configuration Security Authentication The authentication process used, e.g. WPA2-PSK (Pre-Shared- Key) Display of the corresponding encryption process, e.g. (AES-CCMP, Encryption TKIP) 9.6.10.2. Roaming The Roaming dialog is used to define the following parameters: Fig.9.26: Roaming dialog in the Roam Management menu Roam Signal Level (dBm): This setting defines when the client is to be begin the roaming... -
Page 71: Fig.9.27: Roam Management - Choose Band And Channels
Wi-Fi configuration timestamp is added. If the log file is larger than 100 mb, a new file is created. Note: This option should only be enabled for short periods for analysis purposes, not permanently! Firmware Logging Option can be enabled to create a "Firmware" log. The log file is saved to the C:\WlanLogs folder and is assigned the current timestamp and the extension _fw. - Page 72 Wi-Fi configuration Channel List Select all 2.4Ghz This option can be used for simultaneous pre-selection of all channels 2.4 GHZ channels 1 to 13 supported by the Wi-Fi driver. Modifications to individual channels can be carried out at any time by clicking the checkboxes for each channel.
-
Page 73: Fig.9.28: Radio Dialog In The Roam Management Menu
Wi-Fi configuration 9.6.10.3. Radio Tab The Radio dialog is used to define the following parameters: Fig.9.28: Radio dialog in the Roam Management menu Power Save The Power Save Level is set. The levels OFF and Auto-PSM are available. Mode Selection The band of the client is specified. -
Page 74: Laird Connection Manager (Lcm)
Wi-Fi configuration 9.6.10.4. Adapter Tab After clicking the Adapter dialog, the following information is displayed on the screen: Fig.9.29: Adapter Tab in Roam Management menu 9.6.11. Laird Connection Manager (LCM) Start LCM: By clicking the LCM icon on the desktop ... -
Page 75: Fig. 9.31: Lcm Configuration Tab With The Manage Profiles Button
Wi-Fi configuration Click on Manage Profiles. Fig. 9.31: LCM Configuration tab with the Manage Profiles button Click the Admin Login tab. Fig. 9.32: LCM Manage Profiles dialog box with the Admin Login tab Default password: SUMMIT (Must be entered in upper-case characters.) Fig. -
Page 76: Wwan Configuration
WWAN configuration WWAN configuration 10.1. Safety notice CAUTION Danger of radiation emission. DLT-V72 devices with radio technology emit high frequency energy (abbreviation: HF). To protect persons against HF radiation: Mount the DLT-V72 so that persons and domestic animals maintain a minimum distance of 20 to 50 cm from the radio antennas. -
Page 77: Differences Between Ms Windows And Linux
WWAN configuration Information on radio performance The consistency of the radio performance is dependent on the following factors: 12. Radio card (set transmission power) 13. Connecting cables 14. Antenna gain Help table for the correct setting: 10.2. Differences between MS Windows and Linux The radio configuration of the DLT-V72 with MS Windows operating system is described in the following manual sections. -
Page 78: Sim Card For Wwan (Customer-Specific)
WWAN configuration 10.4. SIM card for WWAN (customer-specific) A SIM card is required in addition to the WWAN card. The SIM card must be plugged in into the SIM card slot underneath the DLT-V72 antenna: Fig. 10.1: Sim card slot underneath the DLT-V72 antenna NOTICE: Property damage Inserting the SIM card: DLT-V72 must be switched off NOTE... -
Page 79: Open Device Manager
WWAN configuration 10.5.1. Open device manager Check whether or not the Sierra Wireless HSPA Modem is present in the list of modems. Fig. 10.2: SIERRA WIRELESS MC80 - Device manager, Sierra Wireless HSPA Modem Display the Properties window of the Sierra Wireless HSPA Modems (left mouse button). ... -
Page 80: Establish Internet Connection
WWAN configuration 10.5.2. Establish Internet connection Open the Network and Sharing Center. Click Set up a new connection or network. Fig. 10.4: SIERRA WIRELESS MC80 - Set up a new connection or network Connect to the Internet - select ... -
Page 81: Fig. 10.7: Sierra Wireless Mc80 - Telephone Number And Connection Name
WWAN configuration Specify as a telephone number, e.g. *99***1#. Enter a connection name, e.g. Vodafone test connection. Username and password are not required in the example (provider- dependent). Fig. 10.7: SIERRA WIRELESS MC80 - Telephone number and connection name Open the Vodafone test connection under Network connections. -
Page 82: Fig. 10.10: Sierra Wireless Mc80 - Function Test Gsm / Gnss, Test Connection Status
WWAN configuration In the Network and activation center of the device, the status of the test connection can be tested: Right-click the network and then select Status. Fig. 10.10: SIERRA WIRELESS MC80 - Function test GSM / GNSS, test connection status DLT-V72 Operating Instructions V2.50 Preliminary 85 / 140... -
Page 83: Sierra Wireless Mc80 Trouble Shooting
WWAN configuration 10.5.3. SIERRA WIRELESS MC80 Trouble Shooting 10.5.3.1. Testing the virtual COM ports for Wireless card SIERRA WIRELESS MC80 In the device manager it is possible to test that the virtual COM ports are correctly set. If they are not correctly set, they must be modified as appropriate. DLT-V72 with D525 processor: The virtual COM ports must be set up as shown in the figure: Fig. -
Page 84: Fig. 10.12: Sierra Wireless Mc80 - Virtual Com Ports Dlt-V72 With I5 Processor
WWAN configuration DLT-V72 with i5 processor: The virtual COM ports must be set up as shown in the figure: Fig. 10.12: SIERRA WIRELESS MC80 - Virtual COM ports DLT-V72 with i5 processor DLT-V72 with Celeron processor: The virtual COM ports must be set up as shown in the figure: Fig. -
Page 85: Fig. 10.14: Sierra Wireless Mc80 - Test Nmea Data Flows
WWAN configuration 10.5.3.2. Test communication between DLT-V72 and WWAN Radio card The open source software Tera Term, for example, can be used to test that the DLT-V72 can communicate with the Radio card. This software can be downloaded from the following URL, for example (website available at time of writing this operating manual, dated Feb 2019): https://www.heise.de/download/product/tera-term-51776 Perform the following steps:... -
Page 86: Configuration Of Radio Card Quectel Ec25
WWAN configuration 10.6. Configuration of Radio card QUECTEL EC25 The following information is valid for the Radio card QUECTEL EC25. Its precise designation is: 15. USA: QUECTEL EC25A or EC25V 16. Europe: QUECTEL EC25E The WWAN configuration is identical for both Radio cards. For this reason, the abbreviation QUECTEL EC25 is used. -
Page 87: Fig. 10.17: Quectel Ec25 - Connect To The Internet - Dial-Up
WWAN configuration Click Dial-up. Fig. 10.17: QUECTEL EC25 - Connect to the Internet - Dial-up Specify as a telephone number, e.g. *99***1#. Enter a connection name, e.g. Vodafone test connection. Username and password are not required in the example. (Provider- dependent) Fig. -
Page 88: Fig. 10.20: Quectel Ec25 - Dial Vodafone Test Connection
WWAN configuration Do not enter a user name or password. Click Dial. The test connection is established. Fig. 10.20: QUECTEL EC25 - Dial Vodafone test connection In the Network and activation center of the device, the status of the test connection can be tested: Right-click the network and then select Status. -
Page 89: Quectel Ec25 Trouble Shooting
WWAN configuration 10.6.2. QUECTEL EC25 Trouble Shooting 10.6.2.1. Test virtual COM ports In the device manager it is possible to test that the virtual COM ports are correctly set. If they are not correctly set, they must be modified as appropriate. DLT-V72 with i5 processor The virtual COM ports must be set up as shown in the figure: Fig. -
Page 90: Fig. 10.23: Quectel Ec25 - Virtual Com Ports Dlt-V72 With Celeron Processor
WWAN configuration DLT-V72 with Celeron processor The virtual COM ports must be set up as shown in the figure: Fig. 10.23: QUECTEL EC25 - Virtual COM ports DLT-V72 with Celeron processor 10.6.2.2. Test communication between DLT-V72 and WWAN Radio card The open source software Tera Term, for example, can be used to test that the DLT-V72 can communicate with the Radio card. -
Page 91: Fig. 10.24: Quectel Ec25 - Test Nmea Data Flows
WWAN configuration 10.6.2.3. Test that GNSS data can be received The open source software Tera Term, for example, can be used to test that GNSS data can be received. Availability of the software: see previous section. Perform the following steps: Open the NMEA port via Tera Term. -
Page 92: Mechanical Installation
Mechanical installation Mechanical installation Recommend sequence for the mechanical installation Requirement: The vehicle/installation location must be prepared (e.g. connection to the ignition, correct voltage, etc.) Determine a suitable mounting position for the DLT-V72. − Secure device mounting at the vehicle (RAM Mount etc.). −... -
Page 93: Mounting The Dlt-V72 At The Deployment Location
Mechanical installation NOTICE: Physical damage Damage and scratching of the touchscreen without transport protective film. The front display of the DLT-V72 is protected during transport by a transparent film. This film should remain on the front display during assembly to avoid damage to the front display surface. Only remove the film after all of the installation work has been completed. - Page 94 Mechanical installation DANGER Risk of accident on vehicles due to unexpected vehicle emergency stop because of electro-conductive connection of the DLT-V72 to the vehicle chassis. Due to a variety of technical properties of forklifts and forklift trucks, it can be necessary to electrically isolate DLT-V72 from the chassis of the vehicle to prevent malfunctions.
-
Page 95: Attaching Accessories To The Dlt-V72
Mechanical installation 11.3. Attaching accessories to the DLT-V72 For example: mounting bracket, scanner mounting ATTENTION: Physical damage Only use mounting brackets, accessories and mounting materials that have been tested and approved for the respective DLT-V72. Otherwise, any warranty for this device will be void. All mounting brackets, accessories and mounting materials supplied by Advantech are only intended to be used for attachment of the Industrial Computers and the peripheral devices and may not be misused. -
Page 96: Attach The Mounting Bracket
Mechanical installation Examples for RAM Mount Set mounting materials RAM Mount Set short (arm length, 130 mm) RAM Mount Set long (arm length 215 mm) Fixing plate RAM Mount VESA Fixing plate RAM Mount VESA Mounting bracket VESA Mounting bracket VESA Washer spring A6 DIN128 FSt galvan. -
Page 97: Attach The Advantech Accessories
Mechanical installation 11.3.3. Attach the Advantech accessories The housing of the DLT-V72 has holes provided for attaching an Advantech accessory. Example: Fig. 11.3: Scanner mounting attachment Screw-in depth: M6 x 6 mm Suitable mounting material: Cylinder head screw DIN 912 M6 Washer ISO 8738 - A6-A2 Installation sequence if Advantech mounting bracket and additional accessory are being attached If you are mounting an Advantech mounting bracket and a keyboard holder:... -
Page 98: Electrical Installation, Cable Connection, Cable Cover
Electrical installation, cable connection, cable cover Electrical installation, cable connection, cable cover 12.1. Safety notice – observe before connecting WARNING Risk of injury and damage due to improper electrical installation. These instructions are directed to skilled personnel. Only qualified skilled personnel are permitted to perform the electrical installation of the DLT-V72. -
Page 99: Preparations
Electrical installation, cable connection, cable cover 12.2. Preparations Lay out ready all cables that are to be connected to the DLT-V72. Select the appropriate slots on the connector panel of the DLT-V72. Test in which order the cables best fit in the cable compartment. ... -
Page 100: Inserting The Rubber Seal In The Cable Compartment
Electrical installation, cable connection, cable cover 12.3. Inserting the rubber seal in the cable compartment Place the rubber seal in the frame of the cable compartment (see figure). Press the plugs of the rubber seal into the holes of the frame. ... -
Page 101: Plugging In And Screwing On The Power Supply Cable
Electrical installation, cable connection, cable cover NOTICE: Physical damage Observe the potential ratios. On the DLT-V72, the logic ground and the shield ground are firmly connected to each other. Logic ground is the ground (GND) used to supply the internal parts and components such as the display or CPU. -
Page 102: Securing The Ground Using Ring Tongue To The Ground Bolt
Electrical installation, cable connection, cable cover 12.3.2. Securing the ground using ring tongue to the ground bolt Fig. 12.3: Ring tongue secured to the ground bolt Secure the ring tongue of the power supply cable to the ground bolt. ATTENTION For correct grounding, it is important to have the correct order of the components on the ground bolt (from inside to outside):... -
Page 103: Securing The Power Supply Cable To The Strain Relief Rail
Electrical installation, cable connection, cable cover 12.3.3. Securing the power supply cable to the strain relief rail Place one cable clip on the power supply cable. Secure the cable clip to the strain relief rail using 2 mounting screws ... -
Page 104: Connecting The Usb, Ethernet And Com Cables
Electrical installation, cable connection, cable cover 12.4. Connecting the USB, Ethernet and COM cables NOTICE: Physical damage Observe the following when connecting/removing external devices on the DLT-V72. Only use accessories that have been tested and approved for the respective DLT-V72. ... -
Page 105: Ethernet Cable
Electrical installation, cable connection, cable cover 12.4.2. Ethernet cable Plug the Ethernet cable into the associated port. Fold open the round cable passage in the rubber seal. Insert the Ethernet cable. Secure Ethernet cable to the strain relief rail with cable clips and screws. ... -
Page 106: Closing Off Unused Cable Openings
Electrical installation, cable connection, cable cover 12.5. Closing off unused cable openings Close off all unused cable openings of the rubber seal using the accompanying blind plugs so that they are sealed. Fig. 12.8: Unused cable outlets sealed off with blind plugs 12.6. -
Page 107: Pressure Compensation Element
Electrical installation, cable connection, cable cover 12.6.1. Pressure compensation element The DLT-V72 cable cover has a pressure compensation element. Do not modify or remove the pressure compensation element; doing so would make the device leak and the IP protection would no longer be ensured. Fig. -
Page 108: Connectors
Connectors Connectors 13.1. Under the cable cover Fig. 13.1: External connectors under the cable cover Pin assignment Power supply 12/24/48 VDC nominal 1 x RSMA (optional) Remote Wi-Fi antenna 1 x SMA (optional) Remote WWAN antenna USB0, USB1, USB2, USB3 USB 2.0 interfaces (HI-SPEED™), bootable RJ45 LAN Ethernet 10/100/1000 MBit/s... -
Page 109: Network Adapter (10/100/1000)
Connectors 13.1.1. Network adapter (10/100/1000) The DLT-V72 is equipped with a 10/100/1000 Mbit network adapter with 10/100/1000 Mbit per second. This adapter can be accessed via the bottom of the device and offers an RJ45 connection jack. The RJ45 connection port has two integrated status LEDs and are assigned as follows: Fig. -
Page 110: Com1 As A Voltage Source
Connectors 13.1.4. COM1 as a voltage source The COM1 interface can optionally supply to externally connected equipment with +5 VDC. The voltages are protected by internal fuses and may not exceed a continuous consumed current of 1 A at 5 V. Depending on the connected devices, the maximum current consumption may be significantly lower. -
Page 111: Cfast Slot
Connectors 13.2.2. CFast slot There is a CFast slot under the antenna. Exercise special care when removing and re-inserting CFast cards. Use only CFast cards that have been approved. 13.2.3. Antenna opening/closing Opening Loosen the two screws of the antenna using Torx screwdriver. ... -
Page 112: Integrated Power Supply, Power Supply Cable
Integrated power supply, power supply cable Integrated power supply, power supply cable DLT-V72 is equipped with a galvanically separated, integrated DC power supply unit. Power is connected to the back of the unit using a Phoenix Contact plug. There is no power switch. Fig. -
Page 113: Dc Voltage Supply Connection
Integrated power supply, power supply cable Power consumption DLT-V7210 (all model types) Typically 25 W; Standby typically 1 W DLT-V7212 Typically 30 W; Standby typically 1 W Power supply unit fuses Power supply unit Fuse type Example DC-16 5 x 20 mm T 12,5 A Schurter 0001.2515 H / 250 V Siba 179200.12,5... -
Page 114: Dc Power Supply Cable
Integrated power supply, power supply cable 14.1.2. DC Power supply cable WARNING Electric shock, fire due to incorrect power supply cable. Use only original Advantech power supply cables; these meet the specific requirements for low-temperature flexibility, UV resistance, oil resistance, etc. Fig. -
Page 115: Optional Equipment
Optional equipment Optional equipment 15.1. Integrated UPS (optional) The DLT-V72 is optionally available with an integrated uninterrupted power supply (UPS). The battery pack (lithium-ion technology) of the UPS is located in the battery pocket up top on the device. Fig. 15.1: Battery pocket DLT-V72 WARNING Personal injury due to short-circuit, fire, chemical burns, toxic substances. -
Page 116: Battery Pack Specifications
Optional equipment 15.1.1. Battery pack specifications Two battery pack types are available: Lithium-ion battery pack I Bridging time The integrated UPS can bridge an interruption of the main supply for typically 20 minutes. Requirement: The battery pack is fully charged. Operating temperature -20 to +40 °C Charging time... -
Page 117: Charging The Battery Pack
Optional equipment 15.1.2. Charging the battery pack Connect the properly installed DLT-V72 to the main supply voltage. ATTENTION: The cable cover of the DLT-V72 must be screwed together properly. The battery pocket must be screwed together properly. The device must be fully closed. WARNING Electric shock when charging the battery pack. -
Page 118: Fig. 15.2: Inserting The Battery Pack In The Battery Pocket
Optional equipment Procedure for opening the battery cover IMPORTANT: Switch off the DLT-V72. Loosen the two screws of the battery cover using an Allen wrench. Remove the battery cover. Remove the battery pack. Insert the new battery pack into the battery pocket as shown in the figure. ... -
Page 119: Screen Defroster (Optional)
Optional equipment 15.2. Screen defroster (optional) The following DLT-V72 devices are optionally available with a screen defroster. DLT-V7210 D with resistive touchscreen − DLT-V7212 D with resistive touchscreen − Functional description As soon as the internal temperature of the DLT-V72 device falls below 5°C, the screen defroster is automatically activated and heats the front of the device. -
Page 120: Keyboards And Keyboard Mounts (Optional)
Optional equipment 15.3. Keyboards and keyboard mounts (optional) Any USB keyboard can be connected to the DLT-V72. Advantech offers the following keyboards: Fig. 15.3: SMALL keyboard − SMALL keyboard Mountable − Protection class IP65 − − Keyboard layouts: German, English, French Fig. -
Page 121: Scanner And Scanner Bracket (Optional)
Optional equipment 15.4. Scanner and scanner bracket (optional) You can connect scanners to either the USB interface or the serial interface. Please contact your Advantech sales representative if needed. If connected to COM1, the scanner can be powered through the interface with a voltage of 5 V. ... -
Page 122: Touch Stylus
Optional equipment 15.5. Touch stylus Advantech offers some touch stylus pens (with associated mountings) for resistive and PCT touchscreens. Please contact your Advantech sales representative if needed. Use only touch stylus that have been approved by Advantech. Fig. 15.7: Examples touch stylus Touch stylus with mounting Touch stylus with mounting for resistive touchscreen:... -
Page 123: Protective Film For Touchscreen (Optional)
Optional equipment 15.7. Protective film for touchscreen (optional) An optional protective film is available for resistive touchscreens. This film protects the touchscreen during extreme use. NOTICE: Physical damage Do not attach the protective film to damaged or worn out touchscreens. Air bubbles can get trapped and cause malfunctions. -
Page 124: 16. Maintenance
Maintenance 16. Maintenance 16.1. Manufacturer, authorized service centers WARNING Only the manufacturer and its authorized service centers may perform: Repairs − Modifications − − Replace modules − Open the device The legal warranty shall apply. It expires if the customer performs measures on the device that are only permitted to be performed by the manufacturer and it’s authorized Service Centers. -
Page 125: Remove The Integrated Keyboard
Maintenance 16.2.1. Remove the integrated keyboard Fig. 16.1: Unscrew the mounting screws of the integrated keyboard Use a TX10 screwdriver to loosen the 5 mounting screws of the integrated keyboard. Carefully remove the keyboard grid; it will be used again later. Carefully remove the silicon keyboard mat;... -
Page 126: Fig. 16.4: Attach Keyboard Grid
Maintenance − Carefully press the 3 nubs on the back of the silicone keypad into the openings provided on the circuit board. Place on the keyboard grid at a 45° angle, see Fig. 16.4. Snap in keyboard grid lugs ... -
Page 127: 16.3. Regular Checks And Maintenance Of The Complete System
Maintenance 16.3. Regular checks and maintenance of the complete system To ensure the stability and security of the DLT-V72 complete system: Regularly check whether the DLT-V72 is firmly seated in the associated holder (RAM mount, mounting bracket) and the mounting screws are not loose. Also check whether the bracket is secured stably to the respective deployment location. -
Page 128: Touchscreen Protective Film (Optional)
Maintenance Cleaning the housing Ensure that the DLT-V72 is switched off and currentless. Clean the housing with a slightly dampened cloth. Do not use compressed air, a high-pressure cleaner or vacuum cleaner, as this can damage the surface. -
Page 129: Malfunctions And Troubleshooting
Malfunctions and troubleshooting Malfunctions and troubleshooting Please contact Advantech if the DLT-V72 malfunctions. Error Possible cause(s) Remedy Battery pack run time The device may possibly Check the temperature specifications for is significantly shorter not be in the temperature the device and surroundings. than specified. - Page 130 Malfunctions and troubleshooting does not start Operating system damage Operating system or image must be reinstalled Software keyboard License missing or invalid Enter the correct software license not functioning No Wi-Fi connection Connection deactivated Activate connection in the Control Panel AP access problem List ACL and check access rights to AP Invalid network settings...
-
Page 131: Reasonably Foreseeable Misuse
Reasonably foreseeable misuse Reasonably foreseeable misuse Observe the intended use The DLT-V72 Industrial Computers are data communication terminals for use in commercial environments (e.g. logistics, warehousing, manufacturing). Do not use in the EX zone (potentially explosive), on ships and rail vehicles. ... -
Page 132: Guidelines And Certificates
Guidelines and certificates Guidelines and certificates 19.1. Simplified EU declaration of conformity The manufacturer: Advantech Co Ltd NO.1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 114, Taiwan (R.O.C.) Authorized representative in Europe: Advantech Europe B.V. Science Park Eindhoven 5708, 5692 ER Son, Netherlands Hereby declares that the following products Product name: Industrial Computer Model name: DLT-V72xx... -
Page 133: Usa/Canada
Guidelines and certificates 19.3.3. USA/CANADA This equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co- located or operating in conjunction with any other antenna or transmitter This device complies with part 15 of the FCC rules and RSS-247 of Industry Canada. -
Page 134: China
19.6. MIC Japan (previously TELEC) In several of the DLT-V72 series, the PE15N PCI Express Mini Card from Laird is used. Laird has implemented the following MIC certifications for this: − Article 2 Item 19, Category WW (2.4 GHz Channels 1 - 13) −... -
Page 135: End-Of-Life Device Disposal
End-of-life device disposal End-of-life device disposal DLT-V72 devices and lithium-ion batteries are recyclable; they may not be disposed of with general/domestic waste. They must be disposed of properly in accordance with local regulations. Please contact the responsible authorities in your country/region to find out about the applicable regulations, if necessary. 138 / 140 DLT-V72 Operating Instructions V2.50 Preliminary... - Page 136 List of figures List of figures Fig. 5.1: Dimensions DLT-V7210 P, R, D ..........................16 Fig. 5.2: Dimensions DLT-V7212 P, R, D ..........................17 Fig. 5.3: Dimensions DLT-V7210 K, KD ..........................18 Fig. 5.4: Dimensions DLT-V7212 P+ ........................... 19 Fig. 5.5: Position VESA drill holes DLT-V7210 P, R, D ....................... 20 Fig.
- Page 137 List of figures Fig. 10.3: SIERRA WIRELESS MC80 - Sierra Wireless HSPA Modem - Properties ............82 Fig. 10.4: SIERRA WIRELESS MC80 - Set up a new connection or network ..............83 Fig. 10.5: SIERRA WIRELESS MC80 - Connect to the Internet ..................83 Fig.
Need help?
Do you have a question about the DLT-V72 Series and is the answer not in the manual?
Questions and answers
