  • Page 1 Advantech-DLoG DLT-V83 Series ∕ Manual DLT-V83 Series Industrial PCs Manual V1.31 www.advantech-dlog.com...
  • Page 2 Manual PN: 20DLDOCX885199E04 Manual Version: V1.31  Copyright 2013-2015 DLoG GmbH info@dlog.com By DLoG GmbH Industriestraße 15 www.advantech-dlog.com All rights reserved D-82110 Germering Phone (+49) 89 / 41 11 91 0 Fax (+49) 89 / 41 11 91 - 900...
  • Page 3 Chapter overview IMPORTANT INFORMATION ABOUT THE DLT-V83 MANUALS ESSENTIAL SAFETY INSTRUCTIONS FUNCTIONAL DESCRIPTION UNPACKING, TRANSPORTING AND STORING THE DEVICE OPERATING THE TOUCHSCREEN, FRONT KEYS CONFIGURATION MOUNTING (MECHANICAL AND ELECTRICAL) POWER SUPPLY UNITS, PIN ASSIGNMENT, POWER SUPPLY SERVICE USB AND SIM CARD SLOT OPTIONAL EQUIPMENT/ACCESSORIES SERIAL INTERFACES AUTOMATIC SHUT DOWN...
  • Page 5: Table Of Contents

    6. CONFIGURATION.............. 44 Table of contents 6.1. Configuring the DLT-V83 with Linux (optional) ....... 45 6.2. MS Windows operating systems (optional) ......45 1. IMPORTANT INFORMATION ABOUT THE DLT-V83 6.2.1. Setting up MS Windows ............45 MANUALS ................. 7 6.2.2. USB recovery stick ..............
  • Page 6 Pre-converter and power cables (optional) ......107 14.16. Device dimensions ..............143 10.5. Integrated low profile Wi-Fi antenna (optional) ....... 108 14.16.1. DLT-V8310 ................143 14.16.2. DLT-V8312 ................146 10.6. Integrated Wi-Fi antenna (optional) ........109 14.16.3. DLT-V8315 ................149 10.7.
  • Page 7: Important Information About The Dlt-V83 Manuals

    Information in this chapter: Available manuals (in printed form or on the Internet) Current manuals and drivers on the Internet Design elements in the manual ONE manual for all device models Advantech-DLoG DLT-V83 Series Manual V1.31 Page 7 of 178...
  • Page 8: Available Manuals (In Printed Form Or On The Internet)

    Current manuals and drivers on the Internet The latest versions of our manuals and device drivers are available at our website www.advantech-dlog.com: − Manuals in the Download -> Products menu − Device drivers in the Download -> Service -> Drivers menu (FTP link) Page 8 of 178 DLT-V83 Series Manual V1.31...
  • Page 9: Design Elements In The Manual

    Information about physical damage as well as tips for handling product and manual are shown as follows: NOTICE: Physical damage Information about possible physical damage Tips for using the product Note about additional information in manuals Advantech-DLoG DLT-V83 Series Manual V1.31 Page 9 of 178...
  • Page 10: One Manual For All Device Models

    Important information about the DLT-V83 manuals 1.4. ONE manual for all device models This manual applies to all models of the DLT-V83 series: − DLT-V8310 (with 10" display) − DLT-V8312 (with 12" display) − DLT-V8315 (with 15" display) − Device model with resistive touchscreen −...
  • Page 11: Essential Safety Instructions

    Do not repair or modify NOTICE: Physical damage Observe all essential safety instructions. The manufacturer assumes no liability for any and all damages that can be attributed to non-observation of these safety instructions. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 11 of 178...
  • Page 12: Installation/Commissioning By Qualified Skilled Personnel

    Users of the DLT-V83 industrial PC must be trained by qualified skilled personnel and instructed about the operation of the device. Users of DLT-V83 industrial PCs with integrated UPS must also be trained in the proper handling of lithium-ion batteries. Page 12 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 13: Hazards From Lithium-Ion Batteries

     Use only tools with insulated handles.  Do not damage the cable cover with lithium-ion batteries; do not drill through and do not crush or drop. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 13 of 178...
  • Page 14: Proper Storage

    DLT-V83 immediately from the source of power.  Do not continue to use the DLT-V83 if you notice unusual heat or smells during charging.  Provide for sufficient ventilation of the DLT-V83 during charging. Page 14 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 15: Risks During Installation/Commissioning

    This also effects the peripherals supplied by the device. 2.3.5. No repair/replacement of the lithium-ion batteries If the lithium-ion batteries are faulty, the entire cable cover, including the integrated batteries, must be replaced. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 15 of 178...
  • Page 16: Hazards From Electric Power

     Unplug the UPS battery. Disconnecting the DLT-V83 without UPS from the electric power source  Shut down the DLT-V83 via the operating system function.  Disconnect from the power source. Page 16 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 17 This also effects the peripherals supplied by the device. Use only original power supply cables from Advantech-DLoG Advantech-DLoG power cables meet the specific requirements for low- temperature flexibility, UV resistance, oil resistance, etc.  Use only original power supply cables from Advantech-DLoG.
  • Page 18 The operation of electrical equipment at locations where flammable gases or vapors are present poses a safety hazard.  Turn off the DLT-V83 when you are near gas stations, fuel depots, chemical plants or places where blasting operations take place. Page 18 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 19: Hazards During Transport, Installation, And Commissioning

    The mounting environment must not result in a closed system. Without fresh cooling air the DLT-V83 may overheat and may be damaged beyond repair. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 19 of 178...
  • Page 20: Observe When Connecting/Removing External Devices

    DLT-V83 cannot take place. Only use authorized accessories  Only use cables, power supply units, and other accessories that have been tested and approved by Advantech-DLoG for the respective DLT-V83.  Ask your Advantech-DLoG sales representative about authorized accessories. Page 20 of 178 DLT-V83 Series Manual V1.31...
  • Page 21: Radio Wave Emission Hazards

    Some technical equipment in hospitals and aircraft is not shielded against radio frequency energy.  Do not use the DLT-V83 in aircraft or hospitals without receiving prior authorization. Use in both is only permitted if such authorization has been obtained. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 21 of 178...
  • Page 22: Do Not Repair Or Modify

    The legal warranty shall apply. This warranty expires if any of the following unauthorized measures are performed by the customer: − Repairs to the device − Modifications to the device − Replacement of modules − Opening the device Page 22 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 23: Functional Description

    Functional description Functional description Information in this chapter: Intended use Mount, operate and service the device correctly Warranty conditions LCD display Device identification/name plate Advantech-DLoG DLT-V83 Series Manual V1.31 Page 23 of 178...
  • Page 24: Intended Use

    Permitted environmental conditions DLT-V83 industrial PCs may only be used under specified environmental conditions. See section 14.4 Environmental conditions. Observe the various environmental conditions of the devices with and without integrated UPS! Page 24 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 25: Mount, Operate And Service The Device Correctly

    The owner/operator commitments with regards to safety (accident prevention regulations, occupational safety) are to be followed. 3.3. Warranty conditions For DLT-V83 industrial PCs, batteries and accessories the Advantech-DLoG TOB regulations are valid (section Liability for defects -> limitation period for claims). Find details on the Advantech-DLoG Homepage: http://www.dlog.com/en/tob/.
  • Page 26: Device Identification/Name Plate

    1 A max. supply unit with max. nominal current 1.66 or 1.80 GHz Clock rate of the CPU Week and year of manufacture S/N ..Serial number: Specific Advantech-DLoG device code Page 26 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 27: Unpacking, Transporting And Storing The Device

    Unpacking, transporting and storing the device Unpacking, transporting and storing the device Information in this chapter: Unpacking Transport Storage If a return/repacking is necessary Advantech-DLoG DLT-V83 Series Manual V1.31 Page 27 of 178...
  • Page 28: Unpacking

    DLT-V83 devices with internal UPS (optional) are equipped with lithium-ion batteries in the cable cover of the device. Lithium-ion batteries are chemical stores of energy which can lead to personal injury or physical damage if they are stored or handled improperly. Page 28 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 29  Place the DLT-V83 into operation within 3 months of receiving it and charge the lithium-ion batteries, which are integrated into the cable cover.  If you are not placing the DLT-V83 into operation within 6 months, make sure you charge it intermediately. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 29 of 178...
  • Page 30: If A Return/Repacking Is Necessary

    If you repack the device, please ensure that the cling wrap in the cardboard frame is positioned towards the front of the device so that it can provide the proper protection. Page 30 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 31: Operating The Touchscreen, Front Keys

    DLT-V83 front keys with PCT touchscreen Software keyboard (optional) NOTICE: Physical damage Operators of the DLT-V83 industrial PC must be trained. Improper operation can cause damage and downtimes to the DLT-V83 industrial PC. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 31 of 178...
  • Page 32: Switching The Dlt-V83 On/Off

    Time between switching off and on: 10 seconds After the DLT-V83 has been shut down and switched off, it takes 10 seconds until the device will react to a switch-on signal (<Power> button / ignition). Page 32 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 33: Operating The Touchscreen

    (abbreviated PCT). Resistive touchscreen available for PCT available for DLT-V8310 with 5 or 26 front keys DLT-V8310 with 9 front keys DLT-V8312 with 5 or 26 front keys DLT-V8312 with 9 front keys...
  • Page 34: Operating The Pct Touchscreen

    (WES 2009) Microsoft Windows 7 Professional Microsoft Windows Embedded Standard 7 (WES7) No - license-dependent Microsoft Windows Embedded 8.1 Industry Pro Microsoft Windows Embedded 8 Standard (WE8S) Advantech-DLoG Linux-Image, based on Debian Page 34 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 35: Dlt-V83 Front Keys With Resistive Touchscreen

    Operating the touchscreen, front keys 5.3. DLT-V83 front keys with resistive touchscreen 5.3.1. Overview of the operating elements on the device front Fig. 5.2: Operating elements on the DLT-V8310, 26 front keys, resistive touchscreen Front keys: - Turn on/off Front keys: - Display brighter...
  • Page 36: Device With 26 Front Keys

    <Shift> key; if the LED is illuminated, it indicates that the <Shift> is activated Explanation LED (red): Indicates a device temperature outside the normal range LED (green): Indicates access to the flash drive LED (green): Display of available internal supply voltage Page 36 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 37 End / Forwards (switch with <Shift> key) Special keys <S1> and <S2> These keys are configured with the "DLoG Config" program; the associated manual is available in the Download Center at www.advantech-dlog.com. <Esc> key <Enter> key Below on the device:...
  • Page 38: Device With 5 Front Keys

    LED off: Touch activated Explanation LED (red): Indicates a device temperature outside the normal range LED (green): Indicates access to the flash drive LED (green): Display of available internal supply voltage Page 38 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 39: Operating States

    -30 and +62 °C again. Computer start-up/normal operational state/shutdown delay time Temperature < -30 or > +70 °C FLASHING Temperature sensor malfunctioning Advantech-DLoG DLT-V83 Series Manual V1.31 Page 39 of 178...
  • Page 40: Dlt-V83 Front Keys With Pct Touchscreen

    Operating the touchscreen, front keys 5.4. DLT-V83 front keys with PCT touchscreen 5.4.1. Overview of the operating elements on the front side Fig. 5.3: Operating elements front side DLT-V8310 with PCT touchscreen Front keys: Front keys: - Special keys - Turn on/off...
  • Page 41: Function Of The Front Keys

    The key glows white when the backlight is switched off The backlight can also be switched on using the "Display brighter" key. Explanation Access to storage medium (backlit green when active) Advantech-DLoG DLT-V83 Series Manual V1.31 Page 41 of 178...
  • Page 42: Operating States

    Special keys <S1> to <S8> These keys are configured with the "DLoG Config" program; the associated manual is available in the Download Center at: www.advantech-dlog.com. Shift key <Shift> is activated when the key lights up white. This allows access to the functions <S5> to <S8>.
  • Page 43: Software Keyboard (Optional)

    Fig. 5.4: Software keyboard If the software keyboard was ordered together with the DLT-V83 industrial PC, then the program will have been fully pre-licensed by the Advantech-DLoG production department. For subsequent installation, an installation program is available. TIP: Download the software keyboard manual The manual for the DLoG software keyboard is available in the Download Center at www.advantech-dlog.com.
  • Page 44: Configuration

    If the DLT-V83 is incorrectly configured, the DLoG GmbH warranty for this device will be void. TIP: Configure first then mount at the installation location  Configure the DLT-V83 before mounting it on machines or vehicles. Page 44 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 45: Configuring The Dlt-V83 With Linux (Optional)

    Refer to the relevant operating system manual for specific instructions. 6.2.2. USB recovery stick The optional Advantech-DLoG recovery stick allows images to be backed up and restored onto the DLT-V83 when necessary (backup & recovery). Please contact your Advantech-DLoG sales representative if needed.
  • Page 46: Configuring The Front Keys, Automatic Shut Down, Etc

    For configuring DLT-V83, the DLoG Config version 4.0.0 (or higher) is required. The DLoG Config manual is available on the Internet at www.advantech- dlog.com (Download menu). Fig. 6.1: DLoG Config Tool main menu Page 46 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 47: Wi-Fi (Optional)

    The regulatory authorities for the respective country can provide information on this. Please keep in mind the configuration for the transmitting power: − Wireless card (set transmission power). − Connecting cables. − Antenna gain. Help table for the correct setting: Advantech-DLoG DLT-V83 Series Manual V1.31 Page 47 of 178...
  • Page 48: Antenna Solutions For Use In Germany

    EIRP (Equivalent Isotropically Radiated Power), in the 2.4 GHz frequency band is set at 20 dBm (100 mw).  Set the transmitting power of the Advantech-DLoG antenna so that the permitted EIRP limit value is complied with.
  • Page 49: Summit Client Utility (Scu) For Wi-Fi Configuration

     To do this, click Admin Login. Default password: SUMMIT (Upper-case characters must be used.) You can find information on the configuration parameters in the SCU online help system. Fig. 6.2: Summit Client Utility menu Advantech-DLoG DLT-V83 Series Manual V1.31 Page 49 of 178...
  • Page 50: Laird Connection Manager (Lcm)

    Fig. 6.3: Initial Laird Connection Manager dialog box Depending on the configuration, you may have to enter a password.  To do this, click Configuration -> Manage Profiles. Fig. 6.4: LCM Configuration tab with the Manage Profiles button Page 50 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 51: Windows Zero Configuration (Wzc)

    Fig. 6.6: Entering the LCM password: SUMMIT The default password is SUMMIT (must be entered in upper-case characters). 6.4.6. Windows Zero Configuration (WZC) You will find information on WZC in the Microsoft Windows online help system. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 51 of 178...
  • Page 52: Wwan, Internal Gps (Optional)

    6.5. WWAN, internal GPS (optional) The options WWAN via internal PCIe MiniCard and GPS via internal PCIe MiniCard are available for DLT-V8310 and DLT-V8312. CAUTION Radiation emissions from WWAN. Observe the applicable regulations for the respective country with regard to frequencies and maximum permitted transmitting power.
  • Page 53: Installation, Configuration, Test

    The installation on 64-bit systems is done in the same manner, only the name of the files and directories is different. Driver installation  Copy Sierra Wireless driver to "C:\Util\". Fig. 6.7: WWAN driver installation, Sierra Wireless driver to C:\Util\ Advantech-DLoG DLT-V83 Series Manual V1.31 Page 53 of 178...
  • Page 54: Fig. 6.8: Wwan Driver Installation, Wwan 32-Bit

    Configuration Fig. 6.8: WWAN driver installation, WWAN 32-bit  Open "WWAN 32-bit".  Right-click on "WWAN32.cmd" and Run as administrator. Fig. 6.9: WWAN driver installation, Run as administrator Page 54 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 55: Fig. 6.10: Wwan Driver Installation, Com Port

    Fig. 6.10: WWAN driver installation, COM port After the installation, the COM ports should have been set up as shown in the figure above.  To complete the installation, restart the terminal. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 55 of 178...
  • Page 56: Fig. 6.11: Driver Configuration, Open Device Manager

    Fig. 6.11: Driver configuration, open device manager  Open the device manager.  Open properties of the Sierra wireless card. Fig. 6.12: Driver configuration, Sierra wireless card using Vodafone as example Page 56 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 57: Fig. 6.13: Function Test Gsm / Gps, Network And Sharing Center

    Function test GSM / GPS Fig. 6.13: Function test GSM / GPS, Network and Sharing Center  Open the Network and Sharing Center.  Open Set up a new connection or network. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 57 of 178...
  • Page 58: Fig. 6.14: Function Test Gsm / Gps, Connect To The Internet

    Configuration Fig. 6.14: Function test GSM / GPS, Connect to the Internet  Select Connect to the Internet and confirm. Fig. 6.15: Function test GSM / GPS, wireless  Select Dial-up. Page 58 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 59: Fig. 6.16: Function Test Gsm / Gps, Telephone Number

    Fig. 6.16: Function test GSM / GPS, telephone number  Enter *99***1# as telephone number and enter a name. Fig. 6.17: Function test GSM / GPS, network connections  Open the Vodafone test connection under Network connections. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 59 of 178...
  • Page 60: Fig. 6.18: Function Test Gsm / Gps, Test Connection

    Fig. 6.18: Function test GSM / GPS, test connection  Do not enter a user name or password.  Click on Dial. The test connection is established. Fig. 6.19: Function test GSM / GPS, test connection status Page 60 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 61: Fig. 6.20: Deleting The Gps Test Connection

    Configuration  After successful testing, delete the created test connection. Fig. 6.20: Deleting the GPS test connection GPS test Fig. 6.21: GPS test  Open the file "C:\Util\WWAN32\teraterm\ttermpro.exe". Advantech-DLoG DLT-V83 Series Manual V1.31 Page 61 of 178...
  • Page 62: Fig. 6.22: Gps Test, Com4

    Configuration Fig. 6.22: GPS test, COM4  Shift to Serial and select "COM4". GPS was activated successfully when the position data appears here: Fig. 6.23: GPS test position data Page 62 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 63: External Gps Solution (Optional)

    The GPS receiver has an integrated antenna for position data of the Global Positioning System (GPS) and communicates with the DLT-V83 via USB interface. We recommend using only a GPS receiver approved by Advantech-DLoG Fig. 6.24: GPS receiver (optional) Installation The installation CD supplied with the GPS receiver includes installation files and a multi-lingual manual.
  • Page 64: Can And Digital I/O Settings (Optional)

    To configure and test the CAN and digital I/O settings, the “IXXAT” driver is used. It is available at www.advantech-dlog.com/driver (Directory Advantech-DLoG Products -> Additional-Drivers-Software). Fig. 6.26: Start of the IXXAT driver installation When installing the “IXXAT”, configuration and test tools are copied to the DLT-V83.
  • Page 65: Imanager

    Hardware details such as the pin assignment of the CAN and Digital I/O interfaces are described here in the manual in: Chapter 11.4 CAN, digital I/O and second Ethernet interface (optional) Advantech-DLoG DLT-V83 Series Manual V1.31 Page 65 of 178...
  • Page 66: Configuring Screen Blanking (Optional)

    This resets the sensitivity of the touchscreen to an operating system default setting, which can result in poorer detection of taps on the screen. You can use Reset to reset the software recalibration. Page 66 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 67: Erp Settings For Ac Devices

     Configure Power Management and LAN Connection so that WakeOnLAN is deactivated. Example: Deactivate WakeOnLAN under WES 7: Fig. 6.28: Network Connection Properties, Figure 6.29: iManager: Network Connection Advanced Properties, Power Management Advantech-DLoG DLT-V83 Series Manual V1.31 Page 67 of 178...
  • Page 68: Power Options

    To optimize the power consumption of the DLT-V83, adapt the power options accordingly. Relevant settings: − Time until the DLT-V83 automatically switches to power-saving mode. − Time until the screen switches off automatically. Page 68 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 69: Mounting (Mechanical And Electrical)

     Only electronic and mechanical skilled personnel are permitted to install DLT- V83 industrial PCs.  Moreover, specialized knowledge about lithium-ion batteries and the applicable safety regulations is also required for devices with internal UPS (optional). Advantech-DLoG DLT-V83 Series Manual V1.31 Page 69 of 178...
  • Page 70: Warning About Injuries And Physical Damage

     Do not operate the DLT-V83 if there is visible damage.  Do not open or modify the DLT-V83.  Use only original Advantech-DLoG power cables; these meet the specific requirements for low-temperature flexibility, UV resistance, oil resistance, etc.  Important: If a DLT-V83 with integrated UPS is installed in a vehicle, the EMERGENCY-OFF switch of the vehicle has no effect on the DLT-V83.
  • Page 71: Overview Of Mounting Steps

    (and other people in your vicinity) should maintain a minimum distance of 20 cm from the antenna integrated into the DLT-V83.  Please observe this during installation of the DLT-V83 with antenna. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 71 of 178...
  • Page 72: Installation: Cooling By Means Of Fresh Air Supply

    Only power up the DLT-V83 when all devices have been connected and the DLT-V83 has been closed correctly (remember the cable cover!). Otherwise, you may damage the DLT-V83. Page 72 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 73: Attaching The Device Mounting Bracket (Optional)

    Attaching the device mounting bracket (optional) Observe the following information about the mounting brackets: − All support brackets and mounting parts supplied by Advantech-DLoG are only intended to be used for attachment of the industrial PCs and the peripheral devices and may not be misused.
  • Page 74: Connecting Dc Devices To The Power Supply

     Make sure that the cables are run without kinks and are protected (securely protected against crushing and abrading).  Use only original power supply cables from Advantech-DLoG. Advantech-DLoG power cables meet the specific requirements for low-temperature flexibility, UV resistance, oil resistance, etc. If other power supply cables are used: The user/operator of the industrial PC is solely responsible for the resulting damage.
  • Page 75: Essential Information For Vehicle Applications (E.g. Forklift)

    − In DC-powered devices, always attach ring tongues on the supply voltage cable to the provided ground bolt situated on the connector panel (see Fig. 7.2: Position of the ground bolt). Advantech-DLoG DLT-V83 Series Manual V1.31 Page 75 of 178...
  • Page 76: Electrically Isolated Installation

    If external antennas are being used, you must ensure that the antennas are isolated at the mounting point on the vehicle chassis. Page 76 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 77: Connecting Ac Devices To The Power Supply

    Logic ground is the ground (GND) used to supply the internal parts and components such as the display or CPU. All cable shields and the housing are connected to shield ground. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 77 of 178...
  • Page 78 DLT- V8315; otherwise, you may encounter start-up problems or malfunctions and there may even be irreparable damage to the device. Page 78 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 79: Attaching The Cable Cover

    (e.g. during scanning). − Unused cable entry holes for the strain relief rail must be closed off with dummy grommets. − The Advantech-DLoG cable cover must then be secured to the DLT-V83. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 79 of 178...
  • Page 80: Required Components

    Fig. 7.5: Dummy grommets and cable grommets for various cable diameters Cable clips Dummy Cable grommets, open/broken grommets through at one position Diameter of the cable grommet is specified on each grommet (3.5 mm to 8.0 mm) Page 80 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 81: Attaching Cable Grommets And Fixing Strain Relief In Place

    Cable grommets and dummy grommets should be cut off as cleanly as possible. This is important in order to seal the industrial PC well. Figure 6: Cable grommets and dummy grommets Correct: Incorrect: Advantech-DLoG DLT-V83 Series Manual V1.31 Page 81 of 178...
  • Page 82: Fig. 7.7: Example Cable Grommet

    The power supply cable is relatively stiff and should be straight (see figure).  Try to lay all cables parallel to each other without crossing each other. Page 82 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 83: Fig. 7.9: Unused Cable Outlets Sealed Off

    Fig. 7.11: Detailed view cable clips on strain relief rail  Tighten the screws to secure the cable but do not squeeze or crimp the cable! This may cause the cable to break or damage the cable insulation. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 83 of 178...
  • Page 84: Fig. 7.12: Cables And Dummy Grommets

    (see detailed view). This gives you the option of securing two cable clips located next to each other with a single screw. Example: Cables are fixed, dummy grommets are positioned Fig. 7.12: Cables and dummy grommets Page 84 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 85: Attaching The Cable Cover (Without Integrated Ups)

     Place 4 cylinder head screws ISO 4762-M4x10-A2 in the holes of the cable cover.  Loosely tighten the screws.  Then fully tighten the screws with 3 Nm torque crosswise. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 85 of 178...
  • Page 86: Attaching The Cable Cover (With Integrated Ups)

     Place 4 cylinder head screws ISO 4762-M4x10-A2 in the holes of the cable cover.  Loosely tighten the screws.  Then fully tighten the screws with 3 Nm torque crosswise. Page 86 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 87: Pressure Compensation Element

     Do not modify or remove the pressure compensation element; doing so would make the device leak and the IP protection would no longer be ensured. Fig. 7.15: Pressure compensation element - Do not modify or remove! Advantech-DLoG DLT-V83 Series Manual V1.31 Page 87 of 178...
  • Page 88: Power Supply Units, Pin Assignment, Power Supply

    Power supply units, pin assignment, power supply Power supply units, pin assignment, power supply Information in this chapter: Integrated DC power supply unit Integrated AC power supply unit Page 88 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 89: Integrated Dc Power Supply Unit

    Ignition on means that a control signal has to be routed to this connection (e.g., ignition of a vehicle), that matches the supply voltage level and is able to supply at least 1 W to the DLT-V83. The signal reference is DC-. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 89 of 178...
  • Page 90 Power consumption DLT-V8310 Typically 25 W; standby typically 1 W DLT-V8312 Typically 30 W; standby typically 1 W DLT-V8315 Typically 30 W;...
  • Page 91: Connections

    USB 2.0 interfaces (HI-SPEED™), bootable Expansion interfaces package 1 (optional) D I/O Digital In/Out RJ45 LAN Ethernet 10/100/1000 MBit/s Expansion interfaces package 2 (optional) CAN interface D I/O Digital In/Out RJ45 LAN Ethernet 10/100/1000 MBit/s Advantech-DLoG DLT-V83 Series Manual V1.31 Page 91 of 178...
  • Page 92: Dc Connection Cable (Power Supply Cable)

    NOTICE: Physical damage Use only original power supply cables from Advantech-DLoG. Advantech-DLoG power cables meet the specific requirements for low-temperature flexibility, UV resistance, oil resistance, etc. If other power supply cables are used: The user/operator of the industrial PC is solely responsible for the resulting damage.
  • Page 93: Fig. 8.4: Dc Connection Cable Assignment - Drawing

    Power supply units, pin assignment, power supply Fig. 8.4: DC connection cable assignment - drawing DC+ ; blue or grey wire Advantech-DLoG DLT-V83 Series Manual V1.31 Page 93 of 178...
  • Page 94: Integrated Ac Power Supply Unit

    There is no switch for the grid power. 8.2.1. AC power supply connection Connector for non-heating apparatus to IEC 320, 3-pin External view of the connector: Fig. 8.5: AC power connector with detail view Page 94 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 95: Ac Power Supply, Power Consumption

    Siba 179200.1 or similar produced by other manufacturers The symbol for the fuse is FA. You will find the exact position on the sticker located on the connection plate of the DLT-V83. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 95 of 178...
  • Page 96: Measurement Results Of The Power Consumption

    (SIQ ID 503; Calibration valid till 2015-07-01) 8.2.5. Special connection cable for AC device To facilitate achieving the lower power state:  Set the switch of the Advantech-DLoG power supply cable to Off. Page 96 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 97: Connections, Expansion Interfaces

    USB 2.0 interfaces (HI-SPEED™), bootable Expansion interfaces package 1 (optional) D I/O Digital I/O RJ45 LAN Ethernet 10/100/1000 Mbps Expansion interfaces package 1 (optional) CAN interface D I/O Digital I/O RJ45 LAN Ethernet 10/100/1000 Mbps Advantech-DLoG DLT-V83 Series Manual V1.31 Page 97 of 178...
  • Page 98: Angled Ac Power Cable

    Fig. 8.7: Angled AC power cable, original Advantech-DLoG NOTICE: Physical damage Use only angled AC power cables from Advantech-DLoG. These meet the specific requirements for low-temperature flexibility, UV resistance, oil resistance, etc. If other power cables are used, the user/operator of the industrial PC is solely responsible for any resulting damage.
  • Page 99: Service Usb And Sim Card Slot

    Information in this chapter: Opening/closing the service USB and SIM card slot Removing/attaching the antenna cap from/to the device Service USB interface Micro Bluetooth Adapter and Service USB SIM card slot Advantech-DLoG DLT-V83 Series Manual V1.31 Page 99 of 178...
  • Page 100: Opening/Closing The Service Usb And Sim Card Slot

    Fig. 9.1: Opened antenna cap Do not pull the antenna connection cables too far out of the unit; do not pinch or cut! Page 100 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 101: Removing/Attaching The Antenna Cap From/To The Device

     Take care not to pinch the antenna connection cables when doing this. The antenna cap seal must not be damaged; it must be seated correctly in the groove.  Reinsert and tighten the two screws of the antenna cap (1 Nm torque). Advantech-DLoG DLT-V83 Series Manual V1.31 Page 101 of 178...
  • Page 102: Service Usb Interface

    A plug connector with increased pull-out force was used for the service USB to meet the specific shock and vibration requirements.  Exercise special care when removing and re-inserting the micro Bluetooth adapter! Page 102 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 103: Sim Card Slot

    ATTENTION: Push in the SIM card tray exactly at the location provided. Otherwise, there is a risk of the tray and SIM card dropping into the device when pushing in the tray. Fig. 9.3: Opened SIM card slot under the antenna cap Advantech-DLoG DLT-V83 Series Manual V1.31 Page 103 of 178...
  • Page 104: Optional Equipment/Accessories

    Keyboards and keyboard mounts (optional) 10.16 External CD/DVD-ROM drive (optional) 10.17 USB recovery stick (optional) 10.18 Scanner and scanner bracket (optional) 10.19 Sun visor (optional) 10.20 Protective film for touchscreen (optional) Page 104 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 105: Defroster (Optional)

    10.1. Defroster (optional) The following DLT-V83 devices are available optionally with a defroster. − DLT-V8310 with 26 front keys and a resistive touchscreen − DLT-V8312 with 26 front keys and a resistive touchscreen Functional description As soon as the internal temperature of the DLT-V83 device falls below 0 °C, the defroster is automatically activated and heats the front of the device.
  • Page 106: Integrated Ups (Optional)

    0 to +45 °C (internal device temperature) Storage temperature -20 to +60 °C Maximum output power 35 W Input voltage 12 V Output voltage Typically 12 V Battery voltage 7.2 V Battery capacity 2200 mAh Page 106 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 107: Integrated Power Supply Unit (Optional)

    Available for all DLT-V83 devices with DC power supply unit: − Preconverter − DC power cable 12/24/48 VDC Available for the DLT-V8315 with AC power supply unit: − EU power cable, 110/220 VAC − US power cable, 110/220 VAC Advantech-DLoG DLT-V83 Series Manual V1.31 Page 107 of 178...
  • Page 108: Integrated Low Profile Wi-Fi Antenna (Optional)

    Band 1: 2400 to 2485 MHz Band 2: 5150 to 5875 MHz Antenna gain Max. 5 dBi (without loss through the cable) 50 Ω Impedance Polarization Vertical/Horizontal Maximum transmitting power 100 mW / 20 dBm Page 108 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 109: Integrated Wi-Fi Antenna (Optional)

    Band 1: 2400 to 2485 MHz Band 2: 5150 to 5875 MHz Antenna gain Max. 3 dBi (without loss through the cable) 50 Ω Impedance Polarization Vertical/Horizontal Maximum transmitting power 100 mW / 20 dBm Advantech-DLoG DLT-V83 Series Manual V1.31 Page 109 of 178...
  • Page 110: Integrated Wi-Fi, Wwan, And Gps Antenna (Optional)

    GSM1900: 1850 to 1990 MHz UMTS: 1920 to 2170 MHz Antenna gain Max. 3 dBi (without loss through the cable) 50 Ω Impedance Polarization Vertical/Horizontal Maximum transmitting power 100 mW / 20 dBm Page 110 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 111: External Wi-Fi Antenna, Remote (Optional)

    N type or TNC N, jack, female, bottom RSMA plug for RSMA socket on the terminal Scope of delivery 3 m antenna cable Maximum transmitting 100 mW / 20 dBm power Advantech-DLoG DLT-V83 Series Manual V1.31 Page 111 of 178...
  • Page 112: External Wwan Antenna, Remote (Optional)

    50 Ω Impedance Polarization Vertical/Horizontal Dimensions 33 mm x 89 mm Maximum transmitting Class 1, 4, E2* + typically 0 dBi (5 dBi) (antenna gain) power *specification taken from: www.sierrawireless.com (Feb 2015) Page 112 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 113: Wi-Fi Card (Optional)

    Integrated in the device at the factory by Advantech- DLoG (internal PCIe MiniCard slot). Driver Generally, only drivers for Wi-Fi cards approved by Advantech-DLoG can be integrated into operating system images. Maximum radiated power 100 mW EIRP 10.11. WWAN card (optional)
  • Page 114: Micro Bluetooth Adapter (Optional)

    Class 2 Micro Size Compatible with USB 2.0/1.1 Supports A2DP stereo transmission Compatible operating system Windows XP Windows Vista Windows 7 Linux optional Plug & Play Maximum transmitting power 2.5 mW Page 114 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 115: Gps Receiver (Optional)

    The GPS receiver has an integrated antenna for position data of the Global Positioning System (GPS) and communicates with the DLT-V83 via USB interface. Installation information is included with the GPS receiver. We recommend using only a GPS receiver approved by Advantech-DLoG. Fig. 10.7: GPS receiver (optional) Properties: −...
  • Page 116: Voice Kit (Optional)

    The handheld microphone is connected to the Audio/Mic interface of the DLT-V83. Please use only handsets from “OTTO Communications”. Please contact your Advantech-DLoG sales representative if needed. Fig. 10.8: Voice Kit microphone (optional) Configuring the Voice Kit under MS Windows To configure the voice kit, use the Control Panel menu Audio Settings.
  • Page 117: Keyboards And Keyboard Mounts (Optional)

    Optional equipment/accessories 10.15. Keyboards and keyboard mounts (optional) Any USB keyboard can be connected to the DLT-V83. Advantech-DLoG offers the following keyboards with protection class IP 65: A mountable SMALL keyboard with a protection class IP 65; available keyboard layouts: German, English, French: Fig.
  • Page 118: External Cd/Dvd-Rom Drive (Optional)

    CD/DVD-ROM, insert a bootable CD/DVD and start the system. 10.17. USB recovery stick (optional) The optional Advantech-DLoG recovery stick allows images to be backed up and restored onto the DLT-V83 when necessary (backup & recovery). 10.18. Scanner and scanner bracket (optional) You can connect scanners to either the USB interface or the serial interface.
  • Page 119: Sun Visor (Optional)

    Optional equipment/accessories 10.19. Sun visor (optional) Sun visors are available for the devices DLT-V8310 and DLT-V8312. Fig. 10.12: DLT-V83 with sun visor Technical data Material Aluminum, powder coated Weight of sun visor DLT-V8310 300 g Weight of sun visor DLT-V8312...
  • Page 120: Protective Film For Touchscreen (Optional)

     Position the protective film with the adhesive side facing downwards tight at one corner of the viewing window.  Carefully press on the foil.  Then using a wiper (wooden wiper) to push out any air bubbles to the corners. Page 120 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 121: Serial Interfaces

    COM1 as a voltage source (optional) 11.2 COM2 as EIA-422/485 (optional) 11.3 Network adapter (10/100/1000) 11.4 CAN, digital I/O and second Ethernet interface (optional) 11.5 Serial interface barcode scanners 11.6 Tips & tricks Advantech-DLoG DLT-V83 Series Manual V1.31 Page 121 of 178...
  • Page 122: Com1 As A Voltage Source (Optional)

    Depending on the connected devices, the maximum current consumption may be significantly lower. 11.2. COM2 as EIA-422/485 (optional) A basic function (RX, TX) EIA-422/485 interface can be integrated optionally into the DLT-V83 as serial interface. Pin assignment 4xx: Signal Signal Page 122 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 123: Network Adapter (10/100/1000)

    100 m given in the specification (IEEE 802.3 standard). The solution here is the use of a shorter cable. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 123 of 178...
  • Page 124: Can, Digital I/O And Second Ethernet Interface (Optional)

    The CAN interface is galvanically separated from the overall system. A matching driver is integrated in the operating system. An API description is available upon request. Contact your Advantech-DLoG sales representative if necessary. Fig. 11.3: Pin assignment of CAN interface...
  • Page 125: Digital I/O Interface

    The Digital I/O interface is galvanically separated from the overall system. A matching driver is integrated in the operating system. An API description as well as sample application are available upon request. Contact your Advantech-DLoG sales representative if necessary. Pin assignment:...
  • Page 126: Network Adapter 2, Ethernet (10/100/1000)

    LED off: no connection or 10/100 MBit or 1000 MBit LED on: Connection with 1000 MBit LED on: Connection with 10 or 100 MBit LED flashing: Activity 1000 MBit LED flashing: Activity 10/100 MBit Page 126 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 127: Serial Interface Barcode Scanners

    232-E connection, may significantly degrade signal quality and effectively stop the data flow. In challenging environments, electrically-isolated connections (via the RS-422/485 option) or external converter from EIA-232-E according to EIA-422/485 are strongly recommended. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 127 of 178...
  • Page 128: Automatic Shut Down

    Automatic shut down Automatic shut down Information in this chapter: 12.1 Functional description 12.2 Sequence 12.3 Configuration Page 128 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 129: Functional Description

    Once the shut-off delay (afterrun time) has elapsed, the operating system will shut down and the device will automatically shut down (e.g. after three minutes or a signal from the operating system). Advantech-DLoG DLT-V83 Series Manual V1.31 Page 129 of 178...
  • Page 130: Configuration

    The DLoG Config program is used for the configuration of the automatic shut down under MS Windows. The manual with the same name can be found online in the download center at www.advantech-dlog.com. The configuration under Linux is explained in the Linux manual and is also available in the download center (after login).
  • Page 131: Cleaning The Device

    Cleaning the device Cleaning the device Information in this chapter: 13.1 Cleaning the housing 13.2 Cleaning the touchscreen Advantech-DLoG DLT-V83 Series Manual V1.31 Page 131 of 178...
  • Page 132: Cleaning The Housing

     Do not use compressed air, a high-pressure cleaner or vacuum cleaner, as this can damage the surface. Using a high-pressure cleaner poses the additional risk of water entering the device and damaging the electronics or display. Page 132 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 133: Cleaning The Touchscreen

     Do not use cleaning agents that contain ammonia or sulfur (tile cleaners, for example, contain ammonia).  Do not use any abrasive glass cleaner or cloths that could scratch the touchscreen. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 133 of 178...
  • Page 134: Technical Data

    USB, Service-USB 14.10 LCD interface 14.11 Touch interface 14.12 Network interface 14.13 Audio interface for handset 14.14 Internal speaker, sound 14.15 Integrated UPS (optional) 14.16 Device dimensions 14.17 VESA drill holes Page 134 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 135: Cpu, Chipset, Ram, Bios, Cfast, Ssd

    Optional, > 4 GB, based on SLC technology (single level cell) 14.2. Housing, material, weight Material Rugged aluminum-cast housing, ESD safe Weight DLT-V8310: 4 kg DLT-V8312: 5.5 kg DLT-V8315: 6.4 kg Dimensions See Chapter 14.16 Device dimensions Advantech-DLoG DLT-V83 Series Manual V1.31...
  • Page 136: Display

    Technical data 14.3. Display DLT-V8310 10.4“ SVGA 800 x 600 400 cd/m Brightness control 10,4“ XGA 1024 x 768 500 cd/m² Brightness control DLT-V8312 12.1" XGA 1024 x 768 500 cd/m Brightness control DLT-V8315 15" XGA 1024 x 768 400 cd/m...
  • Page 137: Environmental Conditions

    EN 60068-2-3 Mechanical vibration Class 5M3 according to EN 60721-3-5 and shock resistance US Highway Truck according to MIL-STD 810F For details, see section 10.2 Integrated UPS (optional). Advantech-DLoG DLT-V83 Series Manual V1.31 Page 137 of 178...
  • Page 138: Resistive Touchscreen

    Technical data 14.5. Resistive touchscreen 14.5.1. Standard version Available for the devices: − DLT-V8310 − DLT-V8312 − DLT-V8315 DLT-V8310 Type 4-wire analog resistive touchscreen Construction Device without defroster: Film-Film-Glass (FFG), fully laminated front Device with defroster: Buffer-film-film-glass heater Resistance Chemically hardened glass...
  • Page 139: Version Suitable For Use In Sunlight (Optional)

    Technical data 14.5.2. Version suitable for use in sunlight (optional) Optionally available for the devices: − DLT-V8310 SVGA − DLT-V8312 Type 5-wire analog resistive touchscreen Construction Film-Glass (FG), chemically toughened glass Hardness of surface JIS-K-5400: 1 H at 750 g...
  • Page 140: Operating Systems (Optional)

    Windows Embedded 8 Standard ® Windows Embedded 8.1 Industry Pro Linux Advantech-DLoG Linux-Image, based on Debian 14.8. Serial interfaces COM1 Max. 115,200 Baud (16550A compatible, 16 byte FIFO), supports EIA-232-E on external 9-pin D-Sub connection ESD Level 4 protected (according to EN 61000-4-2)
  • Page 141: 14.10. Lcd Interface

    PCT touch controller 10": X21-Y28 channel PCT controller with USB interface and Advantech-DLoG-specific firmware; 12" and 15": X52-Y40 channel PCT controller with USB interface and Advantech-DLoG-specific firmware 14.12. Network interface ® Network controller Intel 82567V Gigabit Ethernet 10/100/1000 MB/s...
  • Page 142: 14.14. Internal Speaker, Sound

    The internal speaker is configured in the audio settings for the operating system in question. Fig. 14.1: Internal speaker 14.15. Integrated UPS (optional) For details about the uninterruptible power supply, see section 10.2 Integrated UPS (optional). Page 142 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 143: 14.16. Device Dimensions

    Technical data 14.16. Device dimensions 14.16.1. DLT-V8310 Front view Dimensions without add-ons (in mm) Fig. 14.2: Dimensions DLT-V8310 front side Advantech-DLoG DLT-V83 Series Manual V1.31 Page 143 of 178...
  • Page 144: Fig. 14.3: Dimensions Dlt-V8310 With Standard Resistive Touchscreen, Side View

    Technical data DLT-V8310 Side view Dimensions without add-ons (in mm) Example: Fig. 14.3: Dimensions DLT-V8310 with standard resistive touchscreen, side view The installation depth of the devices varies depending on the type of touchscreen: Device type Building depth (side view)
  • Page 145: Fig. 14.4: Dimensions Dlt-V8310 Standard Resistive Touchscreen, Top View

    Technical data DLT-V8310 Top view Dimensions without add-ons (in mm) Example: Fig. 14.4: Dimensions DLT-V8310 standard resistive touchscreen, top view The installation depth of the devices varies depending on the type of touchscreen: Device type Building depth DLT-V8310 standard resistive touchscreen...
  • Page 146: 14.16.2. Dlt-V8312

    Technical data 14.16.2. DLT-V8312 Front view Dimensions without add-ons (in mm) Fig. 14.5: Dimensions DLT-V8312 front view Page 146 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 147: Fig. 14.6: Dimensions Dlt-V8312 Standard Resistive Touchscreen, Side View

    The installation depth of the devices varies depending on the type of touchscreen: Device type Building depth (side view) DLT-V8312 standard resistive touchscreen 93.5 mm (see figure) DLT-V8312 sunlight readable resistive touchscreen 95.1 mm DLT-V8312 PCT touchscreen 96.4 mm Advantech-DLoG DLT-V83 Series Manual V1.31 Page 147 of 178...
  • Page 148: Fig. 14.7: Dimensions Dlt-V8312 Top View

    The installation depth of the devices varies depending on the type of touchscreen: Device type Building depth (side view) DLT-V8312 standard resistive touchscreen 93.5 mm (see figure) DLT-V8312 sunlight readable resistive 95.1 mm touchscreen DLT-V8312 PCT touchscreen 96.4 mm Page 148 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 149: 14.16.3. Dlt-V8315

    Technical data 14.16.3. DLT-V8315 Front view Dimensions without add-ons (in mm): Fig. 14.8: Dimensions DLT-V8315 front side Advantech-DLoG DLT-V83 Series Manual V1.31 Page 149 of 178...
  • Page 150: Fig. 14.9: Dimensions Dlt-V8315 Side View (Standard Resisitive Touchscreen)

    The installation depth of the devices varies depending on the type of touchscreen: Device type Building depth (side view) DLT-V8315 standard resistive touchscreen 98 mm (see figure) DLT-V8315 PCT Touchscreen 97 mm Page 150 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 151: Fig. 14.10: Dimensions Dlt-V8315 Top View (Standard Resisitive Touchscreen)

    The installation depth of the devices varies depending on the type of touchscreen: Device type Building depth (side view) DLT-V8315 standard resisitive touchscreen 98 mm (see figure) DLT-V8315 PCT touchscreen 97 mm Advantech-DLoG DLT-V83 Series Manual V1.31 Page 151 of 178...
  • Page 152: 14.17. Vesa Drill Holes

    VESA-compatible drilling patterns for the RAM attachment and swivel joint brackets are located on the rear side of the DLT-V83. 14.17.1. DLT-V8310 Dimensions without add-ons (in mm): Fig. 14.11: Position of the VESA drill holes DLT-V8310 Depth of thread: M6 x 6mm. Page 152 of 178 DLT-V83 Series Manual V1.31...
  • Page 153: 14.17.2. Dlt-V8312

    Technical data 14.17.2. DLT-V8312 Dimensions without add-ons (in mm): Fig. 14.12: Position of the VESA drill holes DLT-V8312 Depth of thread: M6 x 6mm. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 153 of 178...
  • Page 154: 14.17.3. Dlt-V8315

    Technical data 14.17.3. DLT-V8315 Dimensions without add-ons (in mm): Fig. 14.13: Position of the VESA drill holes DLT-V8315 Depth of thread: M6 x 6mm. Page 154 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 155: Malfunctions

    / no reception another location for testing No Internet No SIM card is Insert SIM card into SIM slot connection installed. / incorrect / request access number access number from provider Advantech-DLoG DLT-V83 Series Manual V1.31 Page 155 of 178...
  • Page 156: Reasonably Foreseeable Misuse

    16.3. Stationary use with AC power supply unit − Please observe that the switch of the Advantech-DLoG power supply cable must be set to On in order to be able to start the DLT-V83. Page 156 of 178 DLT-V83 Series Manual V1.31...
  • Page 157: Guidelines And Certificates

    17.2 EMC guidelines 17.3 RoHS Directive 17.4 R&TTE EC Directive 1999/5/EC 17.5 Ecodesign directive (2009/125/EC) 17.6 CE marking 17.7 CCC, SRRC China 17.8 MIC Japan (previously TELEC) 17.9 Declaration of conformity Advantech-DLoG DLT-V83 Series Manual V1.31 Page 157 of 178...
  • Page 158: Low-Voltage Guidelines

     Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. Page 158 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 159: Ices Canada

    We hereby confirm the conformity of our products compliant with the RoHS Directive 2011/65/EU of the European Parliament and Council of June 8, 2011 on the restriction of the use of hazardous substances in electrical and electronic equipment. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 159 of 178...
  • Page 160: R&Tte Ec Directive 1999/5/Ec

    Este equipamento está em conformidade com os requisitos [Portuguese]: essenciais e outras provisões relevantes da Directiva 1999/5/EC. Slovensko Ta naprava je skladna z bistvenimi zahtevami in ostalimi [Slovenian]: relevantnimi pogoji Direktive 1999/5/EC. Page 160 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 161: Ecodesign Directive (2009/125/Ec)

    Ecodesign directive (2009/125/EC) DLT-V83 industrial PCs with an AC power supply unit meet the requirements of the Ecodesign directive (2009/125/EC), which prescribes environmentally friendly design for products involved in energy consumption. Advantech-DLoG DLT-V83 Series Manual V1.31 Page 161 of 178...
  • Page 162: Ce Marking

    Fig. 17.1: CE label on the DLT-V83 17.7. CCC, SRRC China The following devices are CCC- and SRRC-certified: − DLT-V8310 and DLT-V8312 with Advantech-DLoG low-profile antenna. − DLT-V8310 and DLT-V8312 with Advantech-DLoG remote antenna. 17.8. MIC Japan (previously TELEC) In several of the DLT-V83 series, the PE15N PCI Express Mini Card from Laird is used.
  • Page 163: Declaration Of Conformity

    Guidelines and certificates 17.9. Declaration of conformity Advantech-DLoG DLT-V83 Series Manual V1.31 Page 163 of 178...
  • Page 164: End-Of-Life Device Disposal

     Please contact the responsible authorities in your country/region about the applicable regulations, if necessary. Technical customer support If you experience technical difficulties, please consult your distributor or contact the technical services department at Advantech-DLoG’s headquarters: Phone: (+49) 89 / 41 11 91 999 email: helpdesk@dlog.com...
  • Page 165: Return Shipment Form

    [ ] Unit was already damaged on delivery (please enclose a copy of the delivery note) [ ] Delivery was incomplete Missing parts: [ ] The following error occurs when operating the unit: [ ] Separate error report is enclosed Advantech-DLoG DLT-V83 Series Manual V1.31 Page 165 of 178...
  • Page 166: Table Of Figures

    Fig. 3.1: Name plate, example ..........................26 Fig. 5.1: <Power> button of the DLT-V83 ......................... 32 Fig. 5.2: Operating elements on the DLT-V8310, 26 front keys, resistive touchscreen ..........35 Fig. 5.3: Operating elements front side DLT-V8310 with PCT touchscreen ............. 40 Fig.
  • Page 167 Fig. 14.1: Internal speaker ............................. 142 Fig. 14.2: Dimensions DLT-V8310 front side ......................143 Fig. 14.3: Dimensions DLT-V8310 with standard resistive touchscreen, side view ..........144 Fig. 14.4: Dimensions DLT-V8310 standard resistive touchscreen, top view ............145 Fig. 14.5: Dimensions DLT-V8312 front view ......................146 Fig.
  • Page 168: Index

    Backup & recovery ............... 45, 118 Band 1 ..................108, 109, 110, 111 Band 2 ..................108, 109, 110, 111 Barcode scanners ................ 127 Battery ..................18, 75, 76, 156 Battery capacity ................13, 106 Page 168 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 169 Cleaning the touchscreen ............133 Cling wrap ..................30 Cold stores ................... 105 Color depth ................... 141 COM1 ................... 122, 140 COM1 as a voltage source ............122 COM2 ................... 122, 140 Advantech-DLoG DLT-V83 Series Manual V1.31 Page 169 of 178...
  • Page 170 Digital I/O ..................64, 124, 125 Dimensions of the device ............. 143 Disconnecting device ..............16, 74 Disconnecting from the electric power source ......15, 16, 72 Disconnecting switch ..............77 Display ..................66, 136 Page 170 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 171 Externally supplied devices ............76, 78 FA 90, 95 FCC requirements ................ 159 FCC USA ..................158 Film ....................70 Fingers ..................33 Flash ..................... 45 Forklift applications ..............75 Forklift chassis................75 Advantech-DLoG DLT-V83 Series Manual V1.31 Page 171 of 178...
  • Page 172 Idle Mode ..................96 IEEE 802.11 standard ..............48 Ignition ..................89, 129 Ignition connecting cable .............. 74 Ignition input ................. 129 Ignition signal ................39 iManager ..................65 Impedance ..................108, 109, 110 Page 172 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 173 Manufacturer address ..............164 Material ..................135 Maximum output power UPS ............13, 106 Memory effect................66 MIC Japan ..................162 Micro Bluetooth Adapter ............... 102 Microphone input ................141 Microsoft OS................. 140 Advantech-DLoG DLT-V83 Series Manual V1.31 Page 173 of 178...
  • Page 174 PCT ....................33, 34, 139 PCT touchscreen operation ............34 Peripheral devices ................ 72, 75, 76, 78 Phoenix contact connector ............74 PhoenixCombicon, 3-pin .............. 89 Physical damage ................72, 92 Page 174 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 175 Repacking ..................30 Resistance ..................138 Resistive touchscreen ..............33, 138 Resources of the serial interfaces ..........122 Return shipment form ..............165 Returning your device ..............30 Ring tongues ................75 Advantech-DLoG DLT-V83 Series Manual V1.31 Page 175 of 178...
  • Page 176 Sound ................... 142 Speaker ..................116, 142 Special keys ................. 37, 42 SRRC ................... 162 SSD ....................135 Standby power consumption ............67 Standby typical ................90 Start phase ................... 129 Page 176 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...
  • Page 177 USB-CD-ROM ................118 Vacuum cleaner ................132 Vapors ..................18 Vehicle applications ..............75 Vehicle battery................18 Vehicle ignition ................46 Vehicle manufacturer ..............75 VESA drill holes ................152, 153, 154 Advantech-DLoG DLT-V83 Series Manual V1.31 Page 177 of 178...
  • Page 178 Wireless, connection cable ............47 WM_QUERYENDSESSION ............130 WWAN ..................52 WWAN 3G-Technology ..............112 WWAN and GPS antenna ............110 WWAN antenna ................112 WZC ..................... 48, 51 XGA ....................136 Page 178 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG...

This manual is also suitable for:

Dlt-v8312Dlt-v8315

Table of Contents
