SPECIFICATIONS

System specifications are included in Table Section 1-9.
Item
Dimensions and Weight
Keyboard
Device Slots
Expansion Slots
Peripheral Interface
Front Panel
Processor
Cache Memory
Flash ROM
Chip Set
System Memory
Standard
Multimedia,
Multimedia/Network and
1.2 GB Hard Disk Systems
Optional SIMMs
Integrated Graphics
Table Section 1-9 Specifications
Specification
Width: 17 inches (43.18 cm)
Depth: 16 inches (40.64 cm)
Height: 4 inches (10.6 cm)
Weight: 22 lb (11.1 kg) (dependent upon options)
Width: 19.0 inches (48.3 cm)
Depth: 8.4 inches (21.3 cm)
Height: 1.6 inches (4.1 cm)
Weight: 3.5 to 4.0 lb. (1.6 to 1.8 kg)
Two 5 1/4-inch, front accessible slots
One 3 1/2-inch front access slot
One 3 1/2-inch internal slot
Four slots:
two 16-bit ISA slots
one ISA/PCI shared slot
one PCI slot
PS/2-style keyboard connector, rear panel
PS/2-style mouse connector, rear panel
Two RS-232C serial ports, rear panel
Parallel printer port, rear panel
VGA port, rear panel
Power button
Power indicator lamp
Hard disk drive busy indicator lamp
Suspend button
Reset button
Intel Pentium 75- or 100-MHz (dependent on system)
16 KB of primary cache (8 KB data, 8 KB instruction) integrated
in the processor, optional 256 KB secondary cache
128 KB (28F001) Flash ROM
SiS5511+/5512/5513 PCI/ISA
8-MB EDO standard, expandable to 128 MB using SIMM sockets
16-MB EDO standard, expandable to 128 MB using SIMM
sockets
4-, 8-, 16-, and 32-MB; 32-bit, non-parity, 70-ns SIMMs
SiS 6205 PCI Graphics & Video Accelerator
1-MB video DRAM standard, expandable to 2 MB
Technical Information 1-23
