3-28 Option Installation
Replace the drive bracket (see "Replacing the 3 1/2-Inch Drive Bracket").
8.

Replacing the Front Panel

Replace the front panel as follows.
Align the four front panel tabs with the holes in the front of the system unit.
1.
2. Evenly press the front panel into position until the tabs lock the panel in place
(see Figure Section 3-37).
Tabs
(behind front panel)
3. Continue to Step 5 in "Replacing the 3 1/2-Inch Drive Bracket."
Figure Section 3-35 Securing the Device
Front Panel
Figure Section 3-37 Aligning the Front Panel
Two of Four
Screws
Blank Panel
Tabs
(behind front panel)
