A-6 Connector Pin Assignments

VGA INTERFACE CONNECTOR PIN ASSIGNMENTS

Video signals are output from the system board through a VGA interface connector, which
is a 15-pin, D-subconnector (VESA VS890803-2) located at the rear of the system unit.
Table Appendix A-6 and Figure Appendix A-6 shows the connector pin locations and pin
assignments.
Table Appendix A-6 VGA Interface Connector Pin Assignments
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Figure Appendix A-6 VGA Interface Connector
Signal
Red
Green
Blue
Monitor ID bit 2 (not used)
Ground
Red return (ground)
Green return (ground)
Blue return (ground)
Key (no pin)
Sync return (ground)
Monitor ID bit 0 (not used)
Monitor ID bit 1 (not used)
Horizontal sync
Vertical sync
Not used
