RS-232C Device Connection

Turn off power to the system and to the serial device.
1.
Connect one end of the serial cable to one of the two serial ports on the rear of
2.
the computer (see Figure Section 3-43).
3. Secure the cable with the screws provided.
4. Connect the other end to the serial device.
Figure Section 3-43 Connecting an RS-232C Cable to the Desktop
NOTE: Before connecting a serial device to the
system, be sure the serial device is set up
correctly. Follow the setup instructions that
come with the option.
Option Installation
Serial Port 1
Serial Cable
Screws
3-31
