A-2 Connector Pin Assignments
Function
VGA Monitor
Microphone In
Speaker In
Line In
Line Out
Parallel Interface
Serial Interface COM1/COM2
Mouse
Keyboard
Diskette Drive
Power Supply
SIMM Memory Sockets
PCI/IDE Interface (primary)
IDE Interface (secondary)
Secondary Cache Module
Fan
Infrared (IRDA)
Suspend Button
Hard disk LED
Power LED
Reset Button
Speaker
ISA/PCI-Bus Backboard
Video Feature
Table Appendix A-1 System Board Connectors
Connector Number
J3
J19
PJ2
J17
J26
J16
J9, J10
J8
J4
J5
J1
SIMM 1, 2, 3, 4
J7
J6
J35
J13
J30
J6
J25
J23
SLOT1
J2
Type
15 pin female sub D-shell
1/8-Inch banana connector
1/8-Inch banana connector
1/8-Inch banana connector
1/8-Inch banana connector
25 pin female sub D-shell
9 pin D-shell
6-pin PS/2 style connector
6-pin PS/2 style connector
2 x 17 pin header
1 x 12 pin locking header
72 pin single inline connector
2 x 20 pin header
2 x 20 pin header
160-pin single inline connector
1 x 3 pin header
1 x 4 pin header
1 x 2 pin header
1 x 4 pin header
1 x 5 pin header
1 x 4 pin header
1 x 4 pin header
98-pin header
2x13 pin header
