To load a disc in the CD-ROM reader, follow these steps.
Press the open/close button. The CD tray opens.
1.
Put the CD, printed side up, into the tray.
2.
3. Press the open/close button again and the tray closes.
4. To remove the disc, press the open/close button. The tray opens, allowing
removal of the disc.

SYSTEM CONFIGURATION

This section describes the Setup utility program that allows the system configuration
information to be viewed and changed.
System configuration information is stored in nonvolatile memory. Nonvolatile memory in
the system is a complementary metal-oxide semiconductor (CMOS) chip backed by a coin-
type battery on the system board. The battery supplies continuous power to the CMOS
memory and maintains configuration information when system power is off.

Setup Utility

The Setup utility is used to view and set system parameters. Use the Setup utility to:
n
set the time and date.
n
update or check system parameters when adding or removing expansion options.
n
change or set power management features.
n
correct a hardware discrepancy when the Power-On-Self-Test (POST) displays an
error message and a prompt appears to run Setup.
n
check the installation of optional memory by comparing the amount of memory
installed with the amount of memory displayed by Setup.
n
change certain system operating parameters, such as boot device sequence or
keyboard parameters.
NOTE: The system ships from the factory with
the correct system parameters for the
configuration. Unless setting the time and date,
setting security features, customizing the system,
or adding optional hardware, Setup does not
need to be run.
Setup and Operation 2-7
