Power Supply Removal

Remove the power supply from the system unit as follows.
1. Remove the system unit cover and front panel as previously described.
2. Unplug the two power cables attached to the system board's connectors.
Unplug the power cables from all installed devices.
3.
Remove the two screws securing the power button to the front of the system unit
4.
(see Figure Section 5-23).
Remove the four screws holding the power supply to the system unit (see
5.
Figure Section 5-25).
Figure Section 5-23 Power Button Screws
System Unit Repair
Power Button
Screws
5-11
