5 Operation | 5.6 Setting Up for Transmitted Light Techniques
Procedure
1. Swivel the PlasDIC compatible objective into
2. Fully open the aperture diaphragm of the con-
3. Place the sample on the stage.
4. Rotate the condenser position with the slit di-
5. If required, increase the illumination brightness.
98
the beam path.
denser.
aphragm for PlasDIC into the beam path.
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
