5 Operation | 5.6 Setting Up for Transmitted Light Techniques
5.6 Setting Up for Transmitted Light Techniques
5.6.1 Setting Up for Transmitted Light Brightfield Microscopy
Every microscope with transmitted light illumination is configured to work with the transmitted
light brightfield (TL) method.

Parts and Tools
ü
Prerequisite
ü
Procedure 1. If required, push the
2. Move the brightfield position of the condenser
3. Place the sample on the stage.
4. Swivel in the 10x objective on the nosepiece
5. Focus the sample.
92
Condenser for TL brightfield
The microscope is operational.
The focus stop is adjusted [
TL
light illumination.
slider/turret into the beam path.
into the beam path.
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
}
87].
button for transmitted
