Zeiss Axiovert 5 Instruction Manual page 91

ZEISS
2. Turn the condenser 90° in the slot until it snaps
3. Allow the locking ring to slide downward.
4. Turn the locking ring of the quick-action lock-
5.5 Moving the Condenser
NOTICE
Property damage due to collision of condenser and carrier for transmitted
light illumination.
Condensers with modulator disk can collide with the carrier for transmitted light illumination
when moving the condenser.
4
ü
Prerequisite
Procedure 1. If required, rotate the condenser [
2. Grab the adapter ring.
3. Carefully push the condenser backwards.
4. Insert the large sample.
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
into place.
ing mechanism to the right.
à
The quick-action locking mechanism is locked.
Rotate condensers with modulator disk so that the modulator disk is either on the right or
on the left side before moving them.
The condenser is installed [
}
74].
}
90].
5 Operation | 5.5 Moving the Condenser
91
