10 Accessories and Optional System Expansions | 10.4 Sliders for Reflected Light and Fluorescence
9. Attach one end of the drainage tube to the collecting trough's drainage connector.
10. Put the drainage tube's other end through the collecting bottle's plug, such that the tube
11.
12. Attach the Velcro® fastener to the stand.
13. Fix the collecting bottle with the Velcro® fastener to the stand.
14. Install the stage.
Proceed in the reverse order for removal.
NOTICE
Performance impairment by liquids
Residues of accidents involving liquids are very likely to impair the performance of optical
parts.
4
4
Cleaning instructions can be found in the brochure "The Clean Microscope".
See also
2
10.4 Sliders for Reflected Light and Fluorescence
The present section applies to the following microscope types:
§
§
§
§
§
10.4.1 Filter Slider A 14x40 mm, 2 Positions and Filter Slider A 14x40 mm, 3 Positions
Purpose The filter slider A can be used for the following RL contrast techniques:
§
§
§
§
Function The filter slider A is used for light and neutral density filters for reflected light with d = 25 mm.
The following filter types can be used:
§
§
Because of an already mounted metal plate the filter slider A is also usable as manual shutters for
epi-fluorescence.
Position The filter slider A is inserted into the 14x40 mm slot marked F on the stand.
154
protrudes about 4 mm below the plug.
NOTICE Adjust the drainage tube such that it will not be bent through focusing.
Firmly insert the plug into the collecting bottle.
After any accident involving liquids, remove the stage and soak up every drop of liquid
from the optics and the nosepiece with a lint-free cloth.
Pay special attention to cleaning the front lens of the objective!
Assembling Objectives [}
Axiovert 5 TL FL SCB
Axiovert 5 RL SCB
Axiovert 5 RL TL SCB
Axiovert 7 RL
Axiovert 7 RL TL
brightfield
DIC
C-DIC
polarization contrast
grey filters that only reduce the intensity of the light
conversion filters for adapting the LED light to the color impression of halogen light
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
