4.7.4 Assembling the Scanning Stage 130x85 mot P; CAN

1
2
3
Fig. 43: Installing the scanning stage 130x85 mot P; CAN
1
3

Parts and Tools
Info
The Scanning stage 130x85 mot P; CAN is not compatible with the Aqua stop II.
Info
For more information on electronic connection of the scanning stage, refer to its operating
manual.
ü
Prerequisite
ü
Procedure
1. Set down the stage
2. Fix the stage to the stand with a screw
3. Connect the joystick, trackball or coaxial drive to the scanning stage.
4. Connect the stage to the user PC via CAN cable and CAN-USB converter.
5. From the stage's bottom side, remove the transport securing pin.
6. For positioning of the sample, place the mounting frame K, low profile or the mounting
NOTICE
Damage due to mechanical shocks
Transporting the stage without transport securing pin may impair with the stage's functioning
or even damage the stage.
4
Proceed in the reverse order for removal.
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
Scanning stage
Mounting hole (3x)
Hex Key, 3.0 mm
The stage's travel range has been adjusted as required [
The nosepiece is in the lowest position.
1
3
.
frame for steel samples in the opening of the stage.
Always screw in the transport securing pin before transporting the stage or storing it
away.
2
on the stand, matching its mounting holes to those of the stand
2
in each of the stage's three mounting holes.
