5 Operation | 5.9 Operating the Microscope via the On Screen Display (OSD) Menu
5.9.2.1 Acquiring a Single Image
ü
Prerequisite
ü
Procedure 1. Click on the Snap button.
2. Click on the preview.
3. Click on the image name.
4. Enter a new name for the image.
5. Click on the button
Info
The Configure File Name Template button opens another template in which presettings for
naming the files can be made.
122
The microscope is operational.
The Single Image (Snap) acquisition mode is active.
à
A single image is captured and a preview is displayed on the bottom right side of the
screen.
à
The image opens and is displayed enlarged.
à
A window opens in which the file name can be entered.
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
to save the changes.
