4.7.2 Assembling the Mechanical Stage 130x85 R/L
Info
Depending on your preferences, the stage can be mounted with the drive on the right- or the
left-hand side.
1
2
3
Fig. 42: Installing the mechanical stage 130x85 R/L
1
3

Parts and Tools
ü
Prerequisite
Procedure 1. Take the stage and position it according to your preferences.
2. Set down the stage
3. Fix the stage to the stand with a screw
4. Continue with Assembling the Mounting Frame K [
Proceed in the reverse order for removal.
4.7.2.1 Assembling the Mounting Frame K
ü
Prerequisite
Procedure 1. Place the mounting frame on the stage. Make sure its red-dotted corner matches the red-
2. Diagonally press the mounting frame against the springs and into the stage's opening.
3. Verify that the mounting frame is seated correctly.
Proceed in the reverse order for removal.
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
Mechanical stage
Mounting hole (3x)
Hex Key, 3.0 mm
The nosepiece is in the lowest position.
1
3
.
The stage is fixed to the stand.
dotted corner of the stage.
2
on the stand, matching its mounting holes to those of the stand
2
in each of the stage's three mounting holes.
4 Installation | 4.7 Assembling the Stage
Fixing screw (3x)
}
71].
