Table of Contents
4 Installation ..................................................................................... 64
4
3.3
Light Manager Function ..................................................................................... 53
3.4
ECO Mode.......................................................................................................... 54
3.5
Microscopy and Contrast Techniques ................................................................. 54
3.5.1
Transmitted Light Brightfield Microscopy............................................... 54
3.5.2
Transmitted Light Phase Contrast Microscopy ....................................... 54
3.5.3
Transmitted Light Differential Interference Contrast Microscopy............ 55
3.5.4
Transmitted Light PlasDIC Microscopy ................................................... 55
3.5.5
Transmitted Light iHMC ........................................................................ 55
3.5.6
Transmitted Light Polarization ............................................................... 55
3.5.7
Reflected Light Brightfield Microscopy Using the KÖHLER Method ........ 55
3.5.8
Reflected Light Darkfield Microscopy Using the KÖHLER Method .......... 55
3.5.9
Reflected Light DIC and C-DIC Microscopy ............................................ 56
3.5.10 Reflected Light Polarization Microscopy................................................. 56
3.5.11 Reflected Light Fluorescence Microscopy............................................... 56
3.5.12 Reflected Light TIC Microscopy.............................................................. 56
3.6
Operating Modes ............................................................................................... 59
3.6.1
Stand-Alone Operation (without PC) via On Screen Display.................... 59
3.6.2
Operation via Labscope ......................................................................... 60
3.6.3
Operation via ZEN on PC ....................................................................... 63
4.1
Unpacking and Setting up the Microscope ......................................................... 64
4.2
Removing the Transportation Lock ..................................................................... 64
4.3
Assembling the Ergo Intermediate Piece ............................................................. 65
4.4
Assembling the Binocular Tube........................................................................... 66
4.5
Assembling Components into the Binocular Tube ............................................... 67
4.6
Assembling Objectives........................................................................................ 67
4.6.1
Assigning Objectives.............................................................................. 68
4.7
Assembling the Stage ......................................................................................... 69
4.7.1
Assembling the Specimen Stage 232x230 ............................................. 69
4.7.2
Assembling the Mechanical Stage 130x85 R/L ....................................... 71
4.7.3
Assembling the Mechanical Stage 40x40 R/L, Reflected Light ................ 72
4.7.4
Assembling the Scanning Stage 130x85 mot P; CAN ............................. 73
4.8
Assembling the Condenser ................................................................................. 74
4.9
Assembling the Light Shield................................................................................ 75
4.10
Assembling a Contrast Module to the Condenser with Modulator Disk............... 75
4.11
Loading the 6-Position Reflector Turret............................................................... 77
4.11.1 Assembling Reflector Modules .............................................................. 77
4.11.2 Assigning Reflector Modules ................................................................. 78
4.11.3 Exchanging the Filters of a Reflector Module FL P&C ............................. 78
4.11.4 Exchanging the Beam Splitter of a Reflector Module FL P&C.................. 80
4.12
Assembling the Reflected Light LED 10W Light Source ....................................... 81
4.13
Assembling the Colibri 3 LED Light Source.......................................................... 83
4.14
Connecting the Microscope to the Mains ........................................................... 85
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
