4.9 Assembling the Light Shield

Parts and Tools
Procedure 1. Attach the ring to the condenser.
2. Tighten the screws to fix the ring.
3. Hold the light shield with the kinked piece facing upwards.
4. Attach the light shield to the condenser.
5. Adjust the light shield to the indicated position marked on it.
6. When not in use, place the light shield under the microscope. It can be pulled out at the
4.10 Assembling a Contrast Module to the Condenser with Modulator Disk
The present section applies to the following components:
§
§
The following modules can be assembled to the condenser:
§
§
§
§
§

Parts and Tools

ü
Prerequisite
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
Hex Key, 2.5 mm
à
The light shield is held by magnets.
side brim.
LD Condenser 0.4 for H Ph PlasDIC DIC iHMC [
LD Condenser 0.55 for H Ph PlasDIC DIC [
Phase stop Ph
Slit diaphragm PlasDIC
Condenser module DIC
iHMC module
Neutral-density filter 0.05
Mounting tool
Hex key, 1.5 mm
The condenser is rotated so that the mounting hole is accessible [
4 Installation | 4.9 Assembling the Light Shield
}
47]
}
48]
}
90].
