Zeiss Axiovert 5 Instruction Manual page 105

ZEISS
5.6.7.3 Operation during Experiments
ü
Prerequisite
ü
ü
Procedure 1. Place the sample on the stage.
2. Focus the sample.
3. Insert the polarization slider into the condenser.
4. Fine adjust the contrast on the polarization slider.
5.7 Setting Up for Reflected Light Techniques
5.7.1 Setting Up for Reflected Light Brightfield Microscopy

Parts and Tools




ü
Prerequisite
ü
ü
Procedure 1. If required, push the
2. Place the sample on the stage.
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
The microscope is operational.
The iHMC module in the condenser is aligned [
The iHMC diaphragm is aligned [
Screwdriver, 3.0 mm, ball head
Reflector module brightfield ACR P&C for reflected light
Stop slider for aperture and luminous-field diaphragm
Stop Slider A with Aperture Diaphragm
High-contrast reflected light sample
A reflected light illuminator is installed [
The microscope is operational.
only for Axiovert 7 RL and Axiovert 7 RL TL: The parfocal alignment is set [
RL
light illumination.
5 Operation | 5.7 Setting Up for Reflected Light Techniques
}
103].
}
103].
}
160] and adjusted, if required.
button for reflected
}
89].
105
