4 Installation | 4.10 Assembling a Contrast Module to the Condenser with Modulator Disk
Procedure 1. Remove the sealing cap from the mounting
2. Screw the desired contrast module onto the
3. Loosen the two centering screws on the mounting hole. Use the hex key.
4. Slightly tilt the mounting tool with the contrast module.
5. Insert the contrast module into the mounting hole. Press the bevel of the contrast module
6. Rotate the alignment unit of the mounting tool
7. Hold the alignment unit and turn the mounting tool to remove it from the contrast module.
8. Insert the sealing cap into the mounting hole.
9. Stick the adhesive labels specifying the contrast modules combinations to the front of the
10. Only for Phase stop PH and iHMC contrast module: align the contrast module [
Proceed in the reverse order for removal.
76
hole.
thread of the mounting tool.
socket against the aluminum-colored pressure piece.
to engage the cam into the recess.
condenser.
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
ZEISS
}
103].
