Zeiss Axiovert 5 Instruction Manual page 114

5 Operation | 5.7 Setting Up for Reflected Light Techniques
3. Using the analyzer turning lever, cross the vibration directions of the analyzer and the polar-
4. Place the sample on the stage.
5. Focus the sample.
5.7.6.3 Setting Polarization with the Analyzer Slider A and Polarizer Slider A

Parts and Tools

ü
Prerequisite
ü
Procedure 1. Slide the analyzer slider A 12x35 mm, 90° ro-
2. Slide the polarizer slider A into slot P.
3. Using the analyzer turning lever, cross the vibration directions of the analyzer and the polar-
4. Place the sample on the stage.
5. Focus the sample.
114
izer.
Analyzer slider A 12x35 mm, 90° rotatable
Polarizer Slider A 6x30 mm, 90° rotatable
The microscope is operational.
The illumination is adjusted for reflected light brightfield microscopy [
tatable into the slot under the reflector turret.
The analyzer slider may be inserted both from
the left-hand and right-hand sides.
izer.
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
ZEISS
}
105].
