3 Product and Functional Description | 3.2 Controls and Functional Elements on Components
Fig. 15: Axiovert 5 RL SCB and Axiovert 7 RL - Controls and functional elements (left side)
9
19
21
23
34
19 20
Focusing drive – coarse adjustment
}
Smart Control Box [ 52] (not included
in Axiovert 7 RL)
Release lever for adjustable focus stop
Axiocam
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
10 9 21 22
10 Focusing drive – fine adjustment
20 12x35 mm slider mount for analyzer
slider
22 Permanent/ECO mode switch
23
