5 Operation | 5.6 Setting Up for Transmitted Light Techniques
2. Slide the analyzer slider A 12x35 mm, 90° ro-
3. Using the polarizer slider lever, cross the vibration directions of the analyzer and the polar-
5.6.4.1 Color-contrasting of anisotropic materials
ü
Prerequisite
ü
ü
Procedure
1. Place the compensator on the analyzer slider A
2. Slide the analyzer slider A 12x35 mm, 90° rotatable with compensator into the slot under
3. Bring the polarizer into the beampath.
4. Bring the sample in the light path and focus the sample.
5. Use the lever of the compensator Lambda to select the best color impression.

5.6.5 Setting Up for Transmitted Light Polarization Contrast (Axiovert 5)

The present section applies to the following microscope types:
§
§
§
Parts and Tools
100
tatable into the slot under the reflector turret.
The analyzer slider may be inserted both from
the left-hand and the right-hand side.
izer until the field of view has reached the extinction position - maximum darkness.
The microscope is operational.
The microscope is adjusted for transmitted light polarization contrast [
One of the following components is available:
compensator Lambda
or
compensator Lambda Pol sub. ±10°
12x35 mm, 90° rotatable.
the reflector turret .
à
With the compensator Lambda the sample appears pinkish.
Axiovert 5 TL
Axiovert 5 TL SCB
Axiovert 5 TL FL SCB
LD Condenser 0.4 H Ph PlasDIC DIC iHMC
Polarizer Slider D 10x46 mm, 90° rotatable
Analyzer fixed for contrast slider 10x29 mm assembled to three-position contrast slider 10x29
mm for PlasDIC module and analyzer
alternatively: Analyzer module Pol ACR P&C for transmitted light in the reflector turret
Instruction Manual ZEISS Axiovert 5, Axiovert 5/7 materials | en-US | Rev. 6 | 431030-7011-101
ZEISS
}
99].
