Setting
b
c
Auto adjustment
Upper limit
Decimal point
Lower limit
Unit selection
Unit
Arbitrary unit
<Calculation formula>
The calculation formula is as follows.
Calculated data = {(a * CH-X) [+|–|*|/] (b * CH-Y) + c} * <Scaling>
By adjusting a, b and c, it is possible to support various Calculation formulas.
Example of settings
Calculation formula
CH1+CH2
3.0 * CH5+100
(2.5 * CH2)/(2.0 * CH3) – 20
<Scaling>
Scaling adjusts the unit of the calculation result.
For example, if the calculation result is "V" and you want the unit to be "mV", set the scaling to "*1000".
4-point input settings
Setting
CH-Z
The upper limit of a measured value
The upper limit of a calculated value
Decimal point
The lower limit of a measured value
The lower limit of a calculated value
Auto adjustment
Set the coefficient of CH-Y.
Set the offset value of the calculated value.
Adjust the span range based on the displayed measurement value.
Set the upper span value to display the waveform.
The set value is the value for the calculation result.
1.0000, 10.000, 100.00, 1000.0, 10000.
Select the decimal point of the calculated value.
* This is the same as the decimal point used for scaling.
Set the lower span value to display the waveform.
The set value is the value for the calculation result.
Select the unit that indicates the calculation results.
Voltage, Current, Length, Area, Volume, Velocity, Accel, Freq, Mass, Energy, Pressure, Flow, Temp,
Strain, Brightness, Concentration
Select the unit after conversion.
The unit displayed here is the unit selected in the "Unit selection".
When using the unit not displayed here, set any character in the "Arbitrary unit". Also, the unit set
here is displayed in the "Arbitrary unit".
Set a unit to be used after conversion.
Arbitrary text consisting of alphabetical characters and numerical values can be set as a unit.
(For the character entering, refer to "10. Text input" in "3.4 Setting Menus".)
When "Unit selection" or "Unit" is specified, it is reflected here.
CH-X CH-Y a
1 2 1.0000
5 Disregard 3.0000
2 3 2.5000
Select the CH number to be calculated.
Set the upper limit of the measured value.
Set the upper limit of the calculated value.
1.0000, 10.000, 100.00, 1000.0, 10000.
Select the decimal point of the calculated value.
* This is the same as the decimal point used for scaling.
Set the lower limit of the measured value.
Set the lower limit of the calculated value.
Adjust the span range based on the displayed measurement value.
Chapter 3 Settings and Measurement
Description
b c Operator
1.0000 0.0000
0.0000 100.0000 Disregard
2.0000 -20.0000
Description
3-35
Remarks
+ Inter-CH Op of an old model
Unary operation is possible
by setting b to 0
/ Use all functions
