4.2
Replay procedure
1. Replay procedure
We explain the simple procedure for replaying the captured data.
The captured data file uses the data captured in the "4.1 Capturing procedure".
The captured data files are stored in the "TEST\<date>" folder in the internal memory (MEM).
Since the captured data file name was saved with an automatic file name function, a file named "Month/Day/Year-Time.
GBD" has been created. (The Month/Day/Year and Time are the time when capturing started.)
1.
Press the "REVIEW" key.
2.
The data replay source specification dialog opens.
The data file specified in the data replay source dialog is set to the data file captured immediately before.
If you are performing this procedure immediately after performing "4.1 Capturing procedure", skip the "Specifying the data
file to replay" below.
Specifying the data file to replay
1.
In the data replay source specification dialog, move the cursor to the file and press the "ENTER" key.
4-12
Chapter 4 Example of Use
