(11) DISPLAY
<When free-running and data capturing>
This key is used to switch the screen mode.
When free-running (when the recording is stopped), data capturing, and
data replaying during the capture, the screen mode can be switched.
Pressing this key switches the screen display as follows:
<Waveform + Digital Screen>
Displays the waveform and the digital values.
<Expanded Waveform screen>
Displays only the waveform expanded in full-screen mode.
<Digital + Calculation Display screen>
Displays digital values and two calculation results in large letters.
Use the
mode. The calculation results are displayed only when switched
to "All Mode".
Refer to "(8) FAST FORWARD key (KEY LOCK)"
<Alarm History screen>
When "Alarm settings" – "Alarm History" is set to enable, the Alarm
History is displayed during capturing.
Refer to "Alarm History".
[DISPLAY] key
Chapter 3 Settings and Measurement
FAST FORWARD keys to change the display
3-15
