List of Options
Item
Input/output cable for GL
DC drive cable
1
Humidity sensor *
Standard 20CH screw terminal
Standard 20CH screwless terminal
Standard 30CH screwless terminal
Withstand high-voltage high-precision
terminal
Base unit for input terminal
Connection cable for extension
terminal
Wireless unit
Battery pack
Bracket for DIN rail (GL860 main body)
Bracket for DIN rail
Shunt resistor
Input terminal cover
*1: Allowable temperature range: –25 to +80°C
Model
B-513 2 m long (no clip on end of cable)
B-514 2 m long (no clip on end of cable)
B-530 3 m long (with power plug)
B-563 20CH standardt erminal
B-563SL 20CH screwless terminal
B-563SL-30 30CH screwless terminal
B-565 20CH Withstand high-voltage high-precision terminal
B-566 Extension terminal base unit, connection plate, screws
B-567-05 Connection cable (50 cm)
B-567-20 Connection cable (2 m)
B-568 Wireless LAN
B-573 7.2V/2875mAh
B-570 Built to order
B-540 Built to order
B-551 Built to order.
250 Ω, Rated power of 1 W, Maximum service voltage of 15.8 V
B-588 Protective cover
5-14
Chapter 5 Specification
Description
