GRAPHTEC miid LOGGER GL860 User Manual page 144

Selection item
Operation Ring capturing function
settings
Relay capturing function
Backup function
Trigger function
Alarm function
Game
Communication I/F command function
settings
FTP server function
WEB server function
•
This setting is also displayed at the first startup. If you skip the setting at the first startup, the same setting is possible
from this setting.
•
When any function is turned off, "Displaying custom menu" is displayed on the DATA menu to indicate that the function is
restricted.
Select whether to use the ring capturing function.
On: Used.
Off: Not used.
* For the ring capturing function, refer to "2-5. Ring/Relay capturing settings".
Select whether to use the relay capturing function.
On: Used.
Off: Not used.
* For the relay capturing function, refer to "2-5. Ring/Relay capturing settings".
Select whether to use the backup function.
On: Used.
Off: Not used.
* For the backup function, refer to "2-6. Backup setting".
Select whether to use the trigger function.
On: Used.
Off: Not used.
* For the trigger function, refer to "3. TRIG settings".
Select whether to use the alarm function.
On: Used.
Off: Not used.
* For the alarm function, refer to "4. ALARM settings".
Select whether to use the game.
On: Used.
Off: Not used.
* For the alarm function, refer to "6-8. Game".
Select whether to use the I/F command function.
On: Used.
Off: Not used.
* For the trigger function, refer to "5.9. Network settings".
Select whether to use the FTP server function.
On: Used.
Off: Not used.
* For the trigger function, refer to "5.9. Network settings".
Select whether to use the WEB server function.
On: Used.
Off: Not used.
* For the trigger function, refer to "5.9. Network settings".
3-88
Chapter 3 Settings and Measurement
Description
