This GL860 is meant for use in Japan, the US, Europe,Taiwan,China and Korea. It has not been certified
for use under any other country's radio laws.
The following are each region's certification marks.
Japan
R 003WWA100913
US
Contains FCC ID: ANSBP3591
Europe
CE Mark
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC CAUTION
Change or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
4. Notes for Safe Operation
(1) Be sure to use the Graphtec-supplied AC adapter. In environments where there is a lot of noise or where the
power supply is unstable, we recommend that you ground the GL860.
(2) When a high-voltage signal cable has been connected to the main unit's analog signal input terminal, avoid
touching the leads of the input terminal's signal cable to prevent electrical shock due to high voltage.
(3) Ensure that the GL860's power source is positioned so that it can easily be disconnected.
(4) Do not input the voltage that is exceeding the specification of this device.
• If a voltage exceeding the specified value is input, the semiconductor relay in the input section will be
damaged. Never input a voltage exceeding the specified value even for a moment. It will cause a fire.
• Have enough margin from the specification of withstanding voltage when using this device, it has to consider
noise and change of the measurement voltage.
• Confirm this device is not broken before the input cable is connected to the input terminal.
• Please take care of the static electricity when connecting the input cables or the thermocouples.
• Do not touch the tip of the thermocouples with a bare hand after the thermocouples are connected to the
terminal of this device when the tip of the thermocouples is not insulated.
The static electricity of the human body will cause damage to this device.
• Do not put the tip of the thermocouples on the object which is containing the static electricity when the tip of
the thermocouples is not insulated. The static electricity of an object will cause damage to this device.
• Do not put the tip of the thermocouples to the object which is containing the leaked high voltage of chassis or
metal etc. when the tip of the thermocouples is not insulated.
The leaked high voltage of the object will cause damage to this device.
• We recommend that the insulation tape be put on the tip of the thermocouples before connecting the
thermocouples to the input terminals.
This will protect this device from the static electricity and the leaked high voltage.
* All CHs are applicable even when CHs are extended.
* When B-563 (B-563SL, B-563SL-30) and B-565 are mixed, all CHs are subject to B-563 (B-563SL,
B-563SL-30) specifications.
Taiwan
Contains NCC ID:
China
CMIIT ID: 2015DJ5376
Korea
MSIP-CRI-KTM-B-568
II
Introduction
CCAB15LP4220T2
