5-4. Station setting
When connecting to the commercially available wireless LAN base unit and controlling multiple GL860s from a PC, the
e-mail send function of the GL860 and Internet connection are available. (The following conditions are required to use
them.)
•
PC connectable to Wireless LAN.
•
Wireless LAN base unit. (Wi-Fi-authenticated devices equipped with wireless LAN base unit functions.)
•
Internet connection environment when connecting to the Internet.
(Internet provider's contracts and mobile carrier's contracts, etc.)
•
Internet connection and e-mail send environments when sending the e-mail.
(E-mail and webmail must be able to send and receive in the SMTP and SMTP via the Internet provider.)
Each station function must be set when the GL860 operates as a child unit.
When the station is selected in the wireless LAN settings and the wireless LAN is restarted, the following screen is
displayed.
•
Station (operated as remote unit)
This is the settings for controlling from a PC and transferring data to a PC after connecting to the separately sold wireless
LAN base unit. When in station configuration, wired LAN cannot be used.
•
After executing "Wireless LAN restart" once, the wireless LAN cannot selected. When the wireless LAN selection is
changed, the restart is enabled.
"Disconnect" "Wireless LAN restarting" "TCP-IP restarting" are executed.
<If the NONE>
Selection item
Wireless LAN
AUTO SETTING (WPS)
SSID search
SSID input
Encryption method
WEP key
Password
11n
Apply settings (Connect)
Disconnection
TCP-IP settings
<If the WEP>
Switches between Off, Stations and Access points.
Select the setting to change and execute "Wireless LAN Restart".
Execute auto-connect using WPS. For details, refer to "How to use WPS".
A list of wireless access points (base unit) can be displayed by searching for an SID.
When you select the access point (base unit) to connect in the list, it is displayed in the SSID input.
Set the SSID (access point identification name) of the access point (base unit) to be connected.
Up to 32 characters can be entered using alphanumeric characters and symbols.
Set the encryption method to NONE, WEP, WPA-PSK/WPA2-PSK.
Set the WEP key with 10-digit alphanumeric characters for WEP64 and 26-digit alphanumeric
characters for WEP128.
Set a password with 8 to 63 alphanumeric characters.
Select whether to use wireless standard 11n or not.
Save the settings and reconnect.
Disconnect the wireless LAN connection.
Acquire the station IP address setting of the wireless LAN unit automatically or set it manually.
After setting, reflect the settings ("
For server settings, refer to "5-9. Network settings".
3-69
Chapter 3 Settings and Measurement
<If the WPA-PSK/WPA2-PSK>
Description
" key) and restart to complete.
