Self-Adhesive Strip - Intermec EasyCoder PM4i User Manual

Self-Adhesive Strip

EasyCoder PM4i Printer User's Guide (Fingerprint Version)
⇐ a ⇒ Media Width (including liner)
Maximum:
Minimum:
⇐ b ⇒ Liner
The liner must not extend more than a total of 1.6 mm (0.06 in)
outside the face material and should protrude equally on both
sides.
⇐ c ⇒ Media Width (excluding liner)
Maximum:
Minimum:
Media Type Setup
• Fix length strip
• Var length strip
Appendix B — Media Specifications
114.3 mm (4.50 in)
25.0 mm (1.00 in)
112.7 mm (4.43 in)
23.8 mm (0.94 in)
133
