Self-Adhesive Strip - Intermec EasyCoder 501 S Installation And Operation Manual

Appendix 2 Media Specifi cations
Media, cont.

Self-Adhesive Strip

112
a Media Width (including liner)
Maximum:
Minimum:
b Liner
The liner must not extend more than a total of 1.6 mm (0.06
inches) outside the face material and should protrude equally
on both sides.
c Media Width (excluding liner)
Maximum:
Minimum:
Media Type Setup
• Fix length strip
• Var length strip
This type of media is not suitable for use with a cutter.
Intermec EasyCoder 501 S – Installation & Operation Ed. 1
120.0 mm (4.72 inches)
25.4 mm (1.00 inches)
118.4 mm (4.66 inches)
23.8 mm (0.94 inches)
