Printing Cards; Print Cards Using Id Software - DataCard RP90 User Manual

Printing cards

Cards can be sent from ID software such as Datacard
ID software handles the types of information used on cards.
If you do not have ID software, you can use another PC application to format the
information to print on cards; however, most PC applications do not support magnetic
stripe encoding or smart card programming. With any application, test the card design to
verify the results.
The printer's LCD panel displays the following sequence when a card is sent to print:

Print cards using ID software

18
1 Follow the instructions for the ID software to capture, format, and save the data for
the card.
In the software, send cards to the
2
printer (usually, use the Print button).
The printer driver receives data for
3
each card, prepares the card for
printing, and sends each card to the
printer.
Printing cards
ID Works identification software.
® ®
RP90 Plus E and RL90 User Guide
