Using the Laminator LCD panel

Use the LCD panel to change laminator settings, or use the Laminator tab of the Status
Monitor to change some settings from the PC.
LCD Display
Mode
Film
Film Position
Temp
Speed
Card Fan
Cool Time
Power Save
LCD contrast
Cleaning
Online Setting
42
Settings
Single
Pass
1-mil
0.6 mil
overlay
-7 to +7
Temperature, default 170°
Lamination speed, default
5.5mm/sec
Off, Low, Half, High, or
Full
0 (default), 5, 7, or 10
seconds
Off, 10, 20, 30 (default),
or 60 minutes
1 to 5
Without HR
With HR
Function
Default setting; laminates on one side only.
Passes card without laminating.
1-mil is the default setting. Use it for patch film 1-mil thick.
Use for patch film 0.6-mil thick.
Use with topcoat with no positioning markings.
Adjusts the patch transfer position. Default setting is 0; the
patch moves to the right with a positive value and to the left
with a negative value.
Press the RESET/ key to set temperature from 120° C to
200° C in 5° increments.
Press the ENTER key to confirm selection.
Press ENTER and use the RESET/ key to set lamination
speed from 2mm/sec to 10mm/sec in 0.5mm/sec
increments. The value that can be set may be limited by
the temperature setting.
Press the ENTER key to confirm selection.
Press the RESET/ key to turn the card cooling fan Off
(default), Low, Half, High, or Full.
Press the ENTER key to confirm selection.
Press the RESET/ key to select the amount of cooling
time before laminating starts.
Lowers the heater temperature if no lamination has
occurred in the set time period. Preheating automatically
returns when a card enters the laminator.
Using the default value of 30 minutes can reduce
discoloration of the laminator material.
Press the RESET/ key to set the LCD display contrast
from 1 to 5. The larger the number, the higher the contrast.
Cleans the transport roller only.
Cleans transport and heat rollers. Remove the laminate
cartridge to clean the heat roller. See
laminator" on page 49
for more information.
Displays settings sent from the PC when the RL90 is
connected through an RP90 Plus E printer to a PC.
RP90 Plus E and RL90 User Guide
Using the LCD menus
"Cleaning the
