Load Laminate - DataCard RP90 User Manual

Load Supplies

Load laminate

Tips: Handling patch
or topcoat material
After powering on the
•
laminator, the patch or
topcoat material must be
initialized. Press the
laminator's RESET/ and
then the ENTER keys to
initialize the material.
The inside of the laminator
•
contains hot surfaces. Use
care when working in these
areas.
Keep unused laminating
•
material in the original
package.
Don't place material on a
•
dusty or dirty surface — dirt
can affect card quality.
During the laminating
•
process, do not turn the
power switch off, open the
laminator door, or unplug the
laminator.
See "Laminator material" on
•
page 68 for more information
about laminating material.
RP90 Plus E and RL90 User Guide
Open the laminator door by
1
pulling the top of the door
toward you.
Press the laminator cartridge
2
eject button and remove the
laminator cartridge carefully.
The material must be tight
when removing the cartridge.
Place the roll of
3
material and
empty take-up
spool side by side
on a clean
surface.
Remove the label from the
4
patch or topcoat material and
use it to secure the free end of
the material to the empty take-
up spool, making sure the
edges are even.
Load the new roll of material
5
on the cartridge:
Put the full roll of material
a
on the supply spindle.
Put the empty take-up
b
spool on the take-up
spindle.
Align the material along
c
the four metal guides as
shown on the cartridge
label.
Wind two or three
d
rotations of film onto the
take-up spool. Take up
slack between the spools
by turning the supply knob
clockwise. If slack cannot
be removed, check that
the supply and take-up
spools are firmly seated on
the spindles.
6 Replace the loaded laminator
cartridge in the laminator until
it clicks into position.
Close the laminator door.
7
