Retransfer tab

The Retransfer tab shows:
Tips for success

Bend Remedy tab

The Bend Remedy tab shows:
Tips for success
28
• Controls for viewing or changing magnetic stripe settings.
— Number of Retry, which sets the maximum number of retries when writing or
reading magnetic stripe data fails. Default value is 1.
— ISO Mode, which sets the power used by the magnetic card encoder. The
default is Hi-Co.
• A control to enable or disable the buzzer.
• A control to set power saving, which reduces the temperature of the retransfer heat
roller after the printer is not used for 30 minutes. The default is Disable.
• Controls to specify the smart card module(s) (IC Encoder) in the printer.
Two matrices for setting the retransfer speed
•
and temperature. Click a square to choose the
setting. On the printer, press the
and then the Enter button to initialize the
printer and make the new setting take effect.
The card type, set on the Media Setting tab.
•
The Refresh button which displays the current
•
printer data.
The transfer power to the card gets stronger
•
towards the upper right, but the card becomes
more distorted due to the heat.
Changing the retransfer temperature on one card side also affects the other side.
•
The range of values changes with the Card Type setting.
•
• Make sample cards to verify settings before using new settings.
• A matrix for setting the bend remedy time and
temperature. Click a square to choose the
setting. On the printer, press the
and then the button to initialize the
Enter
printer and make the new setting take effect.
The card type, set on the Media Setting tab.
•
Bend remedy is effective for single side
•
printing. For double side printing, choose the
Disable button.
When you change to Disable, the printer goes
•
into state for about 10 minutes while
Preheat
the roller temperature drops. Wait until the printer state changes to
• The side of the card where bend remedy is performed can become faded.
• Make sample cards to verify settings before using the new settings.
Reset button
Reset button
RP90 Plus E and RL90 User Guide
Status Monitor
.
Ready
