Status Monitor

Others tab

The Others tab shows the following for a USB-
connected printer:
For both USB-connected and Ethernet-connected
printers, the tab shows:

Status monitor messages

The following messages appear on the Status Monitor Status tab. See
on page 26
Error Code Displayed Message
No Printer is found.
0102D000 There is no card. Please supply cards.
0102D100 Printer door is opened. Please close the
door and initialize the printer by pressing
RESET and ENTER button.
0102D600 Ink Ribbon Cassette or Retransfer Film
Cassette is not set.
0102D700 Cleaning Unit is not set.
01039000 Feed Jam happens. Please unset the
card tray and remove the card after
turning off the printer power.
RP90 Plus E and RL90 User Guide
Controls for printing a test card. The printer will
•
create one test card, using the internal test
pattern.
A control for saving a command log. Your
•
service provider might ask you to save a
command log as part of troubleshooting.
Controls for selecting a firmware file and
•
sending it to the printer. Only update printer
firmware when your service provider
recommends it.
• Version information for the Status Monitor.
.
Solution
• Make sure that the host PC and the printers are
connected properly with a USB cable.
• Make sure that the printer is switched on.
1 Load cards as described in
page 8
.
2 Close or replace the card hopper securely.
1 Close the printer door.
2 Press RESET and then ENTER to initialize the
printer.
1 Load the Ink Ribbon Cassette or Retransfer
Film Cassette and then close the printer door.
2 Press RESET and then ENTER to initialize the
printer.
1 Install the Cleaning Unit and then close the card
hopper.
2 Press RESET and then ENTER to initialize the
printer.
1 Switch off the printer power.
"Hopper jam" on page 52
2 See
card.
3 Switch on the printer power.
"Printer Status tab"
"Load cards" on
to remove the
