Load Supplies
Load cards
Tips: Handling cards
•
Do not open the card
hopper when "Loading"
is displayed on the LCD
panel.
Do not touch the
•
surface of cards before
printing them. (Oils on
hands will reduce
printing quality.)
Handle cards by the
•
edges or wear cotton
gloves.
Cards can stick
•
together. Slide or fan
cards to separate the
edges.
•
Orient all cards the
same way.
Do not use cards that
•
are bent or otherwise
damaged.
"Supplies" on
See
•
page 67
for specific
card information.
8
The card hopper can hold approximately 250, .030" (.75mm) cards. The cards
are loaded and held in position with a card bracket. Make sure that magnetic
stripe or smart cards are loaded in the proper orientation for processing.
Open the card hopper.
1
2
Slide the card bracket to the left until it latches.
Insert cards. See the diagrams below for the correct card orientation.
3
— Load magnetic stripe cards with the magnetic stripe down and
facing the card bracket.
— Load smart cards with the smart card chip toward the back of the
card hopper, facing the card feed roller.
Slide the card bracket back into position carefully so cards are not
4
disturbed and your fingers do not get pinched.
Close the card hopper.
5
Magnetic stripe card orientation
Load Supplies
Smart card chip orientation
RP90 Plus E and RL90 User Guide
