Datacard
RP90 Plus E Card Printer
and RL90 Laminator
Hardware and Driver Installation Manual
June 2008
Part No. 539652-002, Rev C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RP90 Plus E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DataCard RP90 Plus E

Summary of Contents for DataCard RP90 Plus E

  • Page 1 ® Datacard RP90 Plus E Card Printer and RL90 Laminator Hardware and Driver Installation Manual June 2008 Part No. 539652-002, Rev C...
  • Page 2 Liability Statement This product has been built to the high standards of Datacard Group. Please do not attempt to operate or repair this equipment without adequate training. Any use, operation, or repair in contravention of this document is at your own risk. By acceptance of this system you hereby assume all liability consequent to your use or misuse of this equipment.

  • Page 3: Table Of Contents

    Contents Preparing for Installation ____________________________________________ 1 Packing lists ____________________________________________________ 1 Unpacking the RP90 Plus E Printer __________________________________ 2 Unpacking the Optional RL90 Laminator ______________________________ 2 Unpacking other options ___________________________________________ 2 Installing the Printer ________________________________________________ 2 Choosing a Location ______________________________________________ 2...

  • Page 4: Preparing For Installation

    ID software, such as Datacard ID Works software • Printer Plug-in software Packing lists The shipping carton for the Datacard® RP90 Plus E Card Printer contains: • RP90 Plus E Card Printer • Power Cord • RP90 Plus E and RL90 User Guide (PN 570024-001) •...

  • Page 5: Unpacking The Rp90 Plus E Printer

    (22kg). Use care when removing the printer from the shipping container. Remove the RP90 Plus E card printer from the shipping carton. Remove all packing tape from inside and around the printer. Remove the protective cushion that protects the printhead.

  • Page 6: Providing Adequate Printer Ventilation

    Caution: Make sure that the power switch is turned OFF and the power cable is detached from the receptacle before connecting or disconnecting the laminator. If not, electric shock, fire, or malfunction of the product might occur. RP90 Plus Card Printer Installation Manual...
  • Page 7 (The factory default setting is 220-240V AC.) Mount the RP90 Plus E printer over the holes on the joining plate as shown in the following figure. Mount the RL90 laminator over the remaining two holes on the joining plate as shown in the figure below.
  • Page 8 Connect one end of the connecting cable to the connector labeled OPTION 2 on the printer and connect the other end to the connector labeled PRINTER on the laminator. Caution: Always power off the printer and laminator before you connect or disconnect the laminator cable. RP90 Plus Card Printer Installation Manual...

  • Page 9: Installing The Card Stacker

    Installing the Card Stacker Card Stacker on Printer Hang the stacker claw on the stacker receptacle as shown in the following figure. Be sure to hang the card stacker claw on the card stacker receptacle, not on the card discharge slot. The card stacker can hold up to 100 0.76mm (0.03 inch) thick cards or 280 0.25mm (0.01 inch) thick cards.

  • Page 10: Connecting The Power Cord(S)

    If you use the optional RL90 laminator, plug the power cable into the back of the laminator. Plug the power cord(s) into the facility power source. Caution: Do not power on the printer until instructed to do so during the installation of the printer driver. RP90 Plus Card Printer Installation Manual...

  • Page 11: Connecting The Data Cable

    Connect the USB Cable Connect the Network Cable Note: If you plan to use the Datacard Software Plug-in and smart card, use only a USB cable for the data cable. A network connection for smart card is not supported by the Datacard Software Plug-in.

  • Page 12: Installing The Printer Driver

    XP, Windows 2000 or Windows Vista operating system and log in as a user with Administrator permissions. Insert the RP90 Plus E Support CD-ROM in the PC drive. On Windows Vista, a User Account Control dialog might appear. Click Allow to continue.
  • Page 13 The Card Printer installation window opens. Make sure that the following are checked and then click Next: • USB connection • Install • Printer Driver On the Software License Agreement, Click I agree and then click Next. When the following dialog box appears, make sure all printing from the PC is complete and then close all other Windows applications.
  • Page 14 Select the Printer model from the table. If this is the first RP90 Plus E printer installed on this PC, the default printer is “Datacard RP90 Plus E U1.” For best results, use the printer name shown. • “U1” is the unit number, and it must match the USB port you create and the “Unit No.”...
  • Page 15 To share the printer, see “Sharing a Printer on a Network Connection” on ® page 32. The printer name used in this section is Datacard RP90 Plus E U1. • Sharing can be disabled after the driver is installed, if needed.
  • Page 16 Review the summary of choices and then click Finish. The wizard copies driver files. A Windows message appears. • On Windows XP, the Windows Logo testing message appears. Click Continue Anyway to continue with installation. RP90 Plus E Card Printer Installation Manual...
  • Page 17 • On Windows 2000, the Digital Signature Not Found message appears. Click Yes to continue with installation. • On Windows Vista, a Windows Security dialog box can appear. Choose Install this driver . . . to continue. • Security on the PC might be set to prevent installation without a digital signature. See Windows help for "digital signature"...
  • Page 18 On PCs running Windows XP with Service Pack 2, the Welcome to the Found New Hardware Wizard provides the option to search the internet for a driver. Click No, not this time and then click Next. RP90 Plus E Card Printer Installation Manual...
  • Page 19 Click Finish to continue. The RP90 Plus E U-Port dialog box appears. On the Property tab, review the information. For best results, do not change the information. Click OK. If the Printer List displays “No Device,” the USB connection is not correct.
  • Page 20 “Installing the Status Monitor” on page ® After installing the driver and optional Status Monitor, you can install the optional Datacard Software plug-in for the RP90 Plus E Printer. If you want to delete the printer, restart Windows and then follow the steps in “Removing the Printer Driver”...

  • Page 21: About Network Installation

    About Network Installation You can install the printer over the network with the following choices: • Use DHCP or static addressing This choice can be set using the LCD panel or the Status Monitor. It does not affect the procedure you use to install the printer. See “Choosing How to Assign the Network Address”...
  • Page 22 PC can fail and cards will not print. The following shows the process you might follow to enable two PCs to print using a Printer Certificate with IPSec. RP90 Plus E Card Printer Installation Manual...
  • Page 23 To set up IPSec Security using a printer certificate, do the following: Obtain the printer certificate and install it on the PC. Export the Printer Certificate and Certificate Authority (CA) Certificate to files. Open the Management Console by choosing Start > Run. Type mmc in the Run dialog and click OK.
  • Page 24 Power on the printer. For best results, do not send any cards to print. Use the printer LCD panel to set IPSec Mode to ON. See the Printer LCD Panel section of the User Guide. RP90 Plus E Card Printer Installation Manual...

  • Page 25: Install Using A Network Connection

    Use the printer LCD panel to set IPSec Type to Preshared Key. Install the printer using a USB connection and install the Status Monitor. See “Install using a USB connection” on page 9 “Installing the Status Monitor” on page 30 for the steps to follow.
  • Page 26 Insert the RP90 Plus E Support CD-ROM in the PC drive. For Windows Vista, the User Account Control dialog appears. Choose Allow to continue installation. When the opening window is displayed, choose Install the Printer. The Card Printer installation window opens.
  • Page 27 Close all active programs before installing the printer driver. Select the Printer model from the list. If this is the first RP90 Plus E printer installed on this PC, the default printer is “Datacard RP90 Plus E LAN.” For best results, use the printer name shown.
  • Page 28 To share the printer, see “Sharing a Printer on a Network Connection” on ® page 32. The printer name used in this section is Datacard RP90 Plus E LAN. • Sharing can be disabled after the driver is installed, if needed.
  • Page 29 Review the summary of choices and then click Finish. The wizard begins copying driver files. The installation displays a message regarding port creation. A Windows message appears. • On Windows XP, the Windows Logo testing message appears. Click Continue Anyway to continue with installation. Installing the Printer Driver...
  • Page 30 See Windows help for "digital signature" or "Logo signing" to change the security setting. The RP90 Plus E N-Port dialog box appears. On the Property tab, enter a port name, such as RP90 Plus E LAN. RP90 Plus E Card Printer Installation Manual...
  • Page 31 From the Printer List, choose the entry with the printer name and IP address. Click • If the printer name and IP address do not appear, retrieve the IP address, as described in the Printer LCD Panel section of the User Guide, and then click Find.
  • Page 32 Continue with installing the status monitor. ® After installing the driver and optional Status Monitor, you can install the optional Datacard Software plug-in for the RP90 Plus E Printer. If you want to delete the printer, restart Windows and then follow the steps in “Removing the Printer Driver”...

  • Page 33: Installing The Status Monitor

    XP, Windows 2000 or Windows Vista operating system and log in as a user with Administrator permissions. Insert the RP90 Plus E Support CD-ROM in the PC drive. When the opening window is displayed, choose Install the Printer. Choose Install the RP90 Plus E Driver.
  • Page 34 Register for start menu checked, to allow opening the Status Monitor from the Windows Start menu. Click Next to install Status Monitor files. When the Status Monitor is installed, click Finish. Click OK to complete this installation. RP90 Plus E Card Printer Installation Manual...

  • Page 35: Sharing A Printer On A Network Connection

    The PC returns to the Card Printer window. Click Exit and remove the CD from the PC’s drive. You can open the RP90 Plus E Status Monitor from the Start menu (and from the desktop icon if one is installed). See the User Guide for information about using the Status Monitor.
  • Page 36 Add a printer. • For Windows XP or 2000, choose the Add Printer icon (or choose File > Add Printer from the menu). • For Windows Vista, choose Add a printer from the toolbar. RP90 Plus E Card Printer Installation Manual...
  • Page 37 The Add Printer Wizard appears. Click Next. For Windows XP or 2000, choose A network printer, or a printer attached to another computer and then click Next. For Windows Vista, choose Add a network . . . printer and then click Next. •...
  • Page 38 Browse the network for the host PC computer name and then locate the shared printer attached to it. Choose Datacard RP90 Plus E U1 (Shared) (or other printer name) from the Shared printers list and then click Next. An information dialog box appears.
  • Page 39 On Windows 2000, the wizard displays the following dialog box. Choose Yes or No (depending on your needs) and then click Next. On Windows Vista, the wizard prompts for a printer name. Use the default printer name and click Next. Click Finish on the “complete”...

  • Page 40: Removing The Printer Driver

    Close all active programs before removing the printer driver. For best results, begin with the printer powered on and connected to the PC. With Windows running, insert the RP90 Plus E Support CD-ROM in the PC drive. Choose Install the RP90 Plus E Driver.
  • Page 41 The opening dialog box appears. Click Next. Choose the printer from the Printer model list and then click Next. Installing the Printer Driver...
  • Page 42 To remove driver files, click Finish. When the following dialog box appears, click Finish. The printer driver has been removed. Continue with removing the Status Monitor it is was installed, or restart Windows. RP90 Plus E Card Printer Installation Manual...

  • Page 43: Removing The Status Monitor

    Removing the Status Monitor Remove the Status Monitor after removing the driver. Begin with the Card Printer installation window open. Make sure the following are selected, and then click Next: • Uninstall • Status Monitor Click OK. Click Yes to continue. Installing the Printer Driver...

  • Page 44: Updating The Printer Driver

    • Remove the existing printer driver, as described in “Removing the Printer Driver” on page • Restart Windows. • Install the newer printer driver, as described in “Installing the Printer Driver” on page RP90 Plus E Card Printer Installation Manual...
  • Page 45 Installing the Printer Driver...

  • Page 46: Regulatory Compliance

    édicté par le ministère des Communications du Canada. Safety All Datacard products are built to strict safety and reliability specifications in accordance with UL60950-1 and CUL requirements; therefore, safety issues pertaining to operation and repair of Datacard equipment are primarily environmental and human interface.
  • Page 47 • Do not use this product in an environment containing volatile or flammable compounds. Safe Human Interface • Use proper lifting techniques when moving or installing the equipment. • Use standard electrostatic discharge (ESD) precautions when working on or near electrical circuits. •...
  • Page 48 11111 Bren Road West Minnetonka, MN 55343-9015 952.933.1223 952.933.7971 FAX www.datacard.com The design and information contained in June 2008 539652-002 Rev. C these materials are protected by US and international copyright laws and treaties.
