Mending broken ink ribbon or retransfer film

RP90 Plus E and RL90 User Guide
If the ink ribbon or retransfer film breaks, "Media Broken" is displayed on the
LCD panel. Broken ink ribbon is shown in the following example; repairing
broken retransfer film uses the same steps.
1 Slide the door latch to the right and open the printer door.
Remove the cartridge by pressing the cartridge eject button.
2
Trim the ends of the broken
3
portions evenly.
Do not remove the used ink
4
ribbon or film from the take-up
spool.
Align the ends of the broken
5
media evenly and apply tape
to secure.
6 Turn the take-up spool
clockwise until the mended
portion is wound onto the
spool two or three turns.
Reinstall the cartridge into the
7
printer until it clicks into
position.
Close printer door.
8
Initialize the ribbon or film as
9
"Initialize the ink
described in
ribbon" on page 16
"Initialize the retransfer film"
on page 17
.
or
Printer error recovery
55
