Property tab

The Property tab shows:

Printer Select tab

The Printer Select tab shows:
30
• The version of printer firmware, and firmware
versions of any installed options such as
magnetic stripe encoder or laminator. "
means an option is not installed or connected.
Configuration information for options installed.
•
• The unit number. (Use the LCD panel to set the
unit number, described in
LCD panel" on page 36
• The Print Count, which is the number of cards
printed.
The Thermal Head count, which is the number
•
of panels printed by the printhead currently
installed in the printer. (YMCK ink ribbon has four panels.)
The currently selected printer.
•
If more than one RP90 Plus E printer is
•
installed on the PC, you can change the printer
for which information is displayed by choosing
it from the Current Printer list. The Status
Monitor will communicate with the printer to
update information.
• Use the Scan button to locate another printer if
it is not displayed in the list.
Use the button to send the current
• Sync Time
time on the PC to the printer.
Use the button to send changed values
• Update
to the printer.
Use the button to obtain current values from the printer.
• Refresh
If the printer is set, using the LCD panel, to use a LAN connection, this tab displays
•
the default settings (which cannot be changed). If the printer is connected using a
USB connection, you can use this page to set the IP address and other network
values. See About Network Settings
If you need to assign a printer name different from a choice provided by the printer,
•
make sure the printer is installed with a USB connection and then enter the new
printer name. Your network administrator can provide information about allowed or
required names on your network.
• Security settings, which can be set only when the printer is connected using a USB
connection. are available. Use the
box. See the
Installation Guide
"
????
"Using the Printer
.)
in the Installation Guide
button to open the IPSec Setting dialog
Details
for the steps to follow.
RP90 Plus E and RL90 User Guide
Status Monitor
.
