Laminator tab
Tips – Card cleaning roller
Values are blank if the
•
printer is disconnected
or powered off.
Graphics controls show
•
all red if the printer is
disconnected or
powered off.
Clicking on buttons
•
displays the "No printer
is found." message if
the printer is
disconnected or
powered off.

Printing Properties

24
The Laminator tab contains settings
for using the optional RL90
laminator. You can set whether to
apply material to the front of the card,
the back of the card or both. You can
also set the temperature, speed,
patch position, and fan settings for
each side of the card.
Use this tab only if an RL90 laminator
is connected to the printer.
Version tab
The Version tab shows the build
version of the printer driver. Your
service provider might ask you for
this information.
The Printing Properties dialog box options are set up when the printer is
installed or by your system administrator.
Choose Start from the Windows task bar.
1
2 Choose Settings and then Printers (and Faxes). The Printers (and
Faxes) window opens.
Click once on the Datacard RP90 Plus E U1 printer icon to select it.
3
— The driver must be installed for the printer icon to be present.
— Datacard RP90 Plus E U1 is the default
name of the printer. The name of your
printer might be different.
From the File menu, choose Properties.
4
The Properties window opens.
5 Use the tabs to set up Sharing, Ports, Color
Management, Security, and Advanced
options.
Choose OK to save and close, or choose
6
Cancel to close without saving changes.

Printing Properties

RP90 Plus E and RL90 User Guide
