Cleaning the card feed rollers and heat roller

Tips – Cleaning card feed
and heat rollers
• The heat roller cannot be
cleaned while hot. Power
the printer off and allow it
to cool, or perform
cleaning before the heat
roller reaches operating
temperature.
• Clean the card feed
rollers and heat roller
every 1,000 printed
cards.
Use the cleaning card
•
one time only. Using a
dirty cleaning card can
cause damage to the
rollers.
RP90 Plus E and RL90 User Guide
The heat roller provides the heat used during the retransfer process. The card
feed rollers move the card inside the printer. See
page 51 to find the location of the rollers.
Begin with the printer (and optional laminator) powered off.
Move the RL90 laminator (if installed) away from the printer to avoid a
1
card jam during the cleaning process.
2 Slide the door latch to the right and open the printer door.
Press the retransfer film cartridge eject button and remove the
3
retransfer film cartridge.
Close the printer door.
4
Power on the printer. See
5
The "No Cassette" message is displayed on the LCD display.
6
Remove the protective paper from a cleaning card.
7
Press the MENU key until "Cleaning" is displayed.
8
Press the ENTER key.
9
"Rollers OK?" is displayed. Press the ENTER key.
10
Insert the cleaning card into the card slot located on the right side of
11
the printer within 10 seconds. The card will be drawn into the printer by
the rollers and cleaning will begin.
12 Turn the card over when it is discharged and repeat Step 11 to
complete the cleaning process.
When the cleaning card is discharged, power off the printer, wait ten
13
seconds, reinstall the retransfer film cartridge, and power back on.
Cleaning the printer
"Printer roller layout" on
"Power on the printer" on page 15 .
